Manta Boiler Performance BOSS PULCE FI Instruction Manual

ADVA N TAG ES
•
Low price, high performances
•
Small dimensions, minimum weight
•
Maximum handling
•
The lightest on the market
•
Only 500 ml of liquid to work
B EN EF I T S
•
Restoring of the optimal heat exchange
•
Reduction of energy consumption visible on
your bill
•
Extension of system life
•
Prevention of hot water total block
BOS S PU LCE FI
D e s ca l i n g p um p fo r s m a l l h e a t
exc h a n g e r s , ho t w a t e r h e a t e r s ,
bo i l e r s a n d w a l l - m o u n t e d bo i l e r s .
CO D. 30060100 1
TECHNICAL FEATURES
TANK
MAX FLOW RATE
CONNECTIONS
MOTOR
PRESSURE
DEGREE OF PROTECTION
WEIGHT
MAX TEMPERATURE
DIMENSIONS
PACKAGING FEATURES
NUMBER OF PIECES PER BOX
NUMBER OF PIECES PER EPAL PALLET
BOX DIMENSIONS
EPAL PALLET DIMENSIONS
PRODUCT WEIGHT
BOX WEIGHT
EPAL WEIGHT
CUSTOMS CODE *
BARCODE EAN 13
*Data updated in May 2016
MA I N F E AT URE S
The smallest pump for the descaling of
wall-mounted boilers and boilers, equipped with
3-way valves, flow inverter and stand-by.
Low cost and high performances: with only 500
ml of descaling product DETEX Plus (diluted with
1500 ml of water), can be made up to 4 descaling
processes. The shoulder strap whose Boss Pulce
FI is equipped with, in addition to favour its car-
riage, guarantees the connection of the device to
the boiler that has to be descaled. It is equipped
with 2 corner connections that simplify the con-
nections to the heat exchangers, simplifying the
maintenance connections. BOSS PULCE FI has
been designed to offer to the user the maximum
safety, small dimensions the minimum weight
and the maximum handling: features that make
BOSS PULCE FI, a unique product on the mar-
ket. Reinforced and shock-proof polyethylene
tank, special pump with Viton® membrane,
self-priming and acid resistant pump.
3,5 l
8 l/min
1/2"
12VD.C./D.C./0,04 kW
3,5 bar
IP 55
3,5 kg
50° C
H: 270 mm L: 350 mm P: 170 mm
1 pc
24
H: 45 L:36 P: 40
80x120x194 cm
4,7 kg
5,5 kg
152 kg
8413.82.00
8054633849699
