REGULAR CAMERA USER MANUAL
960H Ultra Resolution Series
It's recommended to use this camera with a DVR which supports 960H video recording.
C
C
A
A
U
U
T
T
I
I
O
O
N
N
:
:
To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.
Only operate this apparatus from the type of power source indicated on the label.
The company shall not be liable for any damages arising out of any improper use, even if we have been
advised of the possibility of such damages.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
This exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
ROHS Announcement
All lead-free products offered by the company comply with the requirements of the European law on the
Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and
products are strictly "lead-free" and without the hazardous substances cited in the directive.
The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected
separately at the product end-of-life. This applies to your product and any peripherals marked with this
symbol. Do not dispose of these products as unsorted municipal waste.
CE Mark
This apparatus is manufactured to comply with the radio interference.
The company does not warrant that this manual will be uninterrupted or error-free. We reserve the right to
revise or remove any content in this manual at any time.
The product image may differ from the actual product.
Please read the instructions thoroughly before using the product.
C
A
C
A
R
I
S
K
O
F
E
L
E
R
I
S
K
O
F
E
L
E
U
T
I
O
N
U
T
I
O
N
C
T
R
I
C
S
H
O
C
K
C
T
R
I
C
S
H
O
C
K
505Z
181_V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVC181 and is the answer not in the manual?

Questions and answers

Summary of Contents for Avtec AVC181

  • Page 1 505Z REGULAR CAMERA USER MANUAL 960H Ultra Resolution Series The product image may differ from the actual product. It’s recommended to use this camera with a DVR which supports 960H video recording. Please read the instructions thoroughly before using the product. To reduce the risk of electric shock, do not expose this apparatus to rain or moisture.
  • Page 2 FEATURES 1. 1/3" HR Color CCD with SONY Effio DSP 2. 700 TVL superior image quality 3. Digital wide dynamic range (D-WDR) to increase the image recognizability of the overexposed and dark areas 4. Clear and sharp images in the dark environment with the B/W mode selectable 5.
  • Page 3 MAJOR OPERATING CONTROL AND FUNCTIONS D.D. V.D. 12V DC VIDEO AUDIO 1. Flange Back Adjusting Ring It is suitable for CS-mount lens. When using C-mount lens, please use the CS-C conversion ring*. 2. Back Focal Lock Hexagonal Bolt The camera is set at the standard back focal position. Fine-tuning is inevitable according to the lens types. Adjust the lens back-focus by turning the focusing knob.

  • Page 4: Menu Tree

    Flange Back Adjusting Ring NOTE: Focus or Flange-Back Ring Adjustment Back focal lock hexagonal bolt 1. Mount the lens by turning it clockwise on the lens mount of the camera. 2. Loosen the screws on the flange-back adjusting ring. 3. Turn the flange-back adjusting ring to the desired position. 4.
  • Page 5 SUB-MENU OPTIONS WHITE BAL ANTI CR MANUAL LEVEL 012 ~ 031 PUSH LOCK SPEED 0 ~ 255 DELAY CNT 0 ~ 255 ATW FRAME x0.50 / x1.00 / x1.50 / x2.00 ENVIRONMENT INDOOR / OUTDOOR PUSH USER1 B – GAIN / R – GAIN 0 ~ 255 USER2 BACKLIGHT...
  • Page 6 Sub-menu Brief Description SUB-MENU DESCRIPTION LENS Select and set the type of your lens: D.D., V.D., or board lens. SHUTTER / AGC 1. Select “AUTO” to allow the camera to act automatically when the light condition of the environment changes. 2.
