RFS HYBRIFLEX

RFS' HYBRIFLEX

Remote Radio Head (RRH) hybrid feeder cabling solution combines optical fiber and

DC power for RRHs in a single lightweight aluminum corrugated cable, making it the world's most

innovative solution for RRH deployments. It was developed to reduce installation complexity and

costs at Cellular sites. HYBRIFLEX® allows mobile operators deploying RRH architecture to

standardize the RRH installation process. HYBRIFLEX® combines optical fiber (multi-mode or single-

mode) and DC power wire in a single corrugated cable and can connect multiple RRHs with a single

feeder.

HYBRIFLEX

cables are manufactured, pre-terminated, with various types of termination and are cut

to specific lengths. The aluminium outer conductor facilitates easy transportation (because it is light-

weight) and handling. Moreover this cable is easier to bend than other optic / power solutions using

a steel outer conductor.

Click or scan to learn more

about RFS HYBRIFLEX®

www.rfsworld.com

Doc# HYB-GEN-001 rev. B

Table of Contents

Need help?

Do you have a question about the HYBRIFLEX and is the answer not in the manual?

Questions and answers

Summary of Contents for RFS HYBRIFLEX

Page 1 DC power for RRHs in a single lightweight aluminum corrugated cable, making it the world’s most innovative solution for RRH deployments. It was developed to reduce installation complexity and costs at Cellular sites. HYBRIFLEX® allows mobile operators deploying RRH architecture to standardize the RRH installation process. HYBRIFLEX® combines optical fiber (multi-mode or single- mode) and DC power wire in a single corrugated cable and can connect multiple RRHs with a single feeder.
Page 2: Table Of Contents
Table of contents Image of Non-OVP Hybriflex hybrid system RFS Non-OVP HYBRIFLEX® feeder assembly RFS Non-OVP HYBRIFLEX® configurations RFS Non-OVP HYBRIFLEX® Generation 2 Design Enhancements HYBRIFLEX® tower accessories and installation tools IEC standard fiber inspection Fiber interface zones per IEC template 613000-3-3 RFS suggested optical testing HYBRIFLEX®...
Page 3 ® RFS HYBRIFLEX RFS’ HYBRIFLEX® Remote Radio Head (RRH) hybrid feeder cabling solution combines optical fiber and DC power for RRHs in a single lightweight aluminum corrugated cable, making it the world’s most innovative solution for RRH deployments. It was developed to reduce installation complexity and costs at Cellular sites.
Page 4 ® RFS HYBRIFLEX Non-OVP HYBRIFLEX® feeder assembly (using ODC (top) & LC (bottom) connectors) End 1 End 2 Top RRH Bottom BBU termination on fully- armored fiber Hybrid assembly length LC termination (enlarged to show colors) Color-coded, shielded Power power wire conductors HYBRIFLEX®...
Page 5 This was due to recent attacks from animals that would permanently damage the fiber optic break-outs at the top of the assembly, and to shielding power wires to additional transient voltages from lightning strikes. RFS was able to accommodate these requests by Engineering new features into the existing models:...
Page 6 ® RFS HYBRIFLEX 6x12 HYBRIFLEX® configurations Cable type HB078-05U6S12- HB114-13U6S12- HB158-21U6S12- Cable brand HYBRIFLEX® HYBRIFLEX® HYBRIFLEX® Conductor gauge 10 AWG 6 AWG 4 AWG Number of conductor 6 pairs, shielded 6 pairs, shielded 6 pairs, shielded Number of fibers 12 pairs, armored...
Page 7 ® RFS HYBRIFLEX 9x18 HYBRIFLEX® configurations Cable type HB114-05U9S18- Cable brand HYBRIFLEX® Conductor gauge 10 AWG Number of conductor 9 pairs, shielded Number of fibers 18 pairs, armored Hybrid armor type Corrugated aluminum Hybrid fiber mode single Hybrid termination Top: ODC...
Page 8 ® RFS HYBRIFLEX 3x6 HYBRIFLEX® configurations Cable type HB078-13U3S6- HB114-21U3S6- Cable brand HYBRIFLEX® HYBRIFLEX® Conductor gauge 6 AWG 4 AWG Number of conductor 3 pairs, shielded 3 pairs, shielded Number of fibers 6 pairs, armored 6 pairs, armored Hybrid armor type...
Page 9: Hybriflex® Tower Accessories And Installation Tools
RFS HYBRIFLEX HYBRIFLEX® tower accessories and installation tools Although RFS suggests that hangers and hoisting grips be part of the hybrid kits, which includes the main trunk assembly, RFS can offer these items to be ordered separately if need be.
Page 10: Iec Standard Fiber Inspection
ODC plug and socket connectors attach the RRH to the main trunk. Tools and test equipment Use only approved test equipment recommended by RFS. Note: It is recommended that the main feeder be tested LUCENT using ODC to LC test adapters and not the actual Connector (LC) HYBRIFLEX®...
Page 11: Fiber Interface Zones Per Iec Template 613000-3-3
