JetWave 4110L
Industrial Lora Gateway
User Manual
V1.1 Oct. 2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the Korenix JetWave 4110L and is the answer not in the manual?

Questions and answers

Summary of Contents for BeiJer Korenix JetWave 4110L

  • Page 1 JetWave 4110L Industrial Lora Gateway User Manual V1.1 Oct. 2019...
  • Page 2 JetWave 4110L LoRa Gateway User Manual LoRa 1. Install USB Driver. 1.1 CP210xVCPInstaller_x86.exe: For Windows XP、Vista、win7 32bits. 1.2 CP210xVCPInstaller_x64.exe: For Windows Vista、Win7、Win8 64bits. 2. Copy all files in the "Program Tool" folder in your PC. (WW_BOX_LoRa.exe / SLABHIDDevice.dll / SLABHIDtoUART.dll). 3.
  • Page 3: Icon Introduction

    JetWave 4110L LoRa Gateway User Manual Program Tool (WW_BOX_LoRa.exe) Icon Introduction Read setting from device Write setting to device Back to All setting list Continuous writing device from setting parameter file(*.par)
  • Page 4: Menu Introduction

    JetWave 4110L LoRa Gateway User Manual MENU Introduction File Menu Open… Open a setting parameter file (*.par) Save Save the setting parameter file Save As… Save all settings as another parameter file Read Device Read setting from device Write Device Write all settings to device Main MCU Bootloader Main MCU entry to Firmware Update Mode DIO MCU Bootloader DIO board MCU entry to Firmware Update Mode Exit Exit the program...
  • Page 5 JetWave 4110L LoRa Gateway User Manual Execute WW_BOX_LoRa.exe Press Read setting from device and select the correct COM port and BaudRate(You can ignore BaudRate and the system will automatically search for you). 1. Read setting list from device as below.
  • Page 6: Device Information

    JetWave 4110L LoRa Gateway User Manual All Setting List Device Information JetWave4110L All device information is shown on on the Device Information page. Model Number This item is product model number Firmware Main Firmware Version Hardware Main Hardware Version PCODE Product CODE for factory use Firmware (RF) RF Firmware Version Hardware (RF) RF Hardware Version PCODE (RF) RF Product CODE for factory use...
  • Page 7: Bandwidth (Khz)

    JetWave 4110L LoRa Gateway User Manual Device Setting ※Noted that: All devices are identical in the setting of frequency and RF BitRate. All device settings are shown on as follows. Frequency (Hz) Setting transmit and receive frequency, the frequency range is 410MHz to 525MHz / 862MHz to 1020MHz.
  • Page 8 JetWave 4110L LoRa Gateway User Manual and Bandwidth. RS-485 / RS-232 Baudrate (bps) The Baudrate setting from 4800, 9600, 19200, 38400, 57600, 115200, 230400. RS-485 Address Setting the RS-485 device address(1~255). Modbus RTU Data Filter Function Check the box to enable Modbus RTU data filter function. This function will be checked the RS-485 address and Modbus RTU checksum.
  • Page 9 JetWave 4110L LoRa Gateway User Manual RF Packet Setting ※Noted that: All devices are identical in the Sync. word value to link. Page 9...
  • Page 10 JetWave 4110L LoRa Gateway User Manual Receive Packet Setting Address base filtering Broadcast / Node / Group, Broadcast / Node, Broadcast / Group, Node / Group, Broadcast only, Node only, Group only Node address 1~255 ※Own Address Group address 1~255 ※Own Address Transmit Packet Setting Target address Type Broadcast, Node, Group Node address 1~255 ※Node address of the destination (receiver)
  • Page 11 JetWave 4110L LoRa Gateway User Manual ModBus RTU setting Install “WW_ModBus_RTU” tool. For more ModBus setting. Page 11...
  • Page 12 JetWave 4110L LoRa Gateway User Manual Install “WW_P_CMD_Tool” tool. For more ModBus setting. Page 12...
  • Page 13 JetWave 4110L LoRa Gateway User Manual Register Address Mappings Address Description Attribute 0x3000 REG_DI_VAL_1: DI(AI) #1 Detection value (03H) 0x3001 REG_DI_VAL_2: DI(AI) #1 Detection value (03H) 0x3002 REG_DI_VAL_3: DI(AI) #2 Detection value (03H) 0x3003 REG_DI_VAL_4: DI(AI) #3 Detection value (03H) 0x3004 REG_DI_VAL_5: DI(AI) #4 Detection value...
  • Page 14 JetWave 4110L LoRa Gateway User Manual 0x3020 REG_DIO_EXCEP_STATUS: DIO Abnormal state (03H) 0x3021 REG_POWER_ELECTRICITY: Main power (mV) (03H) 0x4000(~0x4001) REG_DIO_ALL_PAR_1: R/W*** DIO#1 All parameter (03H/10H) 0x4002(~0x4003) REG_DIO_ALL_PAR_2: R/W*** DIO#2 All parameter (03H/10H) 0x4004(~0x4005) REG_DIO_ALL_PAR_3: R/W*** DIO#3 All parameter (03H/10H) 0x4006(~0x4007) REG_DIO_ALL_PAR_4: R/W*** DIO#4 All parameter...
  • Page 15 JetWave 4110L LoRa Gateway User Manual DIO#2 DI(AI) parameter (03H/06H) 0x4024 REG_DIO_ DI _PAR_3: DIO#3 DI(AI)parameter (03H/06H) 0x4026 REG_DIO_ DI _PAR_4: DIO#4 DI(AI)parameter (03H/06H) 0x4028 REG_DIO_ DI _PAR_5: DIO#5 DI(AI)parameter (03H/06H) 0x4030 REG_DIO_DO_PAR1_1: DIO#1 DO parameter1 (03H/06H) 0x4031 REG_DIO_DO_PAR2_1: DIO#1 DO parameter2 (03H/06H) 0x4032 REG_DIO_DO_PAR1_2:...
