Lantech N-KEY Operating Manual

Configuration auto backup, auto upgrade and restore tool
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Operating Guide of N-KEY
Latest update: Jan 2018
Version: 1.00
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the N-KEY and is the answer not in the manual?

Questions and answers

Summary of Contents for Lantech N-KEY

  • Page 1 Operating Guide of N-KEY Latest update: Jan 2018 Version: 1.00...

  • Page 2: Important Notice

    Lantech N-Key – Operating Guide Ver1.00 Important Notice Lantech Communications Global, Inc. reserves the right to modify the equipment, its specification or this manual without prior notice, in the interest of improving performance, reliability, or servicing. At the time of publication all data is correct for the operation of the equipment at the voltage and/or temperature referred to.

  • Page 3: Hardware Installation

    1. Hardware installation There are 3 ways to supply power to N-Key 1.1 PoE 1.2 Power adapter 1.3 USB connection...
  • Page 4 Lantech N-Key – Operating Guide Ver1.00 2. Definition of DIP switch of N-Key Set DIP1 as ON position , N-Key will change to USB dongle mode. Set DIP2 as OFF position, N-Key will be able to upgrade firmware/configuration import/configuration export.

  • Page 5: Led Status

    Lantech N-Key – Operating Guide Ver1.00 3. LED Status LED 1 : Power Indicator On: power Off: no power LED 2 : Status 1 Red Blinking: waiting Green : status ready LED 3 : Status 2 Orange: In transferring process...
  • Page 6 4.2.2 Connect N-Key with desktop directly or via extension cable 4.2.3 Copy new firmware into N-Key 4.2.4 Connect N-Key with switch via Ethernet connection, make sure the first LED is green and the other 2 LEDs are all green. (If the switch doesn’t support PoE function, please make sure you have connected external power with N-Key.)
  • Page 7 4.3.4 When 3 LED change to green , it means the backup job has done. 4.3.5 Change N-Key to USB Dongle mode and connect with desktop, you will find the backup configuration file as below picture, the “cfgexport” means exporting configuration file and 286046123456 is the MAC address of switch which can let you manage lots of backup files from different witches.
  • Page 8 Lantech N-Key – Operating Guide Ver1.00 4.4.5 When 3rd LED change to green , it means the backup job has done. The switch will reboot automatically. http://www.lantechcom.tw Technical Assistance Please contact us directly to reach our technical support team: Telephone: +886-2-2799-5589 E-mail: support@lantechcom.tw...
