Specifications
Model IVT-LBCBSHQ
Pick Up Element Sony 1/3" CCD
NTSC: 811x508
Effective Picture Elements
PAL: 795x596
Horizontal Resolution 540 TV Lines
S/N Ratio > 48 dB
NTSC: 19.0669
Clock Frequency
PAL: 19.3125
Scanning System 2:1 Interlaced
Minimum Illumination 0.01 Lux
Synchronous System Internal, negative synch
NTSC: 1/60 s - 1/100,000 s
Auto electronic shutter
PAL: 1/50 s - 1/100,000 s
Gamma characteristic 0.45
40 Meters (with 48 unit
IR Projection distance
infrared LEDs)
Iris Control Video/DC Iris
White Balance Auto
Back Light Compensation ON/OFF (Optional)
Video Output 1 Vpp, 75 Ω
Auto gain control Auto
Voltage/current 12 VCD (+/- 10%) / 400 mA
Lens C/CS Lens
Dimensions (mm) 112 x 64 x 55
Weight (g) 550
Storage Temperature -45 to +70 ºC
Operational Temperature -40 to +50 ºC
Packing List
Item
Name
Model
1
Auto-iris box color camera
IVT-LBCBSHQ
2
User guide
-
IntellView Technologies Inc.
808 - 55 Avenue NE
Calgary, AB, Canada T2E 6Y4
Phone: 1-403-338-0001
Toll Free: 1-888-922-9235
Fax: 1-403-374-0027
Sales: sales@intelliview.ca
Information: info@intelliview.ca
Support: support@intelliview.ca
#
1
1
IVT-LBCBSHQ
Auto-Iris Box
Color Camera
Auto-Iris Color Camera
Please read this user guide carefully
before powering up the camera.
Do not attempt to disassemble. If the
camera does not work, please contact
Intellivew
Advertisement
Summary of Contents for IntelliView IVT-LBCBSHQ
-
Page 1: Specifications
Specifications Model IVT-LBCBSHQ Pick Up Element Sony 1/3” CCD NTSC: 811x508 Effective Picture Elements PAL: 795x596 Horizontal Resolution 540 TV Lines S/N Ratio > 48 dB NTSC: 19.0669 Clock Frequency PAL: 19.3125 Scanning System 2:1 Interlaced Minimum Illumination 0.01 Lux... -
Page 2: Product Brief
Product Brief Setup Introduction Sensor (CCD) Congratulations on your purchase of IVT-LBCBSHQ auto iris box Adopts 1/3" High Resolution Color CCD Sensor. color camera. This user guide covers the IVT-LBCBSHQ series cameras. Auto Gain Control (AGC) Built-in auto gain control (AGC) circuit. The color This camera uses latest SONY sensor technology.
