This machine transmits both AUDIO and VIDEO
signal by laser beam. It is a good example of a
basic optical communication system.
The Kit consists of:
•
laser transmitter MLDD 3.0
•
laser receiver with holder
•
microphone
•
loudspeaker
•
adjustable transmitter holder
•
power supply -2 pcs
•
all contained in a plastic suitcase
Figure 1 Example of transmission of an audio signal
Laser Communication KIT
1- Display of output power
2- Input connector for external LF-audio signal
3- Green control light-power
4- Power switch (turn the key right to switch on)
5- Input connector for external HF-video signal
6- Knob for controlling output power of laser beam
7- Laser diode with cable
Figure 2 Example of transmission of a video signal
