Summary of Contents for Noon N100
- Page 1 Installation Guide...
-
Page 2: Before You Get Started
Before you get started If you’ve installed light switches before and are comfortable with high voltage wiring, installing a Noon™ switch is easy. If not, we highly recommend hiring a professional installer. Guided installation Get a pro If you would like to be guided... - Page 3 This guide is for experienced DIYers and installers Get additional help at noonhome.com/install.
- Page 4 3-Switch wall plate & mounting plate* Wire strippers Wall screws (x6) Cleaning cloth Base (x3) * Noon Wall Plates and mounting plates are recommended, but not required. Noon switches work with popular ™ third-party wall plates. You can purchase additional Noon Wall Plates at noonhome.com/store.
-
Page 5: Need To Know
• All residential bulbs including: LED, incandescent, halogen, fluorescent and CFL bulbs; MLV and ELV fixtures • Multi-way configurations support up to four switches per circuit. Requires all Noon switches on the multi-way circuit. • Dimmable and non-dimmable bulbs • Designed for indoor use only Rated for the following limits, per switch •... - Page 6 Are you replacing a single-pole or multi-way switch? Single-pole switch CONTINUE One light switch that controls a light or set of lights. Multi-way switch STOP Two or more light switches that control the same light or set of lights. Turn to page 11.
- Page 7 We recommend you apply the labels before detaching the wires from the old switch. Ground and neutral wires are required. If you do not have ground and neutral wires, the Noon switch is not compatible. Contact us at noonhome.com/contact to learn about your options.
- Page 8 Install Noon ™ 1. Install the Noon mounting plate 2. Hang the Noon Base from the mounting plate Make sure the hooks are facing out and upwards. To free up your hands for Look for the “Top” indicator. wiring, hang the Noon Base...
- Page 9 Repeat previous steps for any other switches in this box. 6. Turn the Noon switch ON before installation 7. Install Noon switch into the base Install any other Noon switches you have for this Remove the sticker on room before continuing.
-
Page 10: Check Installation
Check installation 1. Turn power on at the circuit breaker 2. Click switch to turn lights on and off If lights do not turn on or off, visit noonhome.com/troubleshoot for help. - Page 11 You’re done with installation. Use the Noon App to complete setup. You can download the Noon App on your iOS or Android device.
- Page 12 Installing a multi-way switch Noon switches can replace ™ multi-way switches. Noon supports up to four switches controlling the same light. All of the switches on a multi-way need to be replaced. For full multi-way installation instructions, go to noonhome.com/multiway.
- Page 13 Multi-way wiring diagram Noon switches work as 3-way or 4-way switches. They are wired in parallel. Ground and neutral wires are required. Use the multi-way wall stickers and wire labels in the box. Traveller Traveller Traveller Traveller...
- Page 14 Resources For guided installation, visit noonhome.com/install. To book a Noon-trained installer, visit noonhome.com/installers. For help troubleshooting your install, visit noonhome.com/troubleshoot.
-
Page 15: Warranty
(4) Consult the dealer or an experienced radio/TV technician for help. Model numbers: Noon Room Director (N100), Noon Extension Switch (N130), Base (N190), Noon wall plate (Wall Plate) This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
