Degre K LOLe 1 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Table of contents

I- INTRODUCTION..........................................................................................................p.3
II- CEILING VERSION: LOLe 1.P......................................................................................p.4
1. Installation of the ceiling adapter and ceiling arm...................................................p.4
1.1 Assembling the ceiling adapter and attaching to the arm......................................p.5
1.2 Attaching the ceiling adapter to a concrete ceiling .............................................p.8
1.3 Attaching the ceiling adapter to a wooden ceiling..............................................p.10
2. Connection of the power supply cables.................................................................p.10
3. Attaching the light arm to the ceiling arm................................................................p.12
4. Attaching the light head to the light arm................................................................p.14
III- DENTAL UNIT ADAPTATION VERSION : LOLe 1.E.........................................................p.15
1. Remove the existing light.....................................................................................p.16
2. Arm installation...................................................................................................p.18
3. Attaching the light head to the light arm................................................................p.18
4. Connection of the power supply cables.................................................................p.19
IV- WALL VERSION: LOLe 1.M.........................................................................................p.20
1. Installation of the wall adapter plate......................................................................p.21
2. Connection of the power supply cables ................................................................p.22
V- ADJUSTMENTS..........................................................................................................p.24
1. Adjustment of the friction of the arm lifting joint.....................................................p.24
2. Adjustment of the friction of the head lifting joint...................................................p.24
3. Adjustment of the rotational friction of the head joint..............................................p.26
4, rue de Jarente - F 75004 Paris
S A S a u c a p i t a l d e 1 0 5 0 0 0 €
LOLe 1 Installation manual
Tel: +33 (0)1 71 18 18 60
R C S P a r i s B 4 0 2 2 1 1 0 1 5
Fax : +33 (0)9 70 80 10 00
T V A : F R 0 5 4 0 2 2 1 1 0 1 5
1/29
Version December 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOLe 1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Degre K LOLe 1

  • Page 1: Table Of Contents

    2. Connection of the power supply cables…………..………………………………..……..…..p.10 3. Attaching the light arm to the ceiling arm..…………………………………………..….p.12 4. Attaching the light head to the light arm.……………………………………………………...p.14 III- DENTAL UNIT ADAPTATION VERSION : LOLe 1.E………………….………………………….….p.15 1. Remove the existing light………………..……………………………………………………..…p.16 2. Arm installation…………………………..………….……..………….……………………………p.18 3.
  • Page 2 2/29 4. Adjustment of the rotational friction of the arm joint……………………………..………….p.26 VI- LED ASSEMBLY: Opteled………………………………………………….……………………………p.27 1. Replacement of an opteled …………………………………………..……….…….……….p.27 2. Adjusting position of all opteleds………………….....…………………………………...p.29 3. Check of the opteled circuit good working……...…………………………………...……p.30 The manufacturer, assembler and importer are responsible for the safety, reliability and performance of the unit only if: - installation, calibration, modification and repairs are carried out by qualified and authorized personnel...

  • Page 3: I- Introduction

    3/29 I- INTRODUCTION This manual explains how to install the LOLe operating light, to the ceiling using a ceiling adapter, to the wall with the wall adapter plate or to the dental unit. Please read those instructions carefully before installing the unit. NOTE : Information given in this manual should be taken as a general guide for proper installation of the LOLe operating light.

  • Page 4: Ii- Ceiling Version: Lole 1.P

    4/29 II- CEILING VERSION : LOLe 1.P 1. Installation of ceiling adapter and ceiling arm. Warning : Ensure that the power supply is switched off before starting installation. The central point of fixation has to be 1000mm far from the patient’s mouth and 500mm far from the unit axis, like on the picture bellow.

