Related Manuals for Zte TelstraFlip 3 Z2335T
Summary of Contents for Zte TelstraFlip 3 Z2335T
-
Page 1: User Guide
Telstra Flip 3 Z2335T User Guide ZTE Australia provides dedicated support with a call centre and social media outreach. Search „ZTE Australia‟ on Facebook and Twitter to keep in touch. © ZTE 2019 Ver1.0 Oct 2019 The SAR value for this device is published on ztemobiles.com.au... -
Page 2: Table Of Contents
Contents Getting started ........................4 Key definitions ..................... 5 Inserting and Removing the SIM card ..............5 Getting to know your phone Charging the Battery ............7 Switch your phone on..................7 Wake up your phone ................... 8 Switch to sleep mode (turn off the display) ............8 Volume Controls.................... - Page 3 Contacts ........................... 12 Add new contact ....................12 Delete contacts ....................13 Edit contact details .................... 13 Search contacts ....................13 Import/Export contacts ..................14 Share a contact ....................14 Messaging ........................14 Send messages ....................14 Receive messages ................... 15 Email ..........................
- Page 4 Video recording ....................21 Media Centre ........................22 Music Player ..................... 22 Sound Recorder ....................23 Gallery ....................... 23 FM radio ......................23 More Applications ......................24 Browser ......................24 File manager ..................... 24 Calendar ......................24 Alarms ....................... 26 World Clock .......................
-
Page 5: Getting Started
Getting started... -
Page 6: Key Definitions
Key definitions Left Soft Key Contacts. Right Soft Key Messaging. Options key for some menus Power key Press to switch the handset On. Press to light up the display. Press to hang up the phone or reject an incoming call. Press and hold (long press) to power off the phone. - Page 7 5. microSD memory is an optional extra to expand your personal storage. The phone accepts microSD cards up to 32GB with FAT32 format. 6. Replace the battery, back cover and press to lock down.
-
Page 8: Getting To Know Your Phone Charging The Battery
Getting to know your phone Charging the Battery Connect the charger to the phone using a USB cable, and plug the charger into a standard power socket. Only use the approved charger and USB lead provided. Always insert the charger lead carefully. Check the plug and socket are aligned correctly. -
Page 9: Wake Up Your Phone
Wake up your phone After the phone switches to the sleep mode, the screen will be turned off. Open the flip or press the power key to switch on the display. Switch to sleep mode (turn off the display) The display will automatically dim and turn off after a pre-set period of time (see Menu > Settings >... -
Page 10: Make And Answer Calls
During a Call During a call the Volume keys will control the in call (earpiece or speaker) volume levels Media If you are using apps such as Music or Video then the Volume Keys will control the current media volume level. Make and answer calls Make a call You can make calls from the keypad, call log, or Contacts app. -
Page 11: Answer A Call
from the list using the navigation keys. Press Call or the Green Call Key to make the call. Make an international call On the home screen, press & hold the “*” key until “+” appears on the screen, then dial the country code or region code, city code and phone number. -
Page 12: Reject A Call
Reject a call Press Reject (Right Soft Key) or the Red End Key to reject a call. End a call To hang up a call press the Red End Key or simply close the flip if set to do so. Menu >... -
Page 13: Contacts
Call Key to add one call and put the current caller on hold. Press Options (Left Soft Key) then Merge to join the two (or more) parties together to create a conference call. Contacts you can go to Contacts by pressing the Left Soft Key or Menu > Contacts App. When the contacts list is displayed the Left Soft Key changes to three vertical dots which designates Options. -
Page 14: Delete Contacts
Delete contacts 1. Press Contacts > Options > Multi-Select. 2. Select the contacts you want to delete one by one. 3. To select All contacts press Options > Select All. 4. Press Options > Delete to delete the contacts. You can also use Multi-Select to share several contacts. Edit contact details 1. -
Page 15: Import/Export Contacts
refine the search. Import/Export contacts 1. In Contacts, press Options > Import/Export. 2. You can import or export to the SIM card and import or export to a microSD card if installed. Share a contact You can share a contact with someone. 1. -
Page 16: Receive Messages
2. Input your desired name or phone number in the To field. Press and hold the # key to change text entry mode to letters or numbers. You can also press OK to select a contact from your Contacts list. 3. -
Page 17: Email
Email Menu > Email – select your email service provider or select Other then add the details. Enter your full email address and then password to configure your mailbox. You can also browse your email on line for web based email providers. -
Page 18: Main Menu
