Summary of Contents for Simons Voss Technologies 3061 VdS
- Page 1 Digital Locking Cylinder 3061 VdS State of: June 2006...
-
Page 2: Table Of Contents
Digital Locking Cylinder 3061 VdS Page 2 Method of Operation __________________________________3 General Information ______________________________________ 3 Opening and Locking From Outside_________________________ 3 Opening and Locking From Inside __________________________ 3 Special Models _______________________________________4 FH Version ______________________________________________ 4 Overview _______________________________________________ 4 Additional Functions __________________________________4... -
Page 3: Method Of Operation
The cylinder does not couple, however, and you cannot open the door. Opening and Locking From Inside It is always possible to open doors with Digital Locking Cylinder 3061 VdS devices from the inside without operating the transponder... -
Page 4: Special Models
Digital Locking Cylinder 3061 VdS Page 4 Special Models The standard Digital Locking Cylinder 3061 VdS is equipped as a PLUS version, which means that the following functions are always included: Access logging The locking cylinder stores the last 128 accesses with date, time and the user name of the transponder. -
Page 5: Logging Unauthorized Access Attempts
Digital Locking Cylinder 3061 VdS Page 5 Logging Unauthorised Access Attempts For cylinder version 10.2 and later and in combination with the LDG Version 1.40, it is possible to log unauthorised access attempts, as well as authorised accesses. This includes both access attempts without authorisation and access attempts outside the specified time zone. -
Page 6: Transponder
Digital Locking Cylinder 3061 VdS Page 6 Transponder If the transponder battery voltage is coming to an end, eight short signal tones, coming quickly one after another, sound each time the transponder is operated on the locking cylinder after the uncoupling. -
Page 7: Installation Instructions
Digital Locking Cylinder 3061 VdS Page 7 Fix the lock nut in position with the special tool and press it against the flange. Now turn the inner knob onto the screw thread until the stop and tighten the locknut firmly. -
Page 8: Inserting The Digital Cylinder Into The Lock
SLP Locks The Digital Locking Cylinder 3061 FD is used for applications of this type. The Digital Locking Cylinder 3061 VdS does not have approval for SLP doors at this time. See the “Digital Locking Cylinder 3061” manual “Possible Applications. -
Page 9: Data Sheet
Digital Locking Cylinder 3061 VdS Page 9 Data Sheet Knobs Material Stainless steel Colours Brushed stainless steel Brass Diameter 30 mm FH cylinder knobs Material Outer knob stainless steel, inner knob plastic Colour Black Diameter 30 mm Profile cylinders Standard length...