  • Page 5: Assembling The Ceiling Adapter And Attaching To The Arm

    5/29 Assembling the ceiling adapter and attaching to the arm. Shorten the ceiling arm if necessary. The provided arm can be used in 3m (118in.) high rooms. If the room is lower, shorten the arm accordingly. (Example: shorten the arm 500mm (20in.) if the room height is 2.5m.) Use one of the bracket sections as a template and mark the position of the security screw hole that must be drilled with a 5mm drill at the end of the light column.
  • Page 6 6/29 Attach the power supply support to the ceiling bracket with the four attachment screws provided. Place the power supply to the support plate. Route the light cable through the ceiling arm. Slide the insulator onto the cable. Connect the cable to the power supply cable and slide the insulator over the connectors. Secure the insulator with cable ties (white arrows).
  • Page 7 7/29 Attach the terminal block to the connection box and attach the connection box to one of the brackets with plastic screws. Route the power supply cable into the connection box and connect the wires to the terminal block as shown in the picture below.

  • Page 8: Attaching The Ceiling Adapter To A Concrete Ceiling

    8/29 Attaching the ceiling adapter to a concrete ceiling Use the assembled bracket and column as a template to mark the positions of the three bracket securing holes on the ceiling. Drill the holes Ø 10mm (3/8’’) and 30mm (13/16’’) deep. Insert the MK8 expansion screws in each hole and tighten them in place.
  • Page 9 9/29 Make sure that the transformer and insulator are attached firmly to the support. Lift the light arm into position on the expansion screws. Secure then the arm in place with the washers and securing nuts. Washer and securing nut Check the verticality of the arm, following 2 perpendicular axes (front/back and left/right).

  • Page 10: Attaching The Ceiling Adapter To A Wooden Ceiling

    10/29 Attaching the ceiling adapter to a wooden ceiling Use the adjustment gutters provided. Place them (3x) on to the bracket sections. Lift the assembly arm/brackets into position and attach it to the ceiling with 3x M8x50 DIN 571 screws. Use M8x40 DIN 916 screws to adjust the horizontality of the assembly.
  • Page 11 11/29 Connect the wires to the terminal block in the ceiling adapter as shown on the picture bellow: Detailed A Brown Blue Yellow/green Check the wire connections before switching on the operating light. Wrong connection may be hazardous. Attach the connection box cover. Slide the bracket cover and then the holding ring on to the ceiling arm.

  • Page 12: Attaching The Light Arm To The Ceiling Arm

    12/29 3. Attaching the light arm to the ceiling arm. Warning : make sure that the mains power supply is switched off. Bring the light arm near the bottom end of the ceiling arm. Slide the insulator onto the ceiling arm cable. Connect the light arm cable connector to the connector from the ceiling arm and slide the insulator over the connectors.
  • Page 13 13/29 Carefully push the excess cable out from the upper end of the ceiling arm. Place the cable below the cable tie that attaches the power supply to its support plate. Push the cover up over the fixing brackets and secure it in place with the holding ring.

  • Page 14: Attaching The Light Head To The Light Arm

    14/29 Attaching the light head to the light arm 2. Attach the light assembly to the LOLé arm with 1. At the factory, the arm cable is attached to the arm four screws using the 3 mm Allen key. with a cable tie. Remove the cable tie before connecting the light assembly.

  • Page 15: Iii- Dental Unit Adaptation Version : Lole 1.E

    15/29 III- DENTAL UNIT VERSION : LOLe 1.E NOTE : Place the power supply outside patient area (more than 2m (79in) from dental unit). It must not be placed on the floor. Use the extension cable supplied with the operating light if needed.

  • Page 16: Remove The Existing Light

    16/29 1. Remove the existing light 1- Open the cuspidor door. 2- Disconnect the existing light power supply cables. 3- Lift existing light away from the vertical 4- Unscrew the existing column. arm. Vertical arm Bras vertical 5- Lift the arm away from dental unit. 6- Remove the adapter in place.
  • Page 17 17/29 7- Insert the right adapter. 8- Route the new power supply cable 9- Prevent the cable from sliding into the vertical arm by through the arm. fastening it with tape. 11- Route the new cable by pulling on the old one. 10- Join the old and new cables together with tape.

