Summary of Contents for Serafim Keybo

Page 3 Guideline...
Page 5: Table Of Contents
©Serafim Tech Inc. All rights reserved <Table of Content> 1. Package Contents........3 2. Overview..........3 3. Product Instruction........5 3.1 Mechanical Parts........5 3.1.1 Open Phone Stand......5 3.1.2 Close Phone Stand......7 3.2 Turning On..........8 3.3 LED Indicator........9 3.4 Bluetooth Connection......10 3.4.1 ..12 Pairing With HuaweiMobile Phone 3.5 Keyboard Setting......17...
Page 6 ©Serafim Tech Inc. All rights reserved 3.6.2 Android Google Play Link..19 3.6.3 Serafim Keybo APP Connection Guide... 3.7 Power Bank........23 3.7.1 About The Power Bank....23 3.7.2 Operation Mode......23 4. Framework Link........24 5. Troubleshooting........24 6. Safety Notes.........29 7. Product Specification......32 8. Legal............35 8.1 Copyright©........35...
Page 7: Package Contents
©Serafim Tech Inc. All rights reserved 1. Package Contents Thank you for purchasing Serafim Keybo, in this package you will find: Item Number of unit SerafimKeybo Micro USB cable Serafim Keybo Guideline 2. Overview Mobile Phone Stand Indicator Keyboard Projector...
Page 12: Turning On
3.2 Turning On Motion detector Step 1: Face up the Keybo then press and hold the power button (the arrow) as picture mention. Do not cover the motion sensor with your fingers. Step 2: The surface which Keybo is placed must be flat and the sensing area within the black square is clear.
Page 13: Led Indicator
©Serafim Tech Inc. All rights reserved 3.3 LED Indicator Left Right <Keyboard mode> Light Meaning Both in Red Charging. Both Blinking in Low Battery Warning. Both Blinking in Waiting for Bluetooth connection. Blue Both Breathing in Bluetooth connected. Blue L: Red...
Page 14: Bluetooth Connection
©Serafim Tech Inc. All rights reserved <Power Bank mode> Light Battery Percentage(%) Green Blue Blinking in Red Low Battery Warning 3.4 Bluetooth Connection <Android System> Step 1: Turn on Bluetooth. Step 2: Select and pair with Serafim Keybo.
Page 16: Pairing With Huaweimobile Phone
©Serafim Tech Inc. All rights reserved 3.4.1 Pairing With Huawei Mobile Phone Step 1: Download "Bluetooth Auto Connect" on Google play store. Step 2: Launch "Bluetooth Auto Connect" APP then select "Profiles".
Page 21: Keyboard Setting
©Serafim Tech Inc. All rights reserved 3.5 Keyboard Setting 3.5.1 Hotkeys Fn +F1: Reduce screen brightness (For MacOS) Fn +F2: Increase screen brightness (For MacOS) Fn +F3: Mission Control (For MacOS) Fn +F4: Launchpad (Require for first time user) Fn +F5: Reduce projection brightness...
Page 22: Ios Caps Lock Issue
©Serafim Tech Inc. All rights reserved 3.5.2 iOS Caps Lock Issue When user wishes not to switch language with "Caps Lock", please go to: Setting General Keyboard Hardware Keyboard Disable Caps Lock Latin Switch...
Page 24: Serafim Keybo App Connection Guide
©Serafim Tech Inc. All rights reserved 3.6.3 Serafim Keybo APP Connection Guide Step 1: Launch the Serafim Keybo APP. Step 2: Select "Connect to Serafim Keybo" to enter piano mode.
Page 25 ©Serafim Tech Inc. All rights reserved Step 3: Pairing with Keybo( Window will not appear if Keybo already connected). Step 4: Into Piano Mode, swipe red window in the middle or on the piano projection to change scale.
Page 27: Power Bank
Slow Not iOS Charging Only Note: Keybo will STOP charging itself while in power bank mode. Also, when the side USB is plug- in, Keybo only provides slow charging mode to your device. Therefore, do not use the power bank...
Page 28: Framework Link
1. I cannot switch my projection language by press "Fn+L". The "Fn + L" function only belongs to bilingual Keybo. (e.g .: English + Japanese). 2. I cannot switch my phone's input language. You can switch phone's input language by pressing "Caps"...
Page 29 Keybo will enter breathing mode to save power if not use for a while. Press any key to exit the breathing mode. 4. How do I know that Keybo has finished charging? Keybo will turn off both LED indicators as the sign of fully charged.
Page 30 6. Key has been triggered before I pressed. Keybo's sensing system senses 1 mm above the desk surface. Therefore, some key will trigger before you pressed. 7. Is it possible to change hotkey setting, so I can press "Play"...
Page 31 Other Settings Chats Tick Send messages with return key 10. My Keybo is fully charged, but when I use Keybo's Power Bank function on my tablet, both LED indicates Low Battery Warning light. Why is that? Keybo will adjust its LED indicator according...
Page 32 Keybo is still able to charge your device but only provides limited power 11. Can I charge both Keybo and phone at the same time by plug-in side USB and turn on Keybo's power bank mode?
