Summary of Contents for Domi Jump TRAMPOLINE BASKETBALL HOOP
- Page 1 DOMIJUMP TRAMPOLINE BASKETBALL HOOP Installation Manual & Safety Instructions Domi Jump. Inc, Shaoxing,Zhejiang, China Tel: 0086 137 7732 3951. E: lisa@domijump.com...
- Page 2 WARNING: Read these installation instructions carefully before attempting to assemble or use this product. Keep this guide in a safe place for future reference. Got a problem building your basketball hoop? Call us on 0044 1276 855600 and we can help. Contents Warning Page 2...
- Page 3 Tools and Parts List Tools: Installation of the Capital Trampoline Basketball Hoop requires a 10mm spanner, a 13mm spanner and a pair of scissors. These are not provided. You will also need a second person to assist. This person will hold the backboard in place whilst the first person attaches the backboard to the trampoline enclosure pole.
- Page 4 FITTINGS LIST Code Description Where Used Bolt M8 12mm To fix flat plate onto backboard For flat plate (2) & spring through M8 Washer bolt (1) Bolt M5 x 75mm To attach hoop to connection plate Nut M5 To attach hoop to connection plate Spring Through To fix springs to connection plate Bolt M8 x 100mm...
- Page 5 ASSEMBLY Attach the Flat Plate D to Backboard A using 2 x M8 Bolts 1 and 2 x Washers M8 M-2. Attach the Velcro Net C onto the Ring B as shown. Connect the Ring B with Connection Plate E using the M5 Bolt 3 through the joint and locked with M5 Nut L-3 When you insert the M5 Bolt, it can be a difficult to tighten the M5 Nut onto the bolt.
- Page 6 ASSEMBLY Then attach the Ring B onto the front of the backboard by using three M6 Bolts 2 and six M6 Washers M-1. Then fit the two Springs F and G using M8 Bolt 4 with one M8 Nuts L2 and one M8 Washers M-2.
- Page 7 ASSEMBLY The Capital Basket Ball Hoop will work with most shaped enclosure poles and net systems. Select Instructions A, B or C below depending on the type of enclosure pole you have and whether you have a rod round around the top of your net. Note: You will need two people for the following final assembly, one standing inside the trampoline holding the backboard in place and the second person on the outside of the trampoline (using a step-ladder or similar) fixing the brackets, nuts and bolts.
- Page 8 B – Straight Enclosure Pole with a Top Rod Insert and tighten four Medium Threaded M8 Rods 6 into the top and bottom Flat Plate bolts. Then from the inside of the trampoline push through the holes you have cut into the net. Firstly on the bottom rods screw down two M8 Nut with Flange L-4 with the nut end facing the backboard and then attach a Bracket 9 through...
