Rheem RXPX-D01 Installation Instructions

INSTALLATION INSTRUCTIONS
Recognize this symbol as an indication of Important Safety Information!
WARNING
THIS ACCESSORY IS TO BE INSTALLED BY A QUALIFIED, LICENSED SERVICE PERSON. TO AVOID
UNSATISFACTORY OPERATION OR DAMAGE TO THE PRODUCT AND POSSIBLE UNSAFE CONDITIONS,
INCLUDING ELECTRICAL SHOCK, REFRIGERANT LEAKAGE AND FIRE RESULTING IN PROPERTY DAM-
AGE, PERSONAL INJURY OR DEATH, THE INSTALLATION INSTRUCTIONS PROVIDED WITH THIS ACCES-
SORY MUST BE STRICTLY FOLLOWED AND THE PARTS SUPPLIED USED WITHOUT SUBSTITUTION.
DAMAGE TO THE PRODUCT RESULTING FROM NOT FOLLOWING THE INSTRUCTIONS OR USING UNAU-
THORIZED PARTS MAY BE EXCLUDED FROM THE MANUFACTURER'S PRODUCT WARRANTY COVER-
AGE.
Description
Relay Control
Screw (8-18)
Wire Assembly (8" Yellow)
Wire Assembly (18" White/Red)
Wire Assembly (8" Yellow)
Wire Assembly (8" Brown)
Instructions
WARNING
BEFORE BEGINNING ANY MODIFICATION, BE SURE MAIN
DISCONNECT SWITCH IS IN THE "OFF" POSITION. FAIL-
URE TO DO SO CAN CAUSE ELECTRICAL SHOCK
RESULTING IN PERSONAL INJURY OR DEATH. TAG DIS-
CONNECT WITH A SUITABLE WARNING LABEL.
1. INSTALLATION PROCEDURE
A. Remove access panel to control box.
B. Refer to control box drawing for mounting location of the
relay control (Figure 1A Rectangles, Figure 1B Cubes).
2. ELECTRICAL CONNECTIONS
A. Please refer to the unit diagram and to Figure 2 for making
the electrical connections.
B. Locate contactor coil terminals on contactor in unit control
box.
C. Remove the two wire connections (yellow and brown) from
the wire low voltage contactor coil and place the new wires
from the kit (yellow and brown with 3/8" terminals) to the
contactor then place the original wires to the piggyback of
the new wire.
HEAT PUMP THERMOSTAT
WARNING LIGHT KIT
RXPX-D01
PARTS LIST
Part Number
42-23114-06
63-22338-01
45-50205-13 DJ
45-61999-25 JA
45-50205-13-DK
45-50207-13-DK
92-103091-01
D. Connect the other ends of the new wire to the coil side of
the relay.
E. Remove Y. wire from DCF T-Stat side and place new yel-
low wire from kit with two piggybacks in its place. Then put
the original wire on the piggyback wire. Connect other end
to the com terminal of the relay.
F. Connect white/red wire to the normal closed side of the
relay. Run the rest of the wire with the thermostat wire to "L"
terminal of the thermostat.
G. Replace access panel.
H. Restore power to the unit and check for operation.
NOTE: Warning light on thermostat will come on during a 5 minute
compressor time delay, and for 5 seconds during defrost while the
compressor is off. Homeowner should only be concerned if light
stays on for more than 5 minutes.
Qty.
1
1
1
1
1
1
1
92-103091-01-02
SUPERSEDES 92-103091-01-00
