Summary of Contents for FSK HAWK PANIC PACK
- Page 1 HAWK PANIC PACK HAWK TX75X TRANSMITTER TRANSMITTER HAWK HAWK MODIFYING THE TX75X For the SIREN output R31 must be changed to 1k HAWK TX75X 2 HOLES 2,5mm BATTERY 12V 7AH AC IN 220V...
-
Page 2: Wiring Instructions
HAWK PANIC PACK REMOTE CONTROL PROGRAMMING The remote control is factory programmed into the unit Should a remote get lost, delete all the remotes by REMOTE Placing a jumper on the ‘F’orget pins LEARN/ The RED lamp flashes five times... - Page 3 HAWK PANIC PACK 12V DC POWER TRANSMITTER AC FAIL SENSE TO TRANSMITTER FOR SIREN ONLY FOR SIREN ONLY TO TX75X INPUT 7 TO HAWK INPUT 7 NOT USED 12V OUT 200 mA MAXIMUM 12V OUT 200 mA MAXIMUM BATTERY AC FROM...
- Page 4 FIRE PANIC MEDICAL EMERGENCY The remote control can be a 1 Button, 4 Button or 6 Button FSK 433MHz Rolling Code Remote Transmitter. The 1 Button Remote Control will only send a Panic Alarm. On the 4 of 6 Button Remote Controls;...
