Unfortunately, our extensive efforts to provide safe equipment can be negated by a single careless act of an operator. In addition to the design and configuration of the 135lb Stainless Steel Spreader, hazard control and accident prevention are also dependent upon the awareness, condition, maintenance, and storage of the Snowrator and all optional attachments.
MAINTENANCE Follow all safety guidelines when performing maintenance on the 135lb Stainless Steel Spreader. In order to ensure the 135lb. Stainless Steel Spreader is kept in optimum condition, perform the following maintenance activities on a regular basis. DO NOT USE WATER WHEN CLEANING HOPPER Daily •...
REV5 135lb Stainless Steel Spreader Installation 3.0 INSTALLATION WARNING Before Working on This Machine • Switch Engine to OFF • Please note that this installation guide is for a standard machine only. • The hose and electrical harness routing may be different depending on the attachments that may already be installed on your machine.
REV5 135lb Stainless Steel Spreader Installation 4.0 INSTALLATION FERTILIZER BOXES 4.1.1 Remove Rear Tires. Raise the machine using a Jack and Jack Stands (not shown). Tools: Remove both Rear Tires. Ratchet with 13/16” Socket 4.1.2 Remove Rear Light Bracket. Remove the two Bolts connecting the Rear Light Bracket to the Frame.
Page 9
REV5 135lb Stainless Steel Spreader Installation Fertilizer Boxes Cont… 4.1.3 Remove Battery Box. Remove battery cover by unhooking strap. Detach the Negative (black) and Positive (red) Wires from battery. Remove bolts that attach the Battery Box Bracket to the Frame.
Page 10
REV5 135lb Stainless Steel Spreader Installation Fertilizer Boxes Cont… 4.1.4 Attach the Right Fert Box Platform Insert (2) 3/8” x 1” Bolt into Footplate Bracket Line up Slot in Fert Box Platform with Bolts Tools: Ratchet with 9/16” Socket Fasten with (2) 3/8” Flange Nuts.
Page 11
REV5 135lb Stainless Steel Spreader Installation Fertilizer Boxes Cont… 4.1.6 Attach the Left Fert Box Platform Insert (2) 3/8” x 1” Bolt into Footplate Bracket Tools: Line up Slot in Fert Box Platform with Bolts Ratchet with 9/16” Socket Fasten with (2) 3/8” Flange Nuts Hand Tighten 4.1.7 Attach Rear Light Bracket...
4.2.1 Mount 135lb Stainless Steel Spreader Drill out the quick-release pin hole on the Mounting Plate of Snowrator Tools: With one person on each side, lift the 135lb Stainless Steel Spreader by the Drill, 3/8” bit Back Shield and the rear of the Hopper.
Page 13
REV5 135lb Stainless Steel Spreader Installation Mount Spreader Cont... Rest the rear of base on the Mounting plate with the front at a slightly elevated angle. Slide the Hopper Hinge Rods down into the rear Mounting Plate hooks. Set the front of base down so the Hopper Latch Rods are in the front Mounting Plate Hook.
Page 14
REV5 135lb Stainless Steel Spreader Installation Mount Spreader Cont... Secure both Latches with a 1/2” Split Shaft Collar. Align 1/2” Split Shaft Collar so it is flush with the outer edge of the Hopper Tools: Allen Wrench, 1/8” Latch Rod and tighten.
REV5 135lb Stainless Steel Spreader Installation SPEED CONTROL UNIT 4.3.1 Speed Control Unit, Mechanical Rub Slot Edges to reveal Cut location Tools: Utility Knife Cut into Main Control Panel using utility knife and use a Die Grinder with cut-off wheel to cut tabs.
REV5 135lb Stainless Steel Spreader Installation Speed Control Unit cont… 4.3.2 Speed Control Unit, Electrical Power and Ground 1. Attach the connector labeled POWER to the Power Ground Harness Connector labeled SPINNER. 2. Attach the connector labeled MOTOR to the Spinner Motor Connector AUX CONTROL PANEL 4.4.1 Aux Control Panel, Mechanical...
Page 17
REV5 135lb Stainless Steel Spreader Installation Aux Control Panel Cont… 4.4.2 Aux Control Panel, Electrical Switch Connector 1. Connect the Switch Connector on the Electrical Harness to the connector on the back of the Vibrator Switch. All Black Power and Ground 1.
