Summary of Contents for Scootacar Comfi-Car
-
Page 1: User Manual
User Manual Scootacar Limited Rayford House, School Road Hove BN3 5HX email: info@scootacar.co.uk website: scootacar.co.uk Ó Scootacar Limited 2019... -
Page 2: Table Of Contents
Part Diagram 4 - 6 Riding Instructions 7 - 9 Operating Instructions 10 - 11 The Battery 11 - 13 Technical Data 14 - 15 Maintenance and Troubleshooting 16 – 17 Service Engineer Checklist Ó Scootacar Limited 2019 Comfi-Car User Manual... -
Page 3: Introduction
Introduction Thank you for purchasing your Scootacar mobility scooter. Designed to provide Comfi-Car you with years of trouble-free, comfortable, quiet, and eco-friendly service. Your Comfi-Car mobility scooter has been equipped with the latest technologies that assist in providing you with the most efficient and comfortable ride you’ve ever felt. We recognise the importance of... -
Page 4: Part Diagram
This is especially true of the electrical systems and the mechanical components. 1. Wing/ Rear View Mirror 2. Windscreen Wiper 3. Headlights 4. Front Indicators 5. Front Wheel(s) 6. Footrest 7. Rear Wheel(s) 8. Anti-tip Wheels 9. Door Handle 10. Rear Lights Ó Scootacar Limited 2019 Comfi-Car User Manual... - Page 5 High Speed / Low Speed switch - When set to L you are in low speed mode, when set to H you are in high speed mode. Ó Scootacar Limited 2019 Comfi-Car User Manual...
- Page 6 Comfi-Car Brake Light Indicator - When this light is on your brakes are activated. Left Turn Indicator - When this light is on this means you left hand indicator is flashing. Ó Scootacar Limited 2019 Comfi-Car User Manual...
-
Page 7: Riding Instructions
Comfi-Car mobility scooter has. To turn off the Comfi- mobility scooter, simply turn the key to the left and remove the key. Warning Ó Scootacar Limited 2019 Comfi-Car User Manual... -
Page 8: Safety Tips
Drive on an incline with oil, water, or ice on it. • Use parts or accessories that are not authorised. • Connect medical devices to the battery. On the Road Please adhere to the following recommendations to ensure your safety. DO NOT Ó Scootacar Limited 2019 Comfi-Car User Manual... - Page 9 Below 10 degrees Celsius, the battery will not work as well as it would in warmer temperatures. Riding the mobility scooter in cold temperatures may require you to replace the Comfi-Car battery sooner rather than later. Ó Scootacar Limited 2019 Comfi-Car User Manual...
-
Page 10: Operating Instructions
Operating Instructions Getting Started Before the first use, you must charge your Comfi-Car mobility scooter completely. This should take approximately 8 to 14 hours. Getting in/Out Before getting in or out of your Comfi-Car mobility scooter, always make sure that the keys... -
Page 11: The Battery
Please see the section titled “Your Battery” for instructions on battery maintenance while your Comfi-Car mobility scooter is being stored. You may prefer to contact your local Scootacar retailer to immobilise and Comfi-Car disconnect the battery to ensure it is shut down safely and properly for future use. - Page 12 5. This should be a 240v household electricity supply. You can also use a portable generator, if necessary, but make sure it provides 240v current. 6. Allow your Comfi-Car mobility scooter batteries to charge for the appropriate amount of time (8-14 Hours) Ó Scootacar Limited 2019 Comfi-Car User Manual...
- Page 13 Your battery contains significant amounts of electrical power. Do not handle your battery if either you or the battery are wet. Water is an excellent conductor of electricity. You may experience an electrical shock and you may be injured Replacement and Disposal Ó Scootacar Limited 2019 Comfi-Car User Manual...
-
Page 14: Technical Data
Battery Statistics Voltage: 24V240AH Electrical System Statistics Motor Statistics Rated Power: 1400W Max. Climbing Angle: 12 degrees Charger Statistics Charger type: 24V-8AH Charger Input: AC 100 – 240V Standard Input voltage: 110V +/- 10% Ó Scootacar Limited 2019 Comfi-Car User Manual... -
Page 15: Wiring Diagram
Max Climbing slope: 12 degrees Ground Clearance: 110 mm Turning circle: 1.50m Motor power: 24v 1400W Batteries: 12V 75Ah x 2 Controller: 24V PG 200A Battery Charger Output: 24VDC/ 8A Brake type: Regenerative Electro-Mechanical Ó Scootacar Limited 2019 Comfi-Car User Manual... -
Page 16: Maintenance And Troubleshooting
‘Loc-tite’ or a similar adhesive. When changing a tire, the inner tube must be deflated. Remove the four bolts from the wheel and split the rim. It may be easier and safer to have the tubes replaced by your dealer. General Maintenance Ó Scootacar Limited 2019 Comfi-Car User Manual... - Page 17 The unit is switched on All plugs and connectors are firmly fixed Battery is fully charged Free-Wheel lever is engaged Fuses are not blown Check Fault Codes Fuse Panel Ó Scootacar Limited 2019 Comfi-Car User Manual...
- Page 18 Ó Scootacar Limited 2019 Comfi-Car User Manual...
-
Page 19: Service Engineer Checklist
Correct all defects found and required. determine if vehicle is roadworthy. Tiler adjustment – operation, wear Final Road Test & damage. Clean the vehicle. Handlebar alignment – adjust as necessary. Customer Road Test. Ó Scootacar Limited 2019 Comfi-Car User Manual...
