- Page 1 KS 1100 B HD KS 1100 B Swiss Made Quality. Englisch BA KS1100.000-EN 08/2012...
-
Page 2: Table Of Contents
Contents Introduction Page To these operation instructions..............2 Symbols used in this manual..............2 Safety indications..................3 Appropriate use..................3 Product description......................4 Operating panel..................4 Safety instructions ........................5 Applications....................5 Safety devices ........................6 Initial start-up, standard, optional.............6 Operation ..........................7 Safety instructions..................7 Adjust the driver's seat, driving / Start............7 Driving forward, reverse, acoustic signal (optional)........7 Sweeping operation, safety, operating the sweeper......8/9 Operation of extraction, filter cleaning, parking.........9... -
Page 3: To These Operation Instructions
This manaul contains instructions on how to use the ride-on-sweeper KS1100 B and KS 1100 B HD. Our products are being improved continuously, for this reason we cannot include all tech- nical adaptions within this manual by the date of printing. If you should have any questions, please feel free to contact our Service for explanations and advise. -
Page 4: Safety Indications
Introduction Safety indications laws which abide for accident prevention The ride-on-sweeper KS1100 ist built an for protection of the environment! according to the latest standards and safety regulations. All the same it can Do not execute any changes, add or never be foreclosed that life threatening rebuild any components on the Ride-on- dangers can occur for the user or for third... -
Page 5: Product Description
Product description The ride-on-sweeper is driven by electro-motors. The KS1100 does the sweeping job by means of 2 swivel side brushes which brush the wastes to the central cylindrical brush which is positioned parallel to the driving direction. The cylindrical brush then throws over the top all wastes into the waste bin behind. -
Page 6: Safety Instructions
Safety instructions Applications Parking spaces ● Schoolyard ● Petrol station ● Underground park ● Shopping centres ● Warehouses ● Simple emptying Adjustable seat to allow an ergonomic Filter, side brushes and cylindrical brush are easily Steering column with steering accessible without the use wheel and operator panel with: - of tools - Light switch - forwards / backwards... -
Page 7: Safety Devices
Safety devices The Ride-On-Sweeper starts only when, the mechanical functions of the Ride On- Sweeper could be considerably damaged. - the battery mains switch (emergency.- The power supply respectively the start Off) And the start switch with key is in procedure must be interrupted in the ON–position;... -
Page 8: Operation
Operation Drive operation / Starting Safety instructions the Sweeper The Ride-on-Sweeper can only be used • Seat yourself on the drivers seat. by reliable persons. Only trained and well The Ride-on-Sweeper cannot be put instructed persons shall be used. The ☞... -
Page 9: Sweeping Operation, Safety, Operating The Sweeper
Sweeping operation Operation of the side brushes Safety instructions • The side brushes are fixed to swivel Do not switch on the vacuum motor when connections. When the side brushes sweeping wet areas/wastes This would collide with an obstacle they swivel to lead to a clogged filter and damage to the the side which prevents damage to vacuum motor. -
Page 10: Operation Of Extraction, Filter Cleaning, Parking
Sweeping operation Press the Tipp switch 5-10 seconds long Operator panel (without overhead disposal) for the filter cleaning. The filter cleaning begins to work. ON and OFF key switch Switch for cylindrical brush Switch for Lever to open a flap and allow large filter cleaning wastes enter (Wastes till 65mm) E.g. -
Page 11: Dust Bin Emptying, Removing + Installing Dust Box
Operation • Slide the waste box inside again Waste box emptying • As soon as the waste box is The waste box is used to collect all completely inside the machine the sweeped wastes. It can be found at the steel-swivel catches can easily be moved downwards to lock position. -
Page 12: Filter Replacement, Expansion, Installation
Operation Filter exchange Dismantling The integrated lamella filter separates the • Open the main cover. (A). fine dust. The lamella filter is cleaned by • Secure the main cover with the sup- electric activation vibration unit. port rod in top position. •... -
Page 13: Machine Cleaning
Machine cleaning The Ride-on-Sweeper is a machine with electrical components. Attention ! Humidity damages electronic components. Humidity can lead to creeping current and short circuits. Never use high-pressure cleaners. Maintenance and Service Safety instructions Attention ! Before doing any work on the Ride-on-Sweeper it is compulsory to first TURN-OFF and the Main Switch (Emergency-Off Switch) and REMOVE THE KEY in order to prevent unforeseen switching-on of the machine. -
Page 14: Side Brushes
Maintenance and Service Side brushes Side brushes exchange the counter flange coming from the side brush motor and is fixed tightly. Removal of the side brushes • Switch off of the Ride-on-Sweeper. Side brushes adjustment • Pull the levers of the side brushes upwards. -
