- Page 1 πλ² Synthesizer Manual for Assembly Kit Features 2 Oscillators 4 Waveforms 32 Presets 32 User presets Specifications Power supply: +5V DC/50mA Dimensions: 100 x 100 x 23mm...
- Page 2 Congratulations on purchasing our PL2 Synthesizer assembly kit! For a successful and effortless assembly of our product, please read the following instructions carefully! 1. The right equipment Before you start, make sure you have the right tools. We suggest the following: ...
- Page 3 Once you have completed the assembly process, please check that the components on the PCB have all been placed as required and that the polarity is correct. 3 Assembly Manual for PL2 Synthesizer...
- Page 4 On the blank bottom side of the PCB which is now facing you, carefully solder the leads to the PCB. Once the new solder joints have cooled and hardened, you can trim excess leads close to the solder joints. 4 Assembly Manual for PL2 Synthesizer...
- Page 5 4.3 LED ● LED1 Please check for the correct polarity of these component. 4.4 Voltage regulator Please check for the correct polarity of these component. 4.5 Crystal 5 Assembly Manual for PL2 Synthesizer...
-
Page 6: Bill Of Materials
Brown, black, black, red, brown Brown, red, black, red, brown Violet, green, black, brown, brown Brown, green, black, red, brown Brown, green, black, red, brown Violet, green, black, brown, brown Violet, green, black, brown, brown 6 Assembly Manual for PL2 Synthesizer... - Page 7 - ( Jumper ) - ( Jumper ) 100pF 100pF 100pF 100nF 5.3 Electronic capacitors (see section 4.2 of this manual) Part Value Marking 22µF 22µF16V 22µF 22µF16V 10µF 10µF16V 10µF 10µF16V 22µF 22µF16V 22µF 22µF16V 7 Assembly Manual for PL2 Synthesizer...
- Page 8 5.4 Other components (see sections 4.3 - 4.8 of this manual) Part Value Marking M EGA8515 ATM EGA8515L8PU 74AHC04N SN74AHCU04N TS2950CT-3.3 TSC295033 6,3mm jack socket J101 J102 LED1 LED 5mm green CNY17 CNY17-3 8M Hz 8.0000M Hz Potentiometer 50K USB connector M IDI connector 8 Assembly Manual for PL2 Synthesizer...
- Page 9 Colour codes of resistors 9 Assembly Manual for PL2 Synthesizer...
- Page 10 Layout 10 Assembly Manual for PL2 Synthesizer...
- Page 11 11 Assembly Manual for PL2 Synthesizer...
-
Page 12: Important Notes
Original PL2 Synthesizer. Ploytec GmbH refuses to follow any claims for warranty which have been caused by abnormal handling. Repair services are NOT offered. Operation A USB power supply is needed for operating your assembled PL2 Synthesiser. (Despite the...