® RFS HYBRIFLEX Fiber interface zones, per IEC Template 613000-3-3 (for single-mode fiber) A. Critical zone B. Cladding zone C. Adhesive zone D. Contact zone Zone Description Diameter Allowable defect Allowable size diameter scratches Core zone 25μm None @200x None @200x Cladding 25-120μm...
Page 12 ® RFS HYBRIFLEX LC connector inspection 1. Inspect the LC fiber end-face using approved test equipment probe and the appropriate LC fiber tips. If the test fails due to too much debris, clean end-face accordingly and re- test. LC end-face inspection...
Page 13 ® RFS HYBRIFLEX Important Note: In the event of failure, clean connectors as shown below, refer to optical fiber cleaning section within this document for additional cleaning suggestions. Cleaning ODC plug and socket connector If the ODC plug or socket end-face shows any particles or debris, clean the end-face using the following 1.25mm one click cleaning or swab stick.
Page 14 4 dB (2 dB up and 2 dB down) Field Jumpers testing Connect the HYBRIFLEX® jumper cable to the ODC plug test lead as shown below, and follow test equipment instructions. Refer to the system insertion loss table for pass/fail criteria when recording results.
Page 15: Hybriflex Handling And Installation Procedures
Test diagram using ODM Test diagram power meter or similar using OTDR device device HYBRIFLEX handling and installation procedures HYBRIFLEX® cable should be handled and installed according to the same rules, instructions and regulations as typical coaxial cables. www.rfsworld.com Doc# HYB-GEN-001 rev. B...
Page 16 ® RFS HYBRIFLEX These short instructions were written for qualified and experienced installers. They describe, in short, the main points that have to be noted during the installation, without any claim of completeness. Any liability or warranty for results of improper or unsafe use is disclaimed!
Page 17 ® RFS HYBRIFLEX Handling of HYBRIFLEX® cable Upon receiving the HYBRIFLEX® shipment, it is highly recommended that the drum be inspected for any physical damage and all fiber connection points be tested. Do not drag the cable over sharp edges. If it can’t be avoided, protective measures must be...
Page 18 ® RFS HYBRIFLEX HYBRIFLEX® hoisting and pulling  Note: when hoisting and pulling HYBRIFLEX® always uses caution.  Do not remove the protective sock. If removed during pre-test, re-attach securely before hoisting  Do not attach hosting grip over protective sock ...
Page 19 ® RFS HYBRIFLEX HYBRIFLEX® Cable is supplied in specific cut length, with fully terminated factory connectors. Short lengths of small HYBRIFLEX® can be hoisted manually, otherwise a winch is recommended. Provide a pulley high enough on the tower to enable the HYBRIFLEX® line to be raised sufficiently.
Page 20 ® RFS HYBRIFLEX ® HYBRIFLEX bending guidelines and parameters As shown from side view, rather form a large bow and pull and guide the As shown from side cable horizontally without (upper) and top (lower) creating any twist view, do not swing the...
Page 21: Fixation/Mounting Of The Cable
The crush resistance of aluminium is lower than copper, which should be considered when tightening the clamps (especially if these clamps have not been approved by RFS). A number of different clamps may be used, and we recommend using the SNAP-series products. The SNAP hanger is suitable for all fixing situations as well as being the safest (most failure proof) clamp, offering a large number of exceptional advantages.
Page 22 ® RFS HYBRIFLEX 1. Set the JSTRIP onto a straight part of cable at desired point of the grounding kit (figure a). 2. Insert a screwdriver into the two support holes and begin turning, maintaining a Figure a straight line – do not push in any lateral directions and do not twist or leave the right angle line.
Page 23: Rfs Rrh Jumper With Ip-Rc Connector Installation Guide
Afterwards mould it in a straight line to the coaxial cable to avoid gaps where water could enter (see Diagram 5). RFS RRH jumper with IP-RC connector installation guide Use the following instruction to properly install/attach the IP-RC connector. Failure to follow these procedures entirely may cause damage to the Fiber or Connector.
Page 24 ® RFS HYBRIFLEX Engage the compression nut thread to the body 3-4 revolutions to keep the grommet in place but do not tighten fully to allow for adjustment during RRU connection. a) Remove protective dust cap (top), disengage the compression nut (bottom), adjust the jumper to proper length Slide IP-RC Gland body down jacketing to allow access to the fiber end connector.
Page 25 ® RFS HYBRIFLEX Heat shrink exposed Finish threading the compression nut to complete the installation. Thread compression nut until it bottoms out (no gap) with the extended (front) inner body. No gap Reverse steps 6 to 1 to remove sleeve for maintenance. Note: Once the Nut is tight, spring fingers are compressed tightly.