Page 15: Cylindrical Brush
Maintenance and Service Cylindrical brush • Pull out the cylindrical brush out of Cylindrical brush exchange the machine and remove all wastes, Dismantling the cylindrical brush strings, tapes etc. from the cylindrical mandrel. • Switch OFF the Ride-on-Sweeper and remove the key. Cylindrical brush fitting •... -
Page 16: Cylindrical Brush Readjustment
Maintenance and Service Cylindrical brush machine which is on the right-hand Readjustment of the Cylindrical brush side when looking in driving direction. Sweeping height / Sweeping range Hex bolt The sweeping height/sweeping range of the cylindrical brush is important to achieve perfect surface cleaning results Hex nut and for the most effective use of the cylin-... -
Page 17: Batteriy
Maintenance and Service Batteriy Safety instructions for the use of batteries! • Warranty is only applicable if Original Cleanfix batteries and chargers are used. • It is compulsory to read and pay attention to the Operation and Safety Instructions of the Original battery and charger manufacturer! Abide to all recommendations and advices of the local authorities in the country of application before using the batteries and charger. -
Page 18: Battery Charging
Maintenance and Service Battery Description Four Gel batteries type Dryfit each 6 V / 180 Ah provide the Ride-on-Sweeper KS1100 with power. The charging status of the batteries can be read on the battery indication on the Operator Panel. Signification of the LED lights on the battery status panel When switching ON the Ride-on-Sweeper immediatley the LEDs start blinking, nicely one after another, beginning at the minus/negative terminal and blinks along to the plus/ positive terminal. -
Page 19: Brakes, Adjust The Brakes, The Brake Control Function
Maintenance and Service Brake Danger ! The brake is a safety relevant building component! All work for maintenance/ service or exchange have to be done by qualified and trained personell. The brake (drum brake) affects the front wheel and is activated via the brake pedal and bowden cable. -
Page 20: Fuses, Safety Information
Maintenance and Service Fuses Safety information There is an integrated contact in the drivers seat. The Ride-on-Sweeper cannot be driven or other switch functions used unless someone is seated and the seat contact is activated. The fuse box is on the right side of the Ride-on-Sweeper under the main machine cover, underneath the cylindrical-brush lever. -
Page 21: Maintenance Table
Maintenance Table Daily Maintenance • Charge the battery • Check the machine for visible damage or functional errors • Check the state of the lamella-filter and clean it • Empty the waste box (hopper) Additionally every 50 Operation hours • Clean and grease the battery terminals/poles. •... -
Page 22: Errors And Solutions
Errors and Solutions Error Possible reason Solution No function display • Main Switch/Emergency-OFF switch • Press/turn ON red Main on the control Switch, Turn Key-Switch to is not turn ON / activated instruments: position ON • Seat contact—is not activated •... -
Page 23: Circuit Diagram Ks 1100 B
Schaltplan Kehrsaugmaschine KS 1100 B MB 1 MB 2 FM 2 FM 1 M(+) B(+) M(-) B(-) 100% S 10 Pos. Bezeichnung Art. Nr. Relais Bürstmotor 30 A 080.394 Relais Saugmotor 30 A 080.394 Relais Bürstmotor Seitenbesen 30 A 080.394 Relais Rüttlermotor 20 A 500.982 Relais Hydraulikpumpe 30A... -
Page 24: Circuit Diagram Ks 1100 B Hd
Circuit diagram Ride-on-Sweeper KS1100 B HD MB 1 MB 2 FM 2 FM 1 M(+) B(+) M(-) B(-) 100% S 10 Pos. Designation Item No. Brush motor relay 30 A 080.394 Relay 30 A naturally aspirated 080.394 Side brush motor relay 30 A 080.394 Relais motor filter cleaning 20 A 500.982... -
Page 25: Technical Data
Technical Data Batterie 24V (180 Ah) Drive/Power supply upto 4 hours Running time 116 cm Sweeping width with side brushes 70 cm Working width of Cylindrical brush 8000 m Theoritical Sweeping performance 5600 m Practical Sweeping performance 70% of theoretical 16800 m Net cleaning area performance upto m2/3h 60 l... -
Page 26: Disposal, Environmental Protection
In order to have access to the machine type sticker, first lift up the main cover and support with inside machine open position. TRADE MARK OF TRADE MARK OF CLEANFIX AG CLEANFIX AG STETTENSTRASSE STETTENSTRASSE Swiss Made Quality. Swiss Made Quality. CH-9247 HENAU CH-9247 HENAU Made in Switzerland... -
Page 27: Declaration Of Conformity
EN 50366:03+A1:06; IEC 62233:05:05 (ed.1) EN 61000-3-2:06; IEC 61000-3-2:05 (ed.3) EN 61000-3-3:95+A1:01+A2:05; IEC 61000-3-3:94+A1:01 +A2:05 (cons. ed. 1.2) Cleanfix Reinigungssysteme AG declare in own responsibility that the above named product, referred to by this declaration above, with the mentioned standard... -
Page 28: Service
Cleanfix Reinigungssysteme AG Stettenstrasse CH – 9247 Henau-Uzwil Schweiz Tél. +41 71 955 47 47 Fax +41 71 955 47 60 info@cleanfix.com For spare parts visit our website:: www.cleanfix.com Authorized Cleanfix Dealer: • Company:....………………………..…………………………… • Contact person:......……………………………………….. • Address: ……………......………………………………...
