Solid Signal LCD-500 Installation Instruction

Monoprice adjustable tilting desk mount bracket

Monoprice Adjustable Tilting Desk Mount Bracket

Model: LCD-500 (PID#5400)

VESA Compliant up to 100x100

Max Weight: 33lbs

Installation Instruction

Carefully open the carton, remove contents and lay out on cardboard or other

protective surface to avoid damage.

Check package contents against the Supplied Parts List in the next page to assure

that all components were received undamaged. Do not use damaged or defective

parts.

Carefully read all instructions before attempting installation.

Install and operate this device with care.

beginning the installation, and carefully follow all instructions contained herein. Use

proper safety equipment during installation.

Please call a qualified installation contractor for help if you don't understand these

directions or have any doubts about the safety of the installation.

Do not use this product for any purpose or in any configuration not explicitly specified

in this instruction. We hereby disclaims any and all liability for injury or damage

arising from incorrect assembly, incorrect mounting, or incorrect use of this product.

UNPACKING INSTRUCTIONS

Please read this instruction before

English

Table of Contents

Do you have a question about the LCD-500 and is the answer not in the manual?

Page 1 Monoprice Adjustable Tilting Desk Mount Bracket English Model: LCD-500 (PID#5400) VESA Compliant up to 100x100 Max Weight: 33lbs Installation Instruction UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage.
Page 2 Supplied Par ts List (1) Desk Bracket Assembled-a (1)Mornitor Bracket-b (4)M4x12 Bolt-c (4)M4x30 Bolt-d (8)M4 Washer-e (4)M4 Space-f (1)Safety Knob-g Tools Required Phillips Screwdriver CAUTION! This TV Desk mount must be securely attached to the horizontal desk. If the mount is not properly installed it may fall, resulting in possible injury WARNING and/or damage.
Page 3 Mounting the Bracket to the Desk Step 1 Make the tube extension by loose and fasten the knob...
Page 4 Mounting the Monitor Bracket to a TV Step 2 This way up! This way up! For Flat Back TV For Curved Back TV Attaching TV to Desk Bracket and Adding the Knob Step 3 Thanks for choosing our products, enjoy the using.