REV5 135lb Stainless Steel Spreader Installation TEST Connect the Negative (black) Battery Cable before testing. Refer to section 5 for Operating Instructions. 4.5.1 Vibrator Verify the electrical connections have been made properly. Turn on the Vibrator. Listen for vibration. Turn off the Vibrator.
135lb Stainless Steel Spreader Installation 5.0 OPERATION OPERATIONAL CONTROLS The 135lb Stainless Steel Spreader has four controls. These are the Vibrator Switch, Spinner Switch, Spinner Speed Control, and Hopper Cable. These controls can be operated while the spreader is in use.
Page 20
REV5 135lb Stainless Steel Spreader Installation Operational Controls Cont… 5.1.2 Main Control Panel The Main Control Panel is where the Speed Control Unit for the Spinner Motor is located. The unit has an ON/OFF button, speed adjustment controls and an LED indicator strip. The LED indicators alert the operator of malfunctions when they flash in specific patterns.
5.2.1 Rate Control The Rate Control is located on the front of the 135lb. Stainless Steel Spreader near the spinner. The Rate Control setting controls the amount of product that is dispersed from the Hopper by adjusting how far the Hopper Cable can open the Hopper Door. The Rate Control setting primarily affects the density of the product spread in the coverage area.
Page 22
REV5 135lb Stainless Steel Spreader Installation Spread Pattern Adjustment Controls Cont… 5.2.2 Speed Control This setting controls the length (distance) of the spread pattern by controlling how fast the Spinner rotates. This control also affects the density of the spread pattern.
Page 23
Spread Pattern Adjustment Controls Cont… 5.2.3 Directional Control The Directional Control setting is located on the front of the 135lb. Stainless Steel Spreader below the Rate Control. It is made of three main components, the Material Deflector, Deflector Adjustment Plate and Deflector Adjustment Rods as shown in Figure 5. The Directional Control setting controls the direction and width of the spray pattern by the orientation and width of the opening.
Page 24
REV5 135lb Stainless Steel Spreader Installation Spread Pattern Adjustment Controls Cont… Figure 6. Deflector Adjustment Holes Widest Spread Pattern Top view shown without Narrowest Spread Pattern front bumper for clarity. Figure 7. Spread Pattern Example Leading Edge Narrow Spread Pattern Wide Spread Pattern For any questions please contact us at toll free (877) 482-2040 Mon-Fri 8 a.m.
135lb Stainless Steel Spreader Installation SPREAD PATTERN SET-UP This section contains instructions on how to set up a spread pattern with the 135lb. Stainless Steel Spreader. Note that other conditions such as weather, operator driving speed, etc. can affect the spread pattern. Adjust accordingly. See Figure 8.
Page 26
REV5 135lb Stainless Steel Spreader Installation Figure 8. Spread Pattern Diagram Not to scale Width 1. Directional Control 2. Spinner Speed Distance 1. Spinner Speed Density Direction 1. Rate Control 1. Directional Control 2. Spinner Speed OPERATOR LEFT OPERATOR RIGHT...
REV5 135lb Stainless Steel Spreader Installation TROUBLESHOOTING Light pattern - Flashing Controller Error Over Current Short Circuit Open Circuit Low Voltage - 9.5 V High Voltage - 14.8 V - 19V Over Temperature - 60°C (140°F) Problem Possible Cause Corrective Action 1.
Page 28
REV5 135lb Stainless Steel Spreader Installation Troubleshooting Cont… 1. Spinner disk is stuck 1. Turn controller off. Disconnect spinner motor and free the spinner. Reconnect spinner Motor. Turn Controller on again to reset. 2. Spinner Shaft is bent 2. Turn controller off.
Page 29
REV5 135lb Stainless Steel Spreader Installation Troubleshooting Cont… First six lights on controller are 1. Voltage regulator is bad 1. Replace Voltage Regulator flashing 1. Controller is over heating 1. Let controller cool down. Circuit board needs to cool to...
REV5 135lb Stainless Steel Spreader Installation 8.0 AUX ELECTRICAL WIRING HARNESS DIAGRAM For any questions please contact us at toll free (877) 482-2040 Mon-Fri 8 a.m. to 4:30 p.m.
