Summary of Contents for JDW ZQ558
- Page 1 ZQ558 04102018 3.6V Grass Shearer Instruction Manual Model Ref: ZQ558...
-
Page 2: Table Of Contents
INTRODUCTION Thank you for choosing this 3.6V Cordless Shearer. This product is manufactured to the highest standards of performance and safety. Before use, please read this manual carefully. It gives important instructions about safety, use and maintenance of your device. Remove all packaging material. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING - Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. -
Page 4: Personal Safety
- When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. - If operating a power tool in a damp location is unavoidable, use a residual current device (RCD with a tripping current of 30 mA or less) protected supply. - Page 5 - Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. - If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 6 Service - Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Battery/Battery charger safety warnings - Protect the battery charger from rain and moisture. The penetration of water in a battery charger increases the risk of electric shock.
-
Page 7: Special Safety Instructions
- Protect the battery against heat, e.g., including against continuous sun irradiation and fire. There is a danger of explosion. - Do not short-circuit the battery. There is a danger of explosion. - In case of damage and improper use of the battery, vapours may be emitted. -
Page 8: Product Overview
PRODUCT OVERVIEW Operating Controls 1 Blade 2 Button for battery power status display 3 Charger LED-indicator 4 Safety lock 5 Handle 6 On/Off switch 7 SDS drive cover 8 Battery charger 9 SDS drive cover release button... -
Page 9: Using The Shearer
STARTING THE MACHINE WARNING! Only use this machine for applications that will not cause harm or damage to the user or the product. Starting: Push in safety lock 4 and press On/Off switch 6 at the same time, Release safety lock 4. Stopping: Release the On/Off switch 6. - Page 10 Changing the blade Wear gloves when changing the blade. Removing - Push the SDS-blade cover release button 9 and slide the cover 7 towards the On/Off switch 6. Lift away from the housing. - Lift the blade 1 out. Fitting - Fit the blade as shown aligning the holes in the blade onto the drive pins.
- Page 11 Blade Maintenance - Always clean the cutting blades after operation and lubricate with Bosch Maintenance spray. - Visually check the condition of the cutting edges of the cutting blade 1. - Ensure that the blade is covered with the blade guard supplied when not in use.
-
Page 12: Specification
SPECIFICATION Rated voltage DC 7.2 V DC 3.6 V No load speed 1000/min Hedge trimmer cutting length 110 mm Grass shear cutting width 70 mm Declaration of the noise emission values for hedge trimmer according to EN 60745-1 and EN 60745-2-15 A-weighted sound pressure level 68dB(A) 67dB(A) - Page 13 Declaration of the vibration emission of hedge trimmer accord- ing to EN 60745-1 and EN 60745-2-15 3.7 m/s2 2.3 m/s2 Uncertainty K 1.5 m/s2 1.5 m/s2 Declaration of the vibration emission of grass shear according to EN 60335-1 and FprEN 60335-2-94 2,91 m/s2 2,845 m/ Weight [kg]...
- Page 14 DISPOSAL INFORMATION Power tools, accessories and packaging should be sorted for environmentally-friendly recycling. Only for EC countries: Do not dispose of power tools into household waste! According to the European Directive 2002/96/EC on waste electrical and electronic equipment and its incorporation into national law, products that are no longer suitable for use must be separately collected and sent for recovery in an environmentally-friendly manner.
- Page 15 JD Williams Ltd. Manchester, UK, M60 6ES M606ESO1...
