Summary of Contents for X-POWER SanyPump Series
- Page 1 SANY-PUMP Programmable electronic circulator for heating system and domestic water supply Manual www.xpowerwaterpumps.com...
- Page 3 Index Cautions Pag. 01 Introduction Pag. 02 Nomenclature Pag. 02 Data and Dimensions Pag. 03 Curves Pag. 04 Pumping Liquids Pag. 04 Temperature Pag. 05 Installation Pag. 06 Connections Pag. 07 Filling and Bleeding Pag. 08 Main functions and Adjustment Pag.
- Page 4 Cautions Read and understand this user manual before installation and operation of the product. SANY-PUMP is an electrical device. It cannot be used by children and/ or people with physical, sensory and mental disabilities. Also people without experience cannot use the pump; except under close supervision.
- Page 5 Introduction 1. SANY-PUMP circulators (also known as: programmable electronic pumps), are used for hot water circulating in heating circuits and in domestic water supply. They guarantee a better cooling thanks to the motor stator (that is totally shielded), and thanks to the rotating parts (that are completely water immersed).
- Page 6 Data and Dimensions X-Power SanyPump Circulator Dimensional Data Type (mm) (mm) (mm) (mm) SANYPUMP 1” 20-6-130 SANYPUMP 1”1/2 25-6-130...
- Page 7 Curves Pumping Liquids Clean, thin, non-aggressive and non-explosive liquids without solid particles. Liquid temperature range: +2 °C to +75 °C. The model in brass also accepts water with glycol to 10%. The pH value must be between 6.5 and 8.5. Max working pressure: 10 Bar (1.0Mpa) The incoming water...
- Page 8 Temperature The "system temperature" (t1) must always be higher than the "ambient temperature" (t2) to avoid excessive condensation on the pump housing. Please refer to the temperature instructions on the product label. Lowest pumped liquid temp : 2° C Highest pumped liquid temp: 75°C Lowest ambient temp: 2°...
-
Page 9: Installation
Installation For a correct installation of SANY-PUMP, the motor shaft must be kept in horizontal position. This is the best way, for the pumped liquid to cool engine. Please check that the direction of the flow, always coincides with the diecasted arrow on the circulator. Warning! Assembly, disassembly and scheduled or un-... - Page 10 Connections Assembly shall only be performed by qualified personnel. The power cable can not contact with piping or motor housing. Only qualified personal may assem- ble and connect in force of regula- tions and in voltage-free condition. Make sure that the type of power supply is same with the requirement on the nameplate.
- Page 11 Filling and bleeding We recommend the installation of an automatic air valve, to ensure a correct operation of the recirculation system. If the pump works in domestic areas, we recommend to open all the faucets to make sure the bleeding. Make sure that the pipes are fil- led with water (to remove any air or gas bubbles), before starting...
- Page 12 Main functions and adjustment 1. Interface: The assistant panel of SANY-PUMP is designed to give an intuitive and simple interface. The circulator has six buttons: 1) Function viewing It allows to view the set mode. ■ /▶ 2) Start/stop : It allows manual ON/OFF switching. <: 3) Adjusting It allows adjusting the parameters.
- Page 13 3. Time Setting (C) Press the “Home Button” (6) to reach “Time-intervals Mode” (C). Then press “OK” (5) until the Led, that indicates the hour, begins to flash. Set up the desired time, through the Adjustment Buttons (3 and 4). Then key “OK” (5) to confirm the setting. Make sure that "Start"...
- Page 14 7.Function Viewing (1) You can press the "Function Viewing Button" (1) to observe the setting details. Press this button to check the setting data of the current mode when the system is running. 8.Saving parameters SANY-PUMP stores set up parameters. The settings are not deleted in the absence of electricity.
-
Page 15: Problems Solving
Problems Solving Problem Possibile causes Solution Tighten connections, Loose or broken wiring replace broken wiring Blown fuse or open circuit Replace fuse or close breaker circuit breaker Pump will not start Broken capacitor Replace capacitor Fibers or foreign object Disassemble pump and lodged in impeller clean Disassemble pump and... - Page 16 Warranty SANY-PUMP Warranty certificate Thank you for purchasing this pump, designed and manufactu- red to exacting high standards, and to confer safety and high quality performance. The legal guarantee starts from the date of purchase and does not cover damage caused by improper use and/or tampering not expressly indicated in this manual.
- Page 17 UE - Correct Disposal Of The Product This symbol identifies important notes regarding the correct disposal of the device. By disposing of this product correctly you will help ensure that the waste undergoes the necessary treatment, recovery and recycling, and thus prevent potential negative effects on the environment and human health which could otherwise arise due to inappropriate waste...
- Page 18 DECLARATION OF CONFORMITY Elettromek enterprise of Germanò Antonino Via C. Colombo - 98066 Patti, Messina, Italy As attestation of the manufacturer, DECLARES THAT The following models: SANYPUMP20-4-130 SANYPUMP25-4-130 SANYPUMP20-5-130 SANYPUMP25-5-130 SANYPUMP20-6-130 SANYPUMP25-6-130 They are conform to the Standard: EN ISO 12100:2010, EN 809:1998+A1:2009+AC:2010, EN 60204-1:2006+A1:2009+AC:2010, EN 60335-1:2012+AC:2014, EN 62233:2008+AC:2008, EN 60335-2-41:2003+A1:2004+A2:2010,...
- Page 20 www.xpowerwaterpumps.com...
