- Page 1 (NPVD) S ETWORK UBLIC ISPLAY YSTEMS NPVDxxA Series N S T A L L A T I O N A N D P E R A T I N G N S T R U C T I O N S W W W A I G I S M E C H C O M...
-
Page 2: Important Safeguards
I M PORTANT SAFEG UAR DS ATTENTION – Observe Precautions For Handling Electrostatic Sensitive Devices Read Instructions - All the safety and operating instructions should be read before the unit is operated. What is Electrostatic Discharge? Retain Instructions - The safety and operating instructions should be retained for A transfer of electrostatic charges between bodies at future reference. - Page 3 This Instruction Book 2. SERVICE If the unit needs repair service or parts, contact Aigis Mechtronics for authorization to return as well as shipping instructions. 3. DESCRIPTION All NPVD models include a high resolution LCD screen with remote and on-screen display and operate on 110VAC/60Hz input voltage.
- Page 4 NPVD SPECIFICATIONS LCD Panel NPVD26 NPVD32 NPVD37 Resolution 1366H x 768V Pixels WXGA Pixel Pitch 0.1405mm x 0.4215mm 0.170mm x 0.510mm 0.200mm x 0.600mm 600 cd/m 2 Brightness Contrast Ratio 1400 : 1 1600 : 1 Viewing Angle 178 / 178 U/D/L/R Color Depth 8bit / 16.7M Colors Response Time...
-
Page 5: Camera Specifications
NPVD SPECIFICATIONS (continued) Camera Specifications Camera Type Color Hi-Res Wide Dynamic Image Sensor 1/3" Sony Super HAD CCD 1/3" Pixim DPS Sensor Signal System NTSC NTSC Effective Pixels 768 (H) x 494 (V) 720 (H) x 480 (V) Resolution 540TVL Mimimum Illumin 0.1Lux/F1.2 0.5Lux/F1.2;0.08... -
Page 6: Installation
4. INSTALLATION Attention: Installations should be performed by qualified service personnel only in accordance with the National Electrical Code or applicable local codes. 4.1 Mounting For specific directions on mounting the Monitor see the Instruction Book that came with your mount. Use eight (8) #10-24 screws when mounting the NPVD unit to your mount. -
Page 7: Video Connections
4.3 Video Connections Connect the external video source to the cable “Video In”. If you wish to run the video back out to a monitoring station, attach the “Video Out” connector to the input of your external monitor. See Figure 1b for connector locations. Internal Camera Out (n/a for No Camera models) Network Cable... - Page 8 Note: This procedure must be completed during installation to enable the remote content management feature. 1. Log in to the customer website using the provided login details. If the customer did not supply the installer with the necessary details, contact Aigis Mechtronics for instructions. See Figure 2 Figure 2: Log in Screen 2.
- Page 9 3. Under 'Select group of signage', pick the directory that the sign is to be placed in. 4. For 'Number of Signage', select the number of signs that are going to be programmed with this particular setup (similar folder locations, default playlist, and default image). This will be 'one' most of the time. 5.
-
Page 10: Using The Menus
5. USING THE MENUS OVERVIEW On Screen Display Menus Menu Description Use this menu to directly access the video input Press SEL to enter and for the Main Video input of the on screen display. exit the menu. Best used to bypass the PVD menu for MENU confirmation of video input selected during setup. - Page 11 5.2 Using the SEL Menu Main Source ☞ When no menus are open on the screen, pressing the CARD STOP SEL button will bring up the menu shown MENU EXIT This menu allows the user to select the input to be shown on- screen, and can act as an override to the PVD Menu (described in the following section).
- Page 12 5.4 Using the Main Video Setup Menu ☞ A I N I D E O E T U P Access the menu by pressing the PVD button. I D E O O U R C E Press the to choose Main Video Setup. CARD ↓...
- Page 13 5.5 Using the Motion Sensor Setup Menu ☞ O T I O N E N S O R E T U P Access the menu by pressing the PVD button. I D E O O U R C E Press the to choose Motion Sensor Setup.
- Page 14 5.6 Using the Light Sensor Setup Menu I G H T E N S O R E T U P ☞ Access the menu by pressing the PVD button. I D E O O U R C E Press the to choose Light Sensor Setup.
- Page 15 5.7 Using the Switcher Video Setup Menu ☞ Access the menu by pressing the PVD button. W I T C H E R I D E O E T U P Press the to choose Switcher Video Setup. ↓ CARD I D E O O U R C E Press SEL.
- Page 16 5.8 Using the Advanced Setup Menu ☞ Access the menu by pressing the PVD button. Press the to choose Advanced Setup. CARD ↓ D V A N C E D E T U P STOP MENU Press SEL. A C T O R Y E F A U L T EXIT L I P...
- Page 17 5.9 Using the MON Menu Note: It is recommended that NO changes be made to the MON Set Up Menu as they may conflict with the NPVD’s preconfigured circuit board programming. ☞ Access the menu by pressing the MON button. →...
-
Page 18: Monitor Control Buttons
5.9.1 Monitor Control Buttons Note: It is recommended that Monitor Settings should be adjusted by using the Remote Control On Screen Display Menus, see 5.9 Using the MON Menu, not by using the Monitor Control Buttons. Adjustments to the Monitor Settings may be made by navigating through the menus and sub-menus with the buttons. See section 5.9 Using the MON Menu for menu details. -
Page 19: Motion Detection
MOTION DETECTION 6.1 Adjust the Motion Sensor Orientation 1. To make any needed adjustments to the Motion Sensor (PIR) access the back panel of the NPVD by unscrewing the two thumb screws. 2. The motion sensor is located to the far left side of the panel as you are facing the back of the NPVD. See Figure 6. Adjustment Wheel Steering Yoke for adjustment. - Page 20 6.1.1 Motion Sensor Field of View in Meters Field of View in Meters Top View Side View...
- Page 21 INTERNAL CONTROL BOARD 7.1 Control Board Configurations and Option Switches The Control Board is a microprocessor-based circuit that controls the on-board sensors and the video switcher. The main purpose of this switcher is to select the Main Video settings to be displayed on screen and then switch the video to either Light Sensor, Motion Sensor or Switcher Video settings.
-
Page 22: Camera Adjustments
CAMERA ADJUSTMENTS 8.1 Color Camera Adjustments Refer to the following sections to setup the camera for operation. The camera module position can be adjusted both vertically and horizontally and can also be rotated for proper tilt orientation. for the correct camera series adjustment points. Figures 7 Pivot Point Pivot Point... - Page 23 IMENSIONAL UTLINES NPVD 26” 13.0 25.98 25.98 18.91 15.91 26" CrystalVue No Camera 25.88 3.25 25.88 3.25 NPVD 32” 27.5 27.5 12.8 15.4 25.2 15.4 32" 32" 21.5 19.0 32" CrystalVue No Camera 30.3 30.3...
- Page 24 2010 Aigis Mechtronics 100 0250 001 AIG 01/10 1124 Louise Road Winston-Salem, NC 27107-5450 Tel: 336.785.7740 Fax: 336.785.7744 Draft Printed in U.S.A. Data subject to change without notice.
