.68 CAL SEMI-AUTO PAINTBALL MARKER
OWNERS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KAOS-D and is the answer not in the manual?

Questions and answers

Related Manuals for Azodin KAOS-D

Summary of Contents for Azodin KAOS-D

  • Page 1 ® .68 CAL SEMI-AUTO PAINTBALL MARKER OWNERS MANUAL...

  • Page 2: Table Of Contents

    P. 8-9 ZERO SYSTEM P. 10-11 ASSEMBLY AND CLEANING P. 12-13 REASSEMBLE REAR INTERNALS P. 14 TROUBLESHOOTING P. 15 KAOS-D SCREW CHART P. 16-17 KAOS-D O-RING CHART P. 18-19 ZeRO SYSTEM P. 20 INLINE REGULATOR P. 21 ON/OFF BOTTOM ASA P.

  • Page 3: Safety Instruction And Guidelines

    ! WARNING ! IMPORTANT SAFETY INSTRUCTION AND GUIDELINES • This Paintball Marker is NOT A TOY. Misuse can cause serious injury or death. • Recommend 18 years or older to purchase this product. Person under 18 must have adult supervision. •...
  • Page 4 • Any modifications or tampering of original factory parts will void all warranties and liabilities from Azodin Paintball. • This owner’s manual should always accompany this marker for reference and in the event of resale and new ownership.
  • Page 5 ! WARNING ! IMPORTANT CO2/ HPA AIR TANK SAFETY INSTRUCTION AND GUIDELINES • Tank valves must be installed or removed by qualified personnel. • All tanks must be retested before the expiration date. • Improper use, filling, storage of this air tank may cause death, serious injury and property damage.
  • Page 6 ! WARNING ! IMPORTANT CO2/ HPA AIR TANK SAFETY INSTRUCTION AND GUIDELINES STOP IMMEDIATELY CO2 or HPA/ N2 Air tanks will have enough force to fly off and cause serious injury or death if the valve unscrews from the tank head.

  • Page 7: Getting Started

    GETTING STARTED 1. First, place the BARREL BLOCKING DEVICE over the barrel. ® 2. Always point your marker at a “SAFE” direction before use. To use, push the safety button from the “PUSH SAFE” side of the grip frame. Doing this will put the marker in a lock safe mode. To unlock the safe mode, point the marker in the safe direction, and push the safety button towards the “PUSH SAFE”...
  • Page 8 6. Check marker’s velocity FPS (Feet Per Second). Turning the Velocity Adjuster (P023) clockwise will increase the velocity. Counterclockwise will decrease the velocity. 7. After playing, take out all paintballs from the hopper. Then detach the hopper from the marker. CAUTION: There may be 1-2 paintballs in the breach area;...

  • Page 10: Regulator Adjustment

    REGULATOR ADJUSTMENT (INCREASE & DECREASE AIR PRESSURE) CLOCKWISE DECREASE VELOCITY COUNTERCLOCKWISE INCREASE VELOCITY To increase the input pressure use the allen wrench to turn the Regulator Adjustment Screw (S032) counterclockwise. To decrease the input pressure use the allen wrench to turn the Regulator Adjustment Screw (S032) clockwise.
  • Page 11 NOTE: Regulator is preset at the factory for optimum performance. Fine adjustment of velocity should be done with the velocity adjustor (P023) on page 7. NOTE: Each quarter turn correspond to approximate increase or decrease of 20psi.

  • Page 12: Zero System

    ZeRO SYSTEM INSTRUCTION AND ADJUSTMENT WARNING: Never remove the internal of the marker while the air tank is attached with the marker. ® FOR CO2 OPERATION: NOTE: Zenith is optimized for use with HPA, in order to optimize the Zenith for CO2 use, please follow the instructions below.
  • Page 13 2. To optimize the velocity, make sure the rear velocity adjustment is backed all the way out. Adjust the Inline Regulator (refer to Regulator Adjustment) until the marker is shooting at 250 feet per second over a chronograph. 3. To fine-tune the marker velocity follow the direction on page 9 (refer to Velocity Adjustment) ®...

  • Page 14: Assembly And Cleaning

    ASSEMBLY AND CLEANING PULL THE TOP COCKING KNOB WARNING: Never remove the internals of the marker while the air tank is attached with the marker. Always remove all paintballs, loader and air tank before disassembling the marker.
  • Page 15 CLEANING AND DISASSEMBLE REAR INTERNALS 1. Lift upward on the Top Cocking Knob at the rear of Delrin Bolt. This will let the Delrin Bolt (P041) slide out from the rear of the receiver. 2. Turn the End Cap (A051) counterclockwise.

