Robin PRO 05R V2 Quick Start Manual

P R E C A U T I O N S
• Please read and follow these instructions
and keep this manual in a safe place.
• Keep this product away from children.
• Use only parts provided by the
manufacturer.
• Make sure everything is secure before
proceeding.
• Make sure that this product is intact and
that there are no missing parts.
• To avoid damage to this product, be careful
not to overtighten or improperly thread any
of the threaded fittings.
• Do not exceed the maximum load capacity.
• All images are for illustrative purposes only.
