Installation & Assembly:
Parts List
Part #
Parts Description
A
M5x45 Drywall
Screw
B
Plastic Anchor
C
M6.5 Washer
D
M4x16 screw
E
M4x40 screw
F
M6x16 screw
G
M6x40 screw
H
8MM hex bolts
I
M5x16 arm screw
J
M5 washer
K
S=3mm Allen
wrench
L
S=6mm Allen
wrench
M
M5 washer
N
Arm
O
Universal Spider
www.amer.com
Universal Drop Ceiling Mount
Qty. Part Image
2
Not used with 2x2 plate
2
Not used with 2x2 plate
2
Not used with 2x2 plate
4
4
4
4
2
4
4
1
1
4
4
1
IMPORTANT! Read instruction sheet be-
fore you start installation and assembly.
Before you start make sure all parts listed
are included with your product.
Part #
Parts Description
P
Mount plate
Q
Middle Piece
R
Ceiling Plate
S
Caddy® Speed Link
T
Hold Down Clips
For assistance, call 1-800-241-1644
Model Number:
AMR DCP100KIT
Qty. Part Image
1
1
1
1
2
Advertisement
Summary of Contents for Amer AMR DCP100KIT
- Page 1 Model Number: Installation & Assembly: Universal Drop Ceiling Mount AMR DCP100KIT IMPORTANT! Read instruction sheet be- fore you start installation and assembly. Before you start make sure all parts listed are included with your product. Parts List Part # Parts Description Qty.
- Page 2 DO NOT CONTINUALLY TURN THE PROJECTOR IN A COUN- TER-CLOCKWISE DIRECTION! This can cause the mount to come apart and may cause injury or damage. swivel screw swivel screw Support/Safety connection slots (choose 2, depending on installation) tilt screw tilt screw www.amer.com For assistance, call 1-800-241-1644...
