Installation and Replacement
This document contains technical specifications and operating limits for
the DS-F20P-10GigE switch. It also includes procedures for installing
and replacing the switch in a standard-depth (20.5 inches to 34 inches)
19-inch NEMA cabinet and in a 44U InfiniFlex
Topics include:
Technical specifications ....................................................................... 2
Operating limits.................................................................................... 4
Handling FRUs ..................................................................................... 5
Replacing the switch in an InfiniFlex cabinet................................. 13
DS-F20P-10GigE
Guide
P/N 300-006-884 Rev A01
June 2, 2008
™
cabinet.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DS-F20P-10GigE and is the answer not in the manual?

Questions and answers

Related Manuals for EMC2 DS-F20P-10GigE

Summary of Contents for EMC2 DS-F20P-10GigE

  • Page 1: Table Of Contents

    P/N 300-006-884 Rev A01 June 2, 2008 This document contains technical specifications and operating limits for the DS-F20P-10GigE switch. It also includes procedures for installing and replacing the switch in a standard-depth (20.5 inches to 34 inches) ™ 19-inch NEMA cabinet and in a 44U InfiniFlex cabinet.

  • Page 2: Technical Specifications

    264 VAC) 10.2A MAX (Turn on at the 90 deg. phase of 240 VAC) AC inlet type IEC (std. universal 3 prong male) Ride-through time 20ms min Current sharing +-5% (at maximum load) DS-F20P-10GigE Installation and Replacement Guide...
  • Page 3 Fujitsu 10 Gbe physical dimensions Table 2 Measurement Specifications Height 43.8 mm (1.72 inches) Width 440 mm (17.3 inches) Depth 480 mm (18.9 inches) Weight 14 kg (30.9 pounds) DS-F20P-10GigE Installation and Replacement Guide...

  • Page 4: Operating Limits

    20-80%, non-condensing Elevation 10,000 ft (3,048m) Ventilation AC cord to 10 Gbe cables Shipping and storage requirements Shipping and storage requirements Table 4 Requirement Description Ambient temperature 0-50°C Relative humidity 8-80% Elevation 25,000 ft (7,622m) DS-F20P-10GigE Installation and Replacement Guide...

  • Page 5: Handling Frus

    5. Use the ESD kit when handling any FRU. If an emergency arises and the ESD kit is not available, follow the procedures in the Emergency procedures (without an ESD kit) section. DS-F20P-10GigE Installation and Replacement Guide...
  • Page 6 4. If you must move around the room or touch other surfaces before installing a FRU, first place the FRU back in the antistatic bag. When you are ready again to install the FRU, repeat these procedures. DS-F20P-10GigE Installation and Replacement Guide...

  • Page 7: Installing The Switch In A Standard-Depth Cabinet

    Installing the switch in a standard-depth cabinet Installing the switch in a standard-depth cabinet This section describes how to install/replace a DS-F20P-10GigE switch in cabinets that conform to the National Electrical Manufacturer’s Association (NEMA) standards for 19-inch cabinets (where the left and right mounting channels are 19 inches apart) with a depth of 20.5 inches to 34 inches.
  • Page 8 Remove any filler panel, then use a flat-blade screwdriver or similar tool to pry off the latch brackets. Figure 1 shows how to remove a common filler panel and latch bracket. DS-F20P-10GigE Installation and Replacement Guide...
  • Page 9 1. Locate the left and right slide rails that shipped with your switch. 2. Attach the left and right slide rails to the switch with two screws, as shown in Figure Front CL3988 Figure 2 Attach the slide rails to the switch DS-F20P-10GigE Installation and Replacement Guide...
  • Page 10 4. Repeat steps 2 and 3 on the left side, with the left rail (Figure 5. From the rear of the cabinet, use two of the provided screws to secure each rail to the rear channel. Tighten the screws. DS-F20P-10GigE Installation and Replacement Guide...
  • Page 11 1. Use one screw to secure a latch bracket to each front channel. (The brackets include small alignment bumps to correctly orient them to the channel.) Figure 5 shows a secured latch bracket. 2. Press the bezel onto the latch brackets until it snaps into place (Figure DS-F20P-10GigE Installation and Replacement Guide...
  • Page 12 Installing the switch in a standard-depth cabinet Bezel latch bracket Bezel latch bracket CL3905 Installing the latch bracket and bezel Figure 5 DS-F20P-10GigE Installation and Replacement Guide...

  • Page 13: Replacing The Switch In An Infiniflex Cabinet

    1. Using a Phillips-head screwdriver, loosen the two captive screws located on the front of the rails (Figure 2. Remove the switch and the AC power cord from the cabinet (Figure 6). Set the AC power cord aside for reinstallation later. DS-F20P-10GigE Installation and Replacement Guide...
  • Page 14 You must attach the rails that came with your replacement switch before you can install the switch in the cabinet. 1. Using two screws on each side, attach the rails to the switch (Figure Front CL3932 Figure 7 Attaching the rails to the switch DS-F20P-10GigE Installation and Replacement Guide...
  • Page 15 Restoring power to the replaced part 1. Reconnect the AC power cords to both the front of the switch and to the PDU at the rear of the system. 2. Reattach the LAN cables to the switch. DS-F20P-10GigE Installation and Replacement Guide...
  • Page 16 For the most up-to-date regulatory document for your produce line, go to the Technical Documentation and Advisories section on EMC Powerlink. For the most up-to-date listing of EMC product names, see EMC Corporation Trademarks on EMC.com. DS-F20P-10GigE Installation and Replacement Guide...