Main Menu Use the navigation keys to highlight the required item then press the OK button to select it. Each category can also be selected by pressing the corresponding number key. 1 - Call history: review incoming and outgoing call records 2 - Messaging: access SMS and MMS messages 3 - Contacts: view and add Contacts to the phone 4 - Downloads: view downloaded files... -
Page 19: Connectivity
Connectivity Your phone can connect to the Internet via your mobile phone operator. The icons on the Status bar indicate which kind of data network you‟re connected to. Turn Data Off Go to Menu > Settings > Wireless & networks > Data usage to switch data on or off. To check data usage, select Mobile data usage in the same menu. -
Page 20: Connect To A Computer To Transfer Files
Go to Menu > Settings > Wireless & networks > Bluetooth. Press OK to switch Bluetooth On or Off. Available devices will be shown on the screen. Pairing ® 1. Your phone will scan for and display all available Bluetooth devices. -
Page 21: Flight Mode
On your MAC, download and install „Android File Transfer‟. Connect your handset using the USB data lead supplied. Select Media Device (MTP) from the notifications window, which will open the handset on your MAC. Flight mode In areas where the use of mobile devices is restricted, you can activate Flight mode. You will not be able to make/answer calls, send/receive messages in Flight mode. -
Page 22: Camera
Camera Your phone has a 2mp rear camera when the flip is opened. You can set a photo you‟ve taken as the wallpaper, a contact photo or send it through MMS, Bluetooth or Gmail. 1. Go to Menu > Camera. 2. -
Page 23: Media Centre
5. Press Gallery to view your video clips Media Centre Allows you to play music and videos, record sound, show your photos and listen to the radio. Go to Menu > Media centre Music Player Listen to music saved in the phone or on a memory card. Go to Menu >... -
Page 24: Sound Recorder
Sound Recorder You can record audio files through sound recorder. Go to Menu > Media centre > Sound Recorder Press Record to start recording, Select Done to stop recording or Pause to pause the recording. When paused press Resume to continue the recording. When you have finished recording you change the default filename and press Save to save it or press Discard to cancel it. -
Page 25: More Applications
The FM radio scans and saves available stations automatically. More Applications Browser Go to Menu > Browser icon to use the internet. Press Options to enter a URL, create Bookmarks and to check your browsing history. File manager Go to Menu > File Manager icon. You can view all files saved in the phone or on the memory card. - Page 26 Press Options > Calendars to display and press Select on the calendar name. A tick should appear to left of the calendar Creating a new Event 1. Press Add to create a new calendar event. 2. Enter the event name and location. 3.
-
Page 27: Alarms
Alarms Go to Menu > Tools > Alarm to set an alarm. Alarms will switch the handset On even when it is switched off. World Clock Go to Menu > Tools > World clock to add a new world time location (City) Timer Go to Menu >... -
Page 28: Calculator
Calculator Go to Menu > Tools > Calculator On the Calculator screen, slide the screen to the right or left to switch between Advanced panel and Basic panel. -
Page 29: Technical Specifications
Technical Specifications Size and Weight 109 x 56.1 x 19.5 mm. 130g with battery Networks 4G LTE Band 1, 3, 7, 8, 28 LTE Data Rates: 150M Down / 50M Up 3G UMTS 850, 2100 MHz.HSPA+ 42Mbps data 2.8”,240 x 320 and 1.77” External display Display Camera 2MP Front camera on the flip... - Page 30 Charge 3-4 hrs with AC Charger Time Standby Up to 290 hours (subject to network) time Voice Up to 5 hours (subject to network) talk time Connectivity Bluetooth, 3.5mm jack NAHJ, micro USB, External RF port SIM Card Nano SIM, 4FF format.
-
Page 31: Faqs & Troubleshooting
FAQs & Troubleshooting Symptom Solution How do I check the Menu > Settings > About phone > Build number software version? How do I reset to Menu > Settings > Phone settings > Reset > Factory data factory defaults? reset How do I configure the Messages >... - Page 32 Symptom Solution Menu > Settings >Wireless & networks >Tethering and How do I enable USB mobile hotspot > USB tethering. (Connect as CDROM to tethering? install drivers) How do I configure Menu > Settings >Wireless & networks >Mobile Networks > APN‟s Access Point Names >...
- Page 33 Symptom Solution How do I change the Menu > Settings > Sound & notifications > Phone Ringtone Ringtone? Possible network coverage issue. Check the signal level. With only 1 or 2 bars, the battery has to work harder to The battery discharges maintain network contact.
- Page 34 Symptom Solution Turn Bluetooth on. Set visibility to Show. Make sure the I cannot connect to pass-code is correct. Possible compatibility issues. Not all other Bluetooth devices functionality is supported between different Bluetooth devices and standards. ERROR MESSAGES Message Solution Check a valid SIM card is inserted.
-
Page 35: Disposal Of Your Old Phone
Disposal of your old phone 1. When the wheelie bin symbol is attached to a product, it means the product is covered by the European Directive 2002/96/CE. 2. All electrical and electronic products should be disposed of separately from normal household waste via designated collection points provided by government or local authorities.
