Page 1: Table Of Contents
1000F LED light for broadcast, photo, and video studios TABLE OF CONTENTS Marking 1. Introduction 2. Safety precautions 3. Specifications 4. Components and accessories 5. Control panel 6. Operating instructions 7. Warranty... -
Page 2: Introduction
This guide provides information on how to use the product functions to get the full effect and benefits of the Aurora 1000F light, as well as warnings on its use. The Aurora 1000F is designed for professional use, for interior locations or studio and must only be operated by qualified technical personnel. -
Page 3: Specifications
3. Specifications Features HIGH LIGHT OUTPUT Utilizing high efficient LED chips, Aurora 1000F features 2,890 lux at a 1m distance with a beam angle of 109.8°. Brightness achieved reaches 1kW of conventional light, whilst consuming 85% less electricity. CUTTING AND SHAPING 4-way barn doors are supplied and also a slot for gel-frame insertion is equipped at the front. -
Page 4: Photometric Data
Dimensions 54.7cm 15.1cm 15.1cm 54.7cm 29.7cm Photometric Data Beam Width : 0.73 m 35573.25 lux in center 11725.20 lux in side 0.30 m Beam Width : 1.45 m 8893.31 lux in center 2931.30 lux in side 0.60 m Beam Width : 2.18 m 3952.58 lux in center 1302.80 lux in side 0.90 m... -
Page 5: Components And Accessories
4. Components and accessories Broadcast version 1. 4-leaf barndoor (included, not removable) 4. Front screen 2. Gel insertion frame 5. Security cable 3. Lock for gel filter 6. Tightening knob for manual yoke PUSH 7. Control panel with 5-pin DMX in port and out port 10. - Page 6 13. Pole-operated yoke (optional accessory) 15. Adjustment bell-handle for tilting 14. Adjustment bell-handle for panning 16. Clamp (optional accessory) Photo version 1. 4-leaf barndoor (included, not removable) 4. Front screen 2. Gel insertion frame 5. Security cable 3. Lock for gel filter 6.
- Page 7 Model : aurora 1000F Input power : 90~240V,50/60Hz Power consumption : 150W±10% Color temp : Warm Cool Made in Korea USE ONLY WITH A 250V FUSE AC INPUT FUSE POWER VOLUME 7. Control panel with no DMX ports 10. 5m power cord attached (removable) 8.
-
Page 8: Control Panel
Up and Down buttons are for power increments when a DMX console is disconnected, and for channel control when a DMX console is connected. Photo version Model : aurora 1000F Input power : 90~240V,50/60Hz Power consumption : 150W±10% Color temp :... -
Page 9: Operating Instructions
6. Operating Instructions 1) Mounting to a light stand or hanging to a ceiling system Mounting on a light stand Place the unit on to a light stand and fix it, using tightening screw as shown in the picture. Hang to a ceiling system Insert 3/8”... - Page 10 Next to the DMX IN there is also a DMX OUT connector to daisy-chain fixtures. Address channels To address channels for the 1000F units, just push the UP or DOWN buttons to increase or decrease the channel. The chosen channel number will be displayed at the window for 10 sec and then disappear automatically.
- Page 11 Pole-operated yoke Pole-operated yoke enables user to tilt and pan the unit without climbing up a ladder. To tilt downward, rotate the grey bell anticlockwise with or without using a pole. To pan the light clockwise, rotate the blue bell anticlockwise with or without using a pole.
-
Page 12: Warranty
- Submergence in water (flooding), exposure to alcohol or other beverages, infiltration of sand or mud, physical shock, or dropping of the equipment and other unnatural causes. This warranty only applies to the 1000F and not to the accessories, such as the barn doors, nor does it apply to fuses and other consumables provided.