  • Page 16: Reassemble Rear Internals

    REASSEMBLE REAR INTERNALS 1. Insert the Feather Striker (P021) thru the rear of the receiver with the O-Ring facing towards the front of the marker and with the hole on the Feather Striker facing upright. While inserting the Feather Striker, apply pressure behind the Feather Striker and at the same time pull the Trigger to let Feather Striker enter the rear chamber of the receiver.

  • Page 17: Troubleshooting

    TROUBLESHOOTING WARNING: Always remove all paintballs, loader and air tank before disassembling the marker. RECOCKING ISSUES Need Lubrication on the Striker O-Ring (R011). ® Striker O-Ring is damaged or missing. Replace a correct O-Ring. The pressure in the tank is too low and needed to be refilled. Dirt or broken paintball shell fragments in the receiver.
  • Page 18 PART NUMBER AND NAME KAOS-D SCREW CHART SIZE: 1:1 S011 M5 X 10L MAIN BODY SCREW S012 M8 X 8L VALVE RETAINING SCREW S014 M5 X 16L VERTICAL ASA SCREW S015 M3 X 3L DETENT COVER ASA SCREW S016 M4 X 8L...

  • Page 19: Kaos-D Screw Chart

    PART NUMBER AND NAME KAOS-D SCREW CHART SIZE: 1:1 S032 M12 X 8L REGULATOR ADJUSTMENT SCREW S091 M12 X 8L ON/OFF BOTTOM ASA RETAINING SCREW S092 1/8-27 NPT ON/OFF BOTTOM ASA HOSE PLUG S093 M5 X 12L ON/OFF BOTTOM ASA SCREW...

  • Page 20: Kaos-D O-Ring Chart

    PART NUMBER AND NAME KAOS-D O-RING CHART SIZE: 1:1 R011 STRIKER O-RING (RED) R012 FRONT VALVE O-RING (CLEAR) R013 AZ O-RING (BLACK) R015 AZ O-RING (BLACK) R016 BARREL O-RING (BLACK)
  • Page 21 PART NUMBER AND NAME KAOS-D O-RING CHART SIZE: 1:1 R017 END CAP O-RING (BLACK) R031 REGULATOR PISTON O-RING (CLEAR) R032 REGULATOR SWIVEL MOUNT O-RING (BLACK) R033 INNER O-RING (CLEAR) R034 REGULATOR SEAL O-RING (CLEAR) Z021 ZeRO CUP SEAL O-RING (CLEAR)

  • Page 22: Zero System

    Z001 ZeRO SYSTEM Z031 Z014 ® ZeRO SYSTEM PARTS LIST PART NAME P011 VALVE Z041 Z011 ZeRO CUP SEAL STEM Z012 ZeRO CUP SEAL Z014 ZeRO SPRING R015 Z021 R012 FRONT VALVE O-RING (CLEAR) R015 AZ O-RING Z012 Z021 ZeRO CUP SEAL O-RING Z031 ZeRO ADJUSTMENT...

  • Page 23: Inline Regulator

    A062 INLINE REGULATOR R015 REGULATOR PARTS LIST PART NAME P081 P081 MAIN REGULATOR HOUSING S031 P082 REGULATOR SWIVEL R031 MOUNT P083 REGULATOR P084 END CAP P084 REGULATOR PISTON P085 REGULATOR MAIN P085 SPRING P086 SEAT SEAL CARRIER P082 R015 AZ O-RING R031 REGULATOR PISTON R032...

  • Page 24: On/Off Bottom Asa

    A091 ON/OFF BOTTOM ASA P063 P091 ® A092 R033 S092 A093 S091 ON/OFF BOTTOM ASA PARTS LIST PART NAME P063 90 DEGREE MACROLINE HOSE P091 ON/OFF BOTTOM ASA STEM R033 INNER O-RING S091 ON/OFF BOTTOM ASA RETAINING SCREW S092 ON/OFF BOTTOM ASA HOSE PLUG A092 ON/OFF BOTTOM ASA CAP A093...

  • Page 25: Kaos-D Parts List

    KAOS DELUXE PARTS LIST PART NAME PART NAME P011 VALVE S017 VERTICAL ASA P021 FEATHER STRIKER SCREW P022 FEATHER SPRING S093 ON/OFF BOTTOM P023 VELOCITY ADJUSTER ASA SCREW P024 FEATHER BUMPER P031 BALL DETENT A011 KAOS BODY P032 DETENT COVER A031 VERTICAL ASA P041...
  • Page 26 KAOS DELUXE 2011 EXPLODED VIEW A051 P051 R013 P041 ® P024 R017 P023 A011 R016 S015 R011 P031 P022 A202 P021 P032 P032 P011 S015 P031 S012 S011 R015 Z001 PLEASE REFER TO PAGE 23 A031 FOR DETAIL OF ZeRO SYSTEM S011 S016 S017...
