CONNECTIONS
1. Connect the output of your sound source (CD player, mixer signal, sound card) to the Input -6- of the ADM-Sub.
2. Now connect the ADM-Sub Output -5- to your further speakers.
3. Connect the mains connection -8- to the mains cable and then to your power outlet.

OPERATION

1. Volume dial in minimum position
Before operating the device, make sure to bring the volume dial -1- in the minimum position (all the way to the left).
2. Turning on power
After all connections have been carried out, turn on the device via the Power Switch -7-.
3. Volume control
Adjust the volume via the corresponding dial -1-.
4. Crossover
Via the crossover dial -2- you can determine which frequencies the sub should reproduce.
5. The more the crossover dial is turned to the right, the higher the frequencies are that are reproduced by the subwoofer.
6. Phase Cancellation
If a frequency cancellation should occur due to same phases, the phase relation can be reversed by using the phase button -3-.
7. Power Mode
The ADM-Sub disposes of 3 different power modes.
To keep the sub turned on constantly, put the select switch -4- all the way to the left (ON).
In the middle position (AUTO), the subwoofer will go off automatically when not in use.
As soon as a signal above 10mV is received, the subwoofer will turn on automatically.
In the OFF position the input signal will be routed to your further connected speakers. In this case the ADM-Sub is not active.

TECHNICAL SPECIFICATIONS

Type: ................................................. Active Subwoofer
Speaker Size: .................................. 6.5 inches
Rating Power: ................................. 45 W
Dynamic Power: ............................. 50 W
Crossover Slope: ............................ -12 dB/Oct
Frequency Response: .................... 50 – 150 Hz
Input Sensitivity: ............................ 120 mV
Weight: ............................................. 8.0 kg
Dimensions: ..................................... 450 x 310 x 345 mm