  • Page 18: Arm Installation

    18/29 2. Arm installation Slide the insulator onto the arm cable. Connect the cable from the operating light to the cable coming from the arm. Slide the insulator over the connectors and secure it with cable ties. Mount the operating light to the light arm by pushing it into position. 3.

  • Page 19: Iv- Wall Version: Lole 1.M

    19/29 IV- WALL VERSION: LOLe 1.M Recommended maximum height from the floor: 1670mm R =1950m m R =880m m 4, rue de Jarente - F 75004 Paris Tel: +33 (0)1 71 18 18 60 Fax : +33 (0)9 70 80 10 00 S A S a u c a p i t a l d e 1 0 5 0 0 0 €...

  • Page 20: Installation Of The Wall Adapter Plate

    20/29 NOTE : The light connections must be hard wired to the mains (not plug connected). The wall adapter plate must be positioned so that the mains cable can be lead out (12cm) from the opening of the adapter plate. 1.

  • Page 21: Connection Of The Power Supply Cables

    21/29 2. Connection of the power supply cables Refer to information given in § II- 2. page 11 Connect the wires to the terminal block in the wall adapter as shown on the picture below. Route the power supply cable into the connection box and connect the wires to the terminal block as shown on the picture below: 4, rue de Jarente - F 75004 Paris Tel: +33 (0)1 71 18 18 60...
  • Page 22 22/29 Place the power supply to the support plate. Bundle up the excess power supply cable with a cable tie. Route the power supply cable through the wall adapter pipe as shown here below. Slide the insulator onto the arm cable. Connect the cable from the power supply to the cable coming from the arm.

  • Page 23: V- Adjustments

    23/29 V- ADJUSMENTS 1. Adjustment of the friction of the arm lifting joint Braking adjustment by friction : 1. Remove the cover of the light joint. 2. Adjust the lifting friction of the light arm with a 5mm Allen key. Tightening the screw increases the friction 3.
  • Page 24 24/29 3- Rotate the joint assembly so that you can reach the 4- Hold the light assembly in vertical position locking and adjustment screws located on the joint (see picture bellow) and unscrew the locking screw assembly using a 3mm Allen key. DETAILS 3 and 4 : View before rotation after rotation, view of the locking screw...

  • Page 25: Adjustment Of The Rotational Friction Of The Head Joint

    25/29 3. Adjustment of the rotational friction of the head joint Adjust the rotational friction of the light joint by tightening the screw located on the arm end with the 3mm Allen key. Tightening the screw increases the friction. 4. Adjustment of the rotational friction of the arm middle joint Unscrew the eight attachment screws of the upper arm cover using a 2.5mm Allen key.

  • Page 26: Replacement Of An Opteled

    26/29 V- LED MODULE: Opteled 1. Replacement of an opteled Be sure that the operating light is disconnected from mains supply 2- Remove the back covers as follows. 1- The light assembly can be removed from the light Release the cover locking claw by pressing it with a arm before opteled replacement but it is not small Allen key.
  • Page 27 27/29 6- Unscrew the attachment screws of the opteled with 7- Remove the opteled a 2.5mm Allen key. opteled 8- Attach the new opteled in reverse order. Caution: tighten the screws firmly. When attaching the PCB and insulator sheet back to the light assembly, make sure that the heat conductor paddle is properly attached to the insulator sheet.

  • Page 28: Adjusting Position Of All Opteleds

    28/29 2. Adjusting position of all opteleds Optimize the light shape and sharing out of the LOLe light through an adjustment of opteleds’ light superposition: the LOLe light consists in a superposition of all 4 opteleds’ light. 1- Connect the light to the mains supply and switch the light on.

  • Page 29: Check Of The Opteled Circuit Good Working

    29/29 3. Check of the opteled circuit good working The PCB inside the LOLe head has 2 green leds located on D1 and D2 positions. D1 “on” indicates that the PCB is on load (+5V DC) D2 has to blink 25% of total time per second. If the opteled circuit is failing or has a problem, D2 led doesn’t blink anymore.
