CRU BTI-UNI Manual

Hide thumbs
1
2

Advertisement

Table of Contents

- Illuminated 3-key wired remote control for easy access to functions.
- Voice dial function (voice tags) on compatible phones.
- Automatic radio mute function when call is received (if radio has this feature).
- Capable of pairing 2 phones at the same time.
BTI-UNI Module
1. Choose an easily accessible location to mount the illuminated remote control on the dashboard.
2. Use a cleaning cloth to remove grease or dirt from the surface and attach the remote control.
3. Run the microphone cable towards a suitable location for the mic. We recommend installing it at the A
pillar or on the sun visor.
4. Run the cable to where the BTI-UNI module will be installed. It can be mounted behind the radio or
behind the glove box.
5. Mount the speaker in a suitable location. You can hide it by the passenger footwell.
6. Plug the microphone, speaker and power harness to the module.
7. Connect the power harness as follows: YELLOW (Battery), RED (ACC), BLACK (GROUND), BROWN (Mute).
V
Power Harness
Speaker
Remote Control
1 / 2
Microphone
rev.072518

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTI-UNI and is the answer not in the manual?

Questions and answers

Summary of Contents for CRU BTI-UNI

  • Page 1 3. Run the microphone cable towards a suitable location for the mic. We recommend installing it at the A pillar or on the sun visor. 4. Run the cable to where the BTI-UNI module will be installed. It can be mounted behind the radio or behind the glove box.
  • Page 2 Turn ON Bluetooth function on the first phone. Both phones will now be connected to the BTI-UNI. If a call is received on the first phone that was paired, the BTI-UNI will automatically connect to the first phone. If a call is received on the second phone, the BTI-UNI will automatically connect to the second phone.
