- Page 1 USB 2.0 Isolator Compact USB-029L2 User’s Manual Ver. 1.0 HuMANDATA LTD.
-
Page 2: Table Of Contents
2. Feature ......................3 3. Connection ......................3 4. Power Supply ..................... 3 5. Specifications ..................... 4 5.1. Product Specification ...................4 5.2. Optional Accessories ....................5 6. Additional Documentation and User Support ............. 5 7. Warranty and Compensation................5 USB-029L2 (Ver.1.0) - Page 3 Attention Item 7 notwithstanding, HuMANDATA cannot be held liable for the consequences arising from use of this product. HuMANDATA cannot be held liable for consequences arising from using this product in a way different from the uses described herein, or from uses not shown herein.
-
Page 4: Revision History
Introduction Thank you very much for purchasing our product. USB-029L2 is a USB 2.0 High Speed (480Mbps), Full Speed (12Mbps) and Low Speed (1.5Mbps) compliant isolator which isolates between a USB host and a USB peripheral device with 3000VDC. -
Page 5: Overview
1. Overview USB Connector (Host) USB Host side Power LED (Target) USB Connector (Target) USB Target side USB-029L2 (Ver.1.0) -
Page 6: Feature
Top side (Block diagram) 2. Feature USB-029L2 is a USB 2.0 High Speed (480Mbps), Full Speed (12Mbps) and Low Speed (1.5Mbps) compliant isolator which isolates between a USB host and a USB peripheral device with 3000VDC. With USB-029L2, it can be expected to eliminate... -
Page 7: Specifications
Storage Ambient -20 to 60 [°C] (-4 to 140 [°F]) Temperature Storage Ambient 30 to 85 [%RH] Humidity Weight Approx. 75 [g] Only main body 43.5 x 67 x 27 [mm] Dimensions Without projections (1.713" x 2.638" x 1.102") USB-029L2 (Ver.1.0) -
Page 8: Optional Accessories
PEN-003-MG JAN：4937920801201 6. Additional Documentation and User Support The following documents and other supports are available at http://www.hdl.co.jp/en/faspc/USB/usb-029l2 User’s Manual … and more. 7. Warranty and Compensation Please refer to the following URL for the warranty. http://www.fa.hdl.co.jp/en/fa-warranty.html USB-029L2 (Ver.1.0) - Page 9 USB 2.0 Isolator Compact USB-029L2 User’s Manual Ver. 1.0 ..........Oct. 21, 2016 HuMANDATA LTD. Address: 1-2-10-2F, Nakahozumi, Ibaraki Osaka, Japan ZIP 567-0034 Tel: 81-72-620-2002 (Japanese) Fax: 81-72-620-2003 (Japanese/English) URL: http://www.fa.hdl.co.jp (Japan) http://www.fa.hdl.co.jp/en(Global)
