AXNER Power Arm Assembly Instructions

Axner Power Arm: Assembly Instructions
Clamping Bar
Jigger Arm
w/ Handle
Axner Wheel Bracket
(sold separately)
Upright
Adjusting
Bar
Slide the Spring Nuts into your Axner Wheel Bracket
1)
Use the two Flange Bolts to install the Upright Adjusting Bar. Align
2)
the Bar with the center of your wheel head before tightening the
Bolts (images B and
D
490 Kane Ct., Oviedo FL 32765 | P.O. Box 621484, Oviedo FL 32762
Pivot Knuckle
Handle Nut
A
C).
F
E
800-843-7057 or 407-365-2600 | www.axner.com
Axner is a trade name of Laguna Clay Company.

Parts Included:

Jigger Arm Hardware
(1) Clamping Bar
(1) Jigger Arm w/ Pivot Knuckle
(1) Upright Adjusting Bar
Mounting Hardware
(2) 5/16" Washers
(2) 3/8" Spring Nuts
(1) Handle Nut
(2) 3/8" x 2 1/4" Flange Bolts
(2) 5/16" x 2" Hex-Head Bolts
B
(image A).
Insert the Jigger Arm's Pivot
3)
Knuckle into the Upright Bar
(images D and E).
Secure the Jigger Arm with
4)
the Handle Nut (image
Note: The Jigger Arm
should be set to pivot
up-and-down for jiggering
(image G) or side--to-side
for centering (image
G
F).
H
H).
Page 1 of 2
C
OR
