Slootsmid SZB STANDARD User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User guide
SZB STANDARD AND SZB PROFI
Slootsmid Mesttechniek B.V.
KORENBREE 40-A | 7271 LH| BORCULO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SZB STANDARD and is the answer not in the manual?

Questions and answers

Summary of Contents for Slootsmid SZB STANDARD

  • Page 1 User guide SZB STANDARD AND SZB PROFI Slootsmid Mesttechniek B.V. KORENBREE 40-A | 7271 LH| BORCULO...
  • Page 2 Congratulations! You are now the owner of a Slootsmid SZB slurry injector. We believe that you made a good choice by buying a Slootsmid fertilizer. We are confident that you will be with this slurry injector, under normal use and well maintained, a satisfied user for many years.
  • Page 3 EC-DECLARATION OF CONFORMITY FOR MACHINERY Machinery Directive 2006/42/EG, Annex II.1.B Manufacturer : Slootsmid Mesttechniek B.V. Address : Korenbree 40-A, 7271 LH, Borculo (the Netherlands.) Certify that: The Slootsmid SZB slurry injector, Serial number : ________________________________* Year : ________________________________* Delivery date : ________________________________* Meets the requirements of the Machinery Directive ( Directive 2006/42 / EC , as amended ) ;...

  • Page 4: Table Of Contents

    Index 1. INTRODUCTION ............................4 1.1 D ..............................4 ISCLAIMER 1.2 G ................................4 ENERAL 1.4 T ............................4 ERMS OF GUARANTEE 1.5 C .............................. 5 HECK AT RECEIVE 1.6 O ............................5 RDERING SPARE PARTS 2. SAFETY ................................. 6 2.1 G ............................

  • Page 5: Introduction

    Slootsmid accepts no liability for any damages arising from the use of this manual in relation to any goods delivered or possibly to deliver machines, except in the case of intent or gross negligence on the part of Slootsmid.

  • Page 6: Check At Receive

    Check the shipment by receive and make sure it is in accordance with what was ordered by you and check the machine for completeness and damage. Do not use the machine if it is damaged, please contact your Slootsmid dealer or forwarding company. 1.6 Ordering spare parts For a correct and rapid processing for the supply of spare parts.

  • Page 7: Safety

    • Replace safety symbols / icons and/or information labels if they are unreadable by exactly the same models, available at your Slootsmid dealer. • Make sure you are familiar with all functions of the machine before you start working with the machine.

  • Page 8: Safety Instructions Regarding To Machine Operations

    Do not operate the machine if you are tired. • Use only genuine Slootsmid attachments and make sure they are installed properly. • Ensure that no body parts are on or between moving parts. It is a risk that parts of the body shall be crushed or cut off.

  • Page 9: Safety Stickers

    2.6 Safety stickers The safety stickers affixed to the machine or tanker give regarding a safe operation very important instructions. Following these instructions is very important and is for your own safety. Damaged labels must be replaced! Meaning Position Sticker Read before use first the instruction manual and safety rules and follow the...

  • Page 10: Place From Safety Stickers On The Machine

    2.7 Place from safety stickers on the machine. * Sticker C may be disposed at the bottom side, so that it is visible in the folded position.

  • Page 11: Description

    When folding the arms, the hooks of the unfold security locks automatically. At the SZB Standard the unfold security should be done manually by means of a pin-hole connection. In addition to transportation there must be applied a disc security.

  • Page 12: Product Identification

    3.4 Product identification SZB Standard Mid-frame Folding arms Disc security Support wheel Hydraulic motor distributor Connection supply hose. Distributor Pin-hole connection unfold security Fold cylinder 10. Pin-hole connection unfold security 11. Light beam 12. Element...
  • Page 13 SZB Profi 1. Mid-frame 2. Disc security 3. Folding arms 4. Collapsible end piece (SZB 865 ,940 and 1010) 5. Fold cylinder 6. Distributor 7. Element 8. Fold cylinder end piece 9. Hydraulic unfold security 10. Light beam...

