MATKI ONE
MOPR - RECESS INLINE PIVOT
INSTALLATION
PARTS LIST
Please pass the
Guarantee Card
to the customer.
13
Matki PLC, Churchward Road, Yate,
Bristol BS37 5PL
EN 14428:2008+A1
MATKI PLC, CHURCHWARD ROAD, YATE, BRISTOL, BS37 5PL
TELEPHONE:01454 322888 (CUSTOMER SERVICES) EMAIL: techsupport@matki.co.uk
0947AF 05/19
Advertisement
Summary of Contents for Matki MATKI ONE MOPR Series
- Page 1 MOPR - RECESS INLINE PIVOT INSTALLATION PARTS LIST Please pass the Guarantee Card to the customer. Matki PLC, Churchward Road, Yate, Bristol BS37 5PL MATKI PLC, CHURCHWARD ROAD, YATE, BRISTOL, BS37 5PL EN 14428:2008+A1 TELEPHONE:01454 322888 (CUSTOMER SERVICES) EMAIL: techsupport@matki.co.uk 0947AF 05/19...
-
Page 2: Tools Required
TOOLS REQUIRED IMPORTANT Masonry Drill bit 6mm, Tape Measure, Screw Drivers, Safety Glasses, Electric Drill, Level, Pencil, Adjustable Spanners, Non Slip Gloves, 2mm/3mm/4mm Allen Keys Before disposing of carton and/or commencing assembly, please check all the parts to ascertain that none are missing and they are all undamaged No claim for missing/damaged parts will be accepted once the packing carton has been disposed of and/or assembly has commenced. -
Page 3: Top View
STAGE 1 TOP VIEW FIXED PANEL WALL MOUNT THRESHOLD WALL MOUNT 2.5mm THRESHOLD ADJUSTER THRESHOLD PIVOT POINT (IMAGE SHOWS A LH PIVOTING DOOR. ROTATE THRESHOLD BY 180° FOR RH PIVOTING DOOR) Ø6 This stage is describing the fitting of the Fixed panel wall mounts Before fitting the enclosure please check that your product will fit the finished aperture size.(See dimensions) Remove and set aside the threshold cover from the horizontal threshold. - Page 4 FOR BOTH PANELS STAGE 2 OUTSIDE FACE SOAPY WATER SOAPY WATER WALL MOUNT GLASS GUARD This stage is describing the fitting of both fixed panels. Before fitting the fixed glass panels adjust the threshold extrusion so that it is equally positioned between the two wall mounts. Loosen the threshold adjusters at each end and lightly tighten in position as required.
- Page 5 IMPORTANT STAGE 3 THIS IMAGE SHOWS THE ASSEMBLY OF THE HEADRAIL FOR A LH DOOR. ROTATE HEADRAIL 180° FOR RH DOOR. This stage is describing the fitting of the Top Track. . Loosen the fixings in the headrail adjusters to allow the adjusters to move freely in and out. Lower the top track into position, ensuring the tongues on the headrail adjusters fit down into the back of the wall mounts.
- Page 6 STAGE 4 HANDLE GROOVES ON UNDERSIDE This stage is describing the fitting of the Door. . Lift the door and carefully guide the lower pivot block pin into the pivot block fitted to the threshold track. From behind guide the upper pivot block pin fixed to the headrail into the cup in the pivot block fitted to the top of the door. .
- Page 7 IN/OUTWARD OPENING DOOR SEAL (DOOR SHOWN IN OUTWARD OPEN POSITION) STAGE 5 DOOR ADJUST FIXED CLOSURE PANEL PANEL UNLOCK IMPORTANT LOCK This stage is describing the Door adjustment. Fit the door closure seal to the back of the door. The door closure seal can be adjusted away from the edge of the door to improve sealing with the fixed panel or the fixed panel can be adjusted at the top to the seal.
- Page 8 STAGE 6 SLOPE INWARDS SLOPE INWARDS INSIDE This stage is describing the fitting of the covers and caps. . Apply a continuous bead of silicon all around the inside of the troughs in the threshold track between the edge of the fixed panel and the lower pivot block and between the other side of the lower pivot block and edge of the closure fixed panel, as shown above.
- Page 9 STAGE 7 DOOR MAGNETIC SEAL (FACTORY FITTED) INSIDE VIEW This stage is describing the final fitting of the Seals and Silicon Fit the door horizontal seals to the bottom of the door, ensuring that the ends of the seal are firmly pressed up against the side of the lower pivot block on both sides.
-
Page 10: Parts List
PARTS LIST... - Page 11 MATKI ONE RECESS INLINE PIVOT 0947 AF INSTALLATION INSTRUCTIONS MATKI ONE PIVOT KIT OF PARTS 7364 A SILVER (7373 BRASS / 7373 COPPER) MATKI ONE PIVOT DISK KIT OF PARTS 7372 AF (SILVER/BLUE/GREEN/RED/GOLD/COPPER/BRASS (DETAIL PACK) WHITE/BLACK) DIN 557 -M6 SQUARE NUT ST.ST DIN 916 M4 X 5 SOCKET SET SCREW ST.ST...
