INSTALLATION INSTRUCTIONS

ANTI-TIP BRACKET INSTALLATION

Important: Determine the fi nal location of the appliance before attempting to install the bracket. You will
Anti-tip bracket
Anti-tip bracket
Anti-tip bracket
Important: After installing the bracket, try using light force to tip the unit. If the unit does not tip then the
bracket is installed correctly. If the unit does tip, reinstall the bracket more securely.
need to choose one of the three installation methods below.
Drywall Installation:
Flat washer
1. Place the bracket on the fl oor with mounting hole B against
Lock washer
2. Use two screws to secure the bracket to the wall.
3. Ensure at least one screw is secured to a wall stud.
4. Place the unit so that the mounting hole E on the unit is lined
Bolt
Screw
Note: At least one screw must enter a wood wall stud. If there
are no wall studs available, use fl oor installation.
Wall stud
Wood Floor Installation:
Flat washer
1. Place the bracket on the fl oor and secure it with two screws.
Lock washer
2. Place the unit so that mounting hole E on the unit is aligned
Bolt
Screw
Concrete Floor Installation:
Flat washer
1. Place the bracket on the fl oor and mark the location of
Lock washer
2. Using a concrete drill bit, drill an 8mm (3/8") pilot hole
Bolt
3. Remove the nut, spring washer and washer from the expan-
Expansion screw
4. Carefully tap the expansion screw into the drilled hole using
5. Place the fl oor bracket with mounting hole D over the ex-
6. Place the unit so that mounting hole E on the unit is aligned
the wall.
up with mounting hole A on the bracket and secure with a
bolt, a lock washer and a fl at washer.
with mounting hole A on the bracket and secure with a bolt,
a lock washer and a fl at washer.
mounting hole D on the fl oor.
45~55mm (1.7"~2") deep at the marked location.
sion screw.
a hammer or mallet.
pansion screw and secure with the nut, spring washer and
washer.
with mounting hold A on the bracket and secure with a bolt,
lock washer and fl at washer.
