Summary of Contents for Sterisil AC
- Page 1 719 622 7200 Sterisil.com STERISIL® AC SYSTEM INSTALLATION AND OPERATING MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Sterisil Ac Features ® Installation Details Installation Instructions Maintenance Troubleshooting and FAQ NEED HELP OR HAVE QUESTIONS? Our technical support staff is available and ready to help. Please call, email, or visit us online for additional support. -
Page 3: Introduction
Engineered for use with your office’s table top autoclaves and instrument washers, the Sterisil Ac produces distilled quality water with <10 ppm Total Dissolved Solids (TDS). Audible and visual ® alarms make cartridge replacement worry-free and the Sterisil Ac requires only minutes of maintenance. -
Page 4: Sterisil ® Ac Features
• Backup filters supply your office with water for your table top autoclaves even after audible and visual alarms trigger. • Designed for offices with source water containing <150 ppm TDS. • Sterisil ISO 13485 certification ensures that your new Sterisil Ac unit has been tested for performance ® ®... -
Page 5: Installation Details
LOCATION Generally, the Ac System is installed centrally within the dental office in the equipment room, sterilization center, hallway, or laboratory. If the hinged mounting bracket is selected, the typical mounting location would be on the wall near the source water supply. -
Page 6: Installation Instructions
® installation site. 2. Prepare installation site. a. Ensure there is one 110 V AC electrical outlet within 6 ft and a water supply line within 10 ft of the desired installation site. 3. Install the mounting plate. a. Test the fit of the mounting plate at the desired location by placing it on the wall. - Page 7 Insert the faucet assembly into the hole as shown. c. Tighten faucet in place and install quick connect fitting. 6. Establish Sterisil Ac plumbing connections. ® a. Ensure that the municipal cold water supply line to your sink is turned off. From the municipal cold water supply line, install a tee valve for under-sink installation (supplied by customer) and reduce to ¼”...
- Page 8 Insert the white ¼” (red in the diagram below) PEX tubing supplied with your Ac unit into the fitting and ensure a secure fit. c. Run the ¼” white tubing from the municipal cold water supply to the Ac unit and cut the tubing, leaving enough slack to allow the system to slide out from the cabinet.
- Page 9 Connect the RJ12 data line from the Ac unit to the data union included with the unit. Connect the other end of the data union to the RJ12 data line from the faucet.
- Page 10 AC SYSTEM DIAGRAM GP6002.B...
-
Page 11: Maintenance
On the horizontal axis of the graph below, locate your Source TDS reading and trace a line vertically until it touches the red, Ac-CXL curve (or blue, Ac-C curve if you are using the space saving Ac-C cartridges). Next, trace a line horizontally to the left until it meets the vertical axis. This... - Page 12 REPLACING YOUR AC CARTRIDGES After the Ac has notified you that a cartridge replacement is necessary either by the Water Quality Alarm LED light on the faceplate turning solid red and/or after hearing the Ac’s audible alarm (beeping), DO NOT replace all three AC-CXL or AC-C cartridge at once (unless directed to do so by a Sterisil certified technician).
-
Page 13: Troubleshooting And Faq
THE Ac UNIT IS NOT PRODUCING ANY WATER Ensure that the cold water municipal supply line to the Ac unit is turned on. If the cold water supply is not turned on, turn it on and check for water again. If the cold water supply is on, continue troubleshooting: 1. -
Page 14: Sterisil.com
THANK YOU! Thank you for purchasing your new Sterisil Ac System! ® We know that you, your patients and staff will be pleased with this Unit! Should you have any installation questions, please contact us at: (719) 622-7200 or online at Sterisil.com EMERGO EUROPE Sterisil, Inc.