Page 33: Safety Notes
©Serafim Tech Inc. All rights reserved 13. Why is full speed charge mode only enabling when the total power is higher than 75%? The Power Bank function is designed for purposes of emergency use without affecting projection function. Therefore the 75% limited is set.
Page 34 Please keep the product's sensor away from direct low-color temperature lightings, such as halogen and incandescent lamp. Avoid placing any objects in the space between Keybo and the laser projection image.
Page 35 11. The charging time of the battery may vary depending on the environment and temperature. 12. Even thought Serafim Keybo has shown it had been fully charged, the embedded battery may not be charged to 100%. 13. Notice the risk of malfunction if used in an environment with drastic temperature change, high humidity or high-pressure environment.
Page 36: Product Specification
©Serafim Tech Inc. All rights reserved 7. Product Specification <Pattern Projector> Item Specification Light Source Red Laser Diode QWERTY Keyboard Layout Keyboard 24keys (14 white,10 black) Layout Piano Keyboard Layout Arabic Chinese Support English Projection French Keyboard German Language Spanish...
Page 37 ©Serafim Tech Inc. All rights reserved <Keyboard Sensor> Item Specification Light Source IR Laser Diode Recognition Approx. up to 350 characters Rate per minute Operating Any firm flat surface Surface <Electrical Characteristics> Item Specification Side External USB Power/ 5V 500mA Power Supply Battery &...
Page 38 ©Serafim Tech Inc. All rights reserved Frequency 2402 ~ 2480MHz Range Channels Modulation GFSK <Environmental Conditions> Item Specification Operating 10℃ ~ 40℃ Temperature 85%RH Storage -25℃ ~ 75℃ Temperature 85%RH <Dimensions and Weight Specifications> Item Specification Size (mm) 48mm×45mm×77mm Weight (g)
Page 39: Legal
©Serafim Tech Inc. All rights reserved 8. Legal 8.1 Copyright© © Serafim Tech. Inc. All rights reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or any without the express written permission of Serafim Tech.
Page 40: Fcc Notices
©Serafim Tech Inc. All rights reserved 2. In all cases, the commencement date for the period is one year since the actual day of purchase, as reflected on the authorized reseller's or distributor's invoice/receipt provided to you. 8.3 FCC Notices This device complies with Part 15 of the FCC Rules.
Page 41 ©Serafim Tech Inc. All rights reserved harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be...
Page 42 ©Serafim Tech Inc. All rights reserved RF exposure warning: The equipment complies with FCC RF exposure limits set forth for an uncontrolled environment. The equipment must not be co-located or operating in conjunction with any other antenna or transmitter. This...
Page 43 SVK-01A 使用說明書...
Page 44 ©Serafim Tech Inc. All rights reserved 〈目錄〉 1. 包裝內容物 ..........42 2. 產品概觀 ..........42 3. 產品使用說明 ........44 3.1 產品機構 ..........44 3.1.1 打開支撐架 ........44 3.1.2 收合支撐架 ........46 3.2 開機啟動 ...........47 3.3 指示燈號 ..........48 3.4 藍牙連接 ..........49 3.4.1 華為手機配對 .......51 3.5 鍵盤設定 ..........56 3.5.1 快捷鍵...
Page 45 ©Serafim Tech Inc. All rights reserved 3.6.2 Android Google Play 下載 ..58 3.6.3 Serafim Keybo APP 連線說明 ...59 3.7 行動電源 ...........62 3.7.1 規格 ..........62 3.7.2 運作模式 ........62 4. 技術開源包下載 ........63 5. 疑難排解 ..........63 6. 安全與維護 ..........68 7. 產品規格 ..........70 8. 注意事項 ..........73 8.1 版權聲明...
Page 60: 鍵盤設定
©Serafim Tech Inc. All rights reserved 3.5 鍵盤設定 3.5.1 快捷鍵 Fn ＋ F1：降低顯示器亮度 ( 適用於 Mac 電腦 ) Fn ＋ F2：提高顯示器亮度 ( 適用於 Mac 電腦 ) Fn ＋ F3：Mission Control ( 適用於 Mac 電腦 ) Fn ＋ F4：Launchpad ( 初次使用須自行設定 ) Fn ＋...
Page 66: 行動電源
3.7 行動電源 3.7.1 規格 Keybo 內建 3.7V 2000mAh 電池，在電池處於滿電狀態及不影響投影鍵盤正常運作之下，可以幫手機充滿 1000mAh 的電量，換算成 3000 mAh 電量的手機，可以充滿百分之 30 的電量。另外，因為 Keybo 內建電池容量較小，能提供的電量有限，並不建議拿 Keybo 來充平板電腦。 3.7.2 運作模式全速慢速側邊系統...
Page 67: 技術開源包下載
©Serafim Tech Inc. All rights reserved 4. 技術開源包下載 https://goo.gl/qg54to 5. 疑難排解 1. 按下“Fn+L”無法切換投影語系？ “Fn+L”的功能只屬於購買雙語系鍵盤（e.g. ：中文＋日文）的 Keybo 才能使用。 2. Keybo 沒辦法切換輸入的語言 ? 所輸入的語言和手機使用的輸入法有關，Apple 系列產品是按“Caps”做切換，Android 系統的產品由於輸入法眾多，使用者可嘗試以下組合切換：...
