Summary of Contents for Radar Electronics PreView Buzzer FPV410B
- Page 1 www.radar-electronics.com e-mail.:info@radar-electronics.com PreView Buzzer ® FPV410B Operating Manual...
- Page 2 PATENTS Patented under one or more of the following U.S. Patents: 5345471, 5523760, 5457394, 5465094, 5512834, 5521600, 5682164, 5630216, 5510800, 5661490, 5609059, 5774091, 5757320, 5581256, 5832772, 5519400, 5767953, 5767627, 5589838, 5563605, 5661385, 5517198, 5610611, 5883591, 5805110, 5754144, 7088284, and 7215278. Other patents have been applied for.
- Page 3 Contents Buzzer Description ............... 1 Troubleshooting ................2 Specifications ................3 Warranty Information ..............4...
-
Page 4: Buzzer Description
Buzzer Description The Fleet PreView is equipped with a buzzer that varies the audible rate based on an ® objects range from the sensor. The rate of the audible alert will increase as an object becomes closer. The buzzer’s volume can be adjusted by turning the sound volume control knob located on the face of the buzzer. -
Page 5: Troubleshooting
Troubleshooting Common Installation Problems No audible beep on power on. Verify that DC power (9-33V) is applied to the sensor (+V to red, GND to black). Verify that the cable between the sensor and buzzer is connected. Verify that the buzzer is connected properly (Brown to +V, Blue to –V). -
Page 6: Specifications
Specifications BUZZER SPECIFICATIONS (Typical) Sound Output: 90dBA at 60cm, Dimensions: 1.7”Dia x 1.4"D (4.3cm x 3.6cm) Connection: ¼” Spade terminals Mounting: User dependent ELECTRICAL SPECIFICATIONS Power and signal are supplied by sensor OPERATING CHARACTERISTICS Warning Ranges: 5 zones MAINTENANCE Daily: Follow test and maintenance procedure. PRODUCT MANUFACTURED IN THE USA 3700102B Tel: +386 3 4900 800... -
Page 7: Warranty Information
Warranty Information MANUFACTURER STANDARD LIMITED WARRANTY AND LIMITATION OF LIABILITY Manufacturer warrants that on the Date of Purchase this Product will conform to Manufacturer's published specifications for the product, which are available from Manufacturer on request, and Manufacturer warrants that the product is free from defects in materials and workmanship. - Page 8 www.radar-electronics.com e-mail.:info@radar-electronics.com tel.. 00386 3 4900 800 3700102B Tel: +386 3 4900 800 http://radar-electronics.com/ Copyright 2016 Page 5...
