STEP ONE
Slide two FASTwall panels together to create
one unit.
STEP TWO
Align desired width of bases in a row, with white
feet facing the ground. Be sure that the handle
holes are all aligned to the back of the FASTwall.
When aligning bases, place one more base that the
width of the FASTwall.
i.e. 5 units wide = 6 bases,
7 units wide = 8 bases, etc.
STEP THREE
Insert C3 connectors into middle holes as
illlustrated. Connect FASTwall bases using
F2 connectors.
NOTE:
If building FASTwall Columns, connect FASTwall panels using F2 connectors as shown.
Questions about ATOMIC products? Give us a ring! 717-626-4408
RENTAL
SOLUTIONS
www.atomicdesign.tv
FASTWALL
INSTALLATION INSTRUCTIONS
Page 1 of 3
Advertisement
Table of Contents
Summary of Contents for Atomic FASTWALL
- Page 1 Insert C3 connectors into middle holes as illlustrated. Connect FASTwall bases using F2 connectors. NOTE: If building FASTwall Columns, connect FASTwall panels using F2 connectors as shown. Questions about ATOMIC products? Give us a ring! 717-626-4408 www.atomicdesign.tv Page 1 of 3...
- Page 2 NOTE: Connecting C4 connectors to each riser as it is placed makes the following steps easier. If adding interior lighting to FASTwall, place lights inside risers at this point. STEP FIVE Use C4 connector and F2 connector on each end to continue assembling FASTwall.
- Page 3 INSTRUCTIONS: FASTwall MUST be disassembled from top down, in reverse order as the assembly process. Removal of bottom panels first may result in a toppling wall. Questions about ATOMIC products? Give us a ring! 717-626-4408 www.atomicdesign.tv Page 3 of 3...