Page 26: Hybriflex® Bulkhead Connector Fitting Installation
Tape, Ruler, specific bulkhead fitting size open ended wrench, Jacket removal tool and ripcord removal kit HYBRIFLEX® cable bulkhead fitting kit is shipped hand tightened on all trunk cable. In the event of a complete field installation, follow the entire instruction, otherwise skip to step 7a.
Page 27 8) Carefully insert the fiber and DC wires into the junction box punch hole, then slowly guide the HYBRIFLEX® connector (and reducer if applicable) into the fitting hole. Note: Be careful not to cut any wires.
Page 28 ® RFS HYBRIFLEX Figure 8 Figure 9 Figure 10 Figure 11 (Plastic fitting) (Metal fitting) www.rfsworld.com Doc# HYB-GEN-001 rev. B...
Page 29: Additional Installation Guidelines For All Hybriflex® Products
® RFS HYBRIFLEX Additional installation guidelines for all HYBRIFLEX® products www.rfsworld.com Doc# HYB-GEN-001 rev. B...
Page 30: Fiber Cleaning Introduction
® RFS HYBRIFLEX Fiber cleaning introduction Warning: Before attempting to clean or inspect fiber optics it is strongly recommended that technician have a good understand of the IEC 61300-3-35 fiber optics standard procedure. This document can be obtained simply by performing a google search for IEC 61300-3-35.
Page 31: General Reminders And Warnings
® RFS HYBRIFLEX General reminders and warnings Review these reminders and warnings before you inspect and clean your fiber-optic connections. Reminders:  Always turn off any laser sources before you inspect fiber connectors, optical components, or bulkheads.  Always make sure that the cable is disconnected at both ends.
Page 32: General Inspection And Cleaning Procedures
® RFS HYBRIFLEX General inspection and cleaning procedures This section describes the connector cleaning process. Additional sections provide more detail on specific inspection and cleaning techniques. General Cleaning Process Complete the following steps: 1. Inspect the fiber connector, component, or bulkhead with a fiberscope.
Page 33 ® RFS HYBRIFLEX Cleaning techniques for pigtails and patch cords This section describes cleaning techniques for pigtails and patch cords. Note: No known cleaning methods are 100% effective; therefore, it is imperative that inspection is included as part of the cleaning process. Improper cleaning can cause damage to the equipment.
Page 34 ® RFS HYBRIFLEX Dry clean technique: lint-free wipes This section describes dry cleaning techniques that use lint-free wipes. Tools • Lint-free wipes, preferably clean room quality Note: Make sure that the lasers are turned off before you begin the inspection.
Page 35: Hybriflex® Jacket Removal Tools Instruction
Always make sure to use appropriate protection. Also, this user instruction is applicable for all size of HYBRIFLEX®. Use caution when handling the jacket removal tool to avoid any accidental contact with the cutter blade.
Page 36 Armor cutting tool instruction for 1-1/4” and 1-5/8” inch The following instructions can be use for 1-1/4 and 1-5/8” HYBRIFLEX®’s cable. Note, the cutting tool are special design, an off the shelf pipe cutter from local hardware should not be use. Do not use a knife.
Page 37 ® RFS HYBRIFLEX Roller Guide Aluminum Cutting Blade Roller Guide Figure 1 Blade handle Tuning Knob Handle Latch 1) Using the jacket striping tool remove the jacket off the cutting section Figure 2 2) Turn the turning knob counter clockwise all the way until the tool is completely open (Figure 2).
Page 38 Armor cutting tool instruction for 5/8 and 7/8 inch The following instructions are designed for use with the 5/8 HYBRIFLEX® cable. Note: HYBRIFLEX® Cutting tool is a special design. Knives or ‘off the shelf’ pipe cutters should not be used. Aluminum cutting blade space blade taped in box...
Page 39 ® RFS HYBRIFLEX Armor removal instruction Required Tools Stop Collar Click or scan for armor removal video Jacket removal Mandrel Tube cutter 3” Figure 1 Figure 2 Figure 1a Figure 2a Figure 2b Figure 5 Figure 3 Figure 4 www.rfsworld.com...
Page 40 Figure 10 Figure 10b Click or scan for armor removal video HYBRIFLEX® is constructed with ripcord for ease of armor cut back. Follow these steps to remove the armor: Safety: Caution! Use hand protection and safety glasses, the sharp aluminum edges and flying particles can be dangerous.
Page 41 ® RFS HYBRIFLEX 3) Place the cutting tool over the 3” exposed aluminum armor; slowly turn the cutter handle clockwise until the blade is fully engaged with the aluminum armor (Figure 2) Note: Armor should be cut on the high end (peak) of the corrugation, not in the valley (see Figure 2b). Rotate cutting tool and tighten handle as needed until the aluminum armor cut as shown in Figure 2a.
