Monessen Hearth BTSB Installation Manual

BTSB
THERMAL SENSOR
KIT FOR BLO
BLOWER
Use this thermostat only with
DBX series fireplaces
installed with an approved blower.

CONTENTS OF KIT:

DESCRIPTION
T-Stat
Wires
Screw
If any part or parts are missing, contact the dealer where
you bought the thermal sensor kit.

TOOLS NEEDED FOR INSTALLATION:

Short-Handled Phillips Screwdriver
Small Jeweler's Style Screwdriver
• Turn off, unplug, and let fireplace cool before installing thermal sensor.
• Only a qualified service person should service and repair fireplace.
• A qualified service person must connect and disconnect fireplace to gas supply.
• Follow all local codes.
Electrical connections should only be performed by a qualified, licensed electrician.
Main power supply must be turned off before connecting fans to main electrical
power supply or performing service.

Electrical Grounding Instructions:

This appliance is equipped with a three-prong (grounding) plug for your protection
against shock hazard and should be plugged directly into a properly grounded three-
prong receptacle.
Always check local building codes. The installation must comply with local regulations as well
as the national electric code.
Monessen Hearth Systems
QTY
1
2
1

IMPORTANT

P/N 33D1106 Rev. 1 • January 2000