  • Page 14: Machine Attach And Detach

    4. Machine attach and detach In the case of a vacuum tank mount the dosing set on the divider and the fine pressure regulator on the pump, in order to keep the pressure in the tank steady. 4.1 Attaching after a tanker or self-propelled machine. Make sure that the slurry injector is standing stable.
  • Page 15 4.2 Connecting the hydraulics Connect the hoses from the hydraulic operation using the quick connect fittings to the connector plate of the tanker or tractor: • 3x hoses distributor (Leak pipe must be connector on the pressure free return, otherwise the warranty on the hydraulic motor will void!) •...

  • Page 16: Utilize

    7. The fold arms must be horizontal in working position. At the SZB profi this can be adjusted by adapting the stop blocks under the hinges and rotating the ball joints of the folding cylinders. 8. At the SZB standard there is no possibility to adjust the working position. Standing folding arms horizontal is OK 9.

  • Page 17: Adjusting The Slurry Injector

    6. Adjusting the slurry injector 6.1 Mechanical ground pressure adjustment (standard) Adjust spring pressure to mechanical ground pressure. By moving the spring in the direction shown, the ground pressure will be adjust. Higher ground pressure Mechanical ground pressure 6.2 Hydraulic ground pressure adjustment (optional) Setting the ground pressure is divided into 3 sections (left, center and right).

  • Page 18: Mechanical Coulter Closure

    6.3 Mechanical coulter closure. The SZB Profi and SZB Standard versions comes standard with mechanical coulter closing. When the working position is reached, the valves will be opened automatically. When lifting the machine, the rubber slurry outlets will be automatically closed by the steel wire.

  • Page 19: Setting The Speed Of Unfolding The Arms

    6.5 Setting the speed of unfolding the arms. The speed of the fold and unfolding can be set. Left and right cylinder must be set separately. Adjustment of the cartridges is a very precise work. Inquire at your dealer or Slootsmid for the proper adjustment.
  • Page 20 Adjusting 2nd arm unfolding, screwing the cartridge in is more throttling.

  • Page 21: Maintenance

    6. Maintenance With regular use - Daily cleaning the distributor - Lubricate weekly all grease point on the machine. - Check before every ride on public roads reflectors and lights. - Daily lubricate the hub of the distributor. Before placing the machine in storage - Clean the distributor, greasing and clean the aeration valves.

  • Page 22: Lubrication Map

    6.1 Lubrication map • Optional central lubrication can be provided. Lubrication map SZB Standard Greasing point cylinder Greasing point cylinder Greasing point folding arm...
  • Page 23 Lubrication map SZB Profi Greasing point folding cylinder Greasing point folding cylinder Greasing point cylinder Greasing point cylinder Greasing point hinge Greasing point hinge Greasing point hinge end piece end piece Folding arms...

  • Page 24: Distributor

    7. Distributor There are multiple types of distributors available on the SZB Standard and Profi models. Slootsmid usually provides one of the following types of distributors. For information, consult the manual of the relevant distributor. Horizontal eccentric distributor Horizontal rotor distributor...

  • Page 25: Failure

    Coulter closing will not open. • With mechanical coulter closing increase the ground pressure so that the elements come more into working position and the steel wires relaxes. Failures are not in this Guide. Consult your supplier! Or contact Slootsmid 0031 (0)545-273859 (Option 5)

  • Page 26: Technical Data

    9. Technical data Model SZB 580 SZB 650 SZB 720 Standard Standard Standard Working width 5.76 m. 6.48 m. 7.20 m. Transport width 2.75 m. 2.75 m. 2.75 m. Transport height** 2.82 m. 3.18 m. 3.54 m. Number of elements Number of disc Weight 1.380 kg.
  • Page 27 Appendix 1: Linkage Three-point linkage SZB Profi Four-point linkage SZB Profi...
  • Page 28 Three- and four-point linkage SZB Standard 4-point 3 point 3 point 3-point...

  • Page 29: Contact

    CONTACT Slootsmid Mesttechniek B.V. Korenbree 40-A 7271 LH Borculo (The Netherlands) Telephone: +31 (0)545-745 090 E-mail: info@slootsmid.com Internet: www.slootsmid.com...