Page 68 ©Serafim Tech Inc. All rights reserved Shift Shift ＋ Space Shift ＋ Ctrl Ctrl ＋ Space 3. Keybo 投射後會一閃一滅 ? 當一段時間沒有使用 Keybo 會進入呼吸省電狀態。省電模式下只要按下任意按鍵，Keybo 就會回復到一般模式。 4. 充電完成沒有提示 ? 在關機充電時，Keybo 指示燈會顯示雙紅燈，當電池充飽電時，燈號會熄滅即為充飽電時的提示方式。 5. 按鍵會飄，會連發；按鍵失效沒有作動； Fn 按鍵感應不良？請確認是否有東西遮擋到了按鍵，或是...
Page 69 ©Serafim Tech Inc. All rights reserved 請將 Keybo 面向空曠處重新啟動。因為 Fn 鍵在角落的關係，感應會比中心位置的按鍵略差一點，並非商品有瑕疵。 6. 按鍵還沒按下就已經觸發？由於 Keybo 感測系統是在桌面上方約１ mm 的位置進行感測，所以部分按鍵會發生沒按到桌面就觸發的情形。 7. 觀看影片時，可否更改設定，不用加 Fn 就可按 play ？目前投影鍵盤的設定是依照傳統...
Page 70 ©Serafim Tech Inc. All rights reserved 9. 使用 Keybo 時，Line App 輸入完按投影的 Enter 沒有辦法直接傳送訊息呢？請至 Line 裡的設定做更改：其他設定聊天打勾“以換行鍵傳送” 10. Keybo 電量完全充滿並接上平板後， Keybo 卻出現電量低的閃爍紅燈警告？ Keybo 的電池容量小，在跟其他充電裝置連接後會依照其他裝置的電量做燈號的調整，Keybo 依然可以幫您的裝置充電，但能提供的電量有限。...
Page 71 ©Serafim Tech Inc. All rights reserved 11. 插入側邊 USB 並且 Keybo 在行動電源模式下，手機跟 Keybo 卻越充越沒電？行動電源模式下側邊 USB 充電功能是關閉的，並且 Keybo 只會開啟行動電源的慢速充電模式，不建議在側邊 USB 連接的情況下使用 Keybo 行動電源功能。 12. 手機插上去後過很久 Keybo 才進入行動電源模式？各家手機廠商的充電模式不同，在不影響虛擬投影鍵盤功能的情況下，Keybo 需要花一點時間偵測你的裝置是否有插入。 13. 為什麼 AC 全速充電模式只有電量高...
Page 72: 安全與維護
©Serafim Tech Inc. All rights reserved 6. 安全與維護請避免將本產品長時間曝曬於直射陽光下，且遠離熱源。若產品使用於溫度急劇變化的場所，則存在故障的風險。過度用力或撞擊本產品可能會導致產品損壞且導致保固失效。為確保安全並防止損壞，請使用本產品提供的 Micro USB 連接線。請勿嘗試拆卸或自行維修本產品，如此做可能導致觸電且造成保固失效。本產品屬於 Class Ⅰ一類雷射產品 , 經美國 FDA 安全法規認證。為了您的安全，請勿直視雷射光源，如此做可能會傷害您的眼睛。...
Page 73 ©Serafim Tech Inc. All rights reserved 請避免在本機與雷射投影圖像之間的空間內放置任何物品。請勿在不平整或不規則的表面上使用本產品。 10. 請將本產品置於平坦的平面上並避開透射或反射（e.g. 玻璃或鏡子）。 11. 電池的充電時間可能會因不同的環境，溫度而略有增減。 12. 電池可能無法充電至 100％的額定電池容量，即使 Serafim Keybo 燈號顯示已充電完成。 13. 於高溫、潮溼與高壓環境下使用或充電，可能會引起電池爆炸。 14. Keybo 內部電池的儲電容量會隨著時間的推移而自然遞減。...
Page 75 ©Serafim Tech Inc. All rights reserved 〈動作感測〉物件規格光源紅外光雷射二極體鍵盤辨識率約 350 個字元一分鐘投影運作平面任何平坦的平面〈電器特性〉物件規格側邊外部 USB 電源 / 5V 500mA 電源供應介面鋰電池離子電池電池規格 3.7V / 2000mAH(MAX) 電池運作時間投影模式下最多 10 小時電池充電時間約 300 分鐘...
Page 77: 注意事項
©Serafim Tech Inc. All rights reserved 8. 注意事項 8.1 版權聲明 © Serafim Tech. Inc. All rights reserved. 碩擎科技股份有限公司保留所有權利，未經碩擎科技股份有限公司（以下簡稱「碩擎科技」）許可，不得任意地抄襲、轉譯或為其他利用。本使用說明書更新的詳細說明請您造訪碩擎科技的客戶服務網：http：...
Page 78: 使用警語
©Serafim Tech Inc. All rights reserved 8.3 使用警語 FCC Notices This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 79 ©Serafim Tech Inc. All rights reserved antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help.
