DIAMOND CENTOR LED Bunker Installation Guide
WARNING：
-THE LIGHT SOURCE OF THIS LUMINAIRE IS NOT REPLACEABLE;WHEN THE LIGHT SOURCE REACHES
ITS END OF LIFE, THE WHOLE LUMINAIRE SHALL BE REPLACED.
-THE LIGHT SOURCE CONTAINED IN THIS LUMINAIRE SHALL ONLY BE REPLACED BY THE
MANUFACTURER OR HIS SERVICE AGENT OR A SIMILAR QUALIFIED PERSON.
-THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN.
-THE POWER SUPPLY MUST BE TURNED OFF BEFORE INSTALLATION.
-NO WARRANTY WILL BE ACCEPTED IF THIS PRODUCT IS NOT INSTALLED BY A QUALIFIED
ELECTRICIAN.
-AC INPUT WIRE SPECIFICATIONS: 1.5MM
-THE DRIVER CAN'T BE REPLACED AND IS SUITABLE FOR OPERATION WITH LED MODULES ONLY.
COH-CEN-9-26FW
Net Weight
2
Remove from package. Remove four screws from
the outer cover ring and remove outer cover from
the base.
2
COH-CEN-18-35FB
9W
100-240VAC
100-240VAC
50/60Hz
90mA
50
1.28KG
IP65
18W
50/60Hz
185mA
50
2.03KG
3
Cut grommet to suit the outside diameter of the
input power cord.
1.Disconnect mains supply before
installation or removing cover.
Advertisement
Table of Contents
Summary of Contents for Soitec COH-CEN-9-26FW
