  • Page 1 Adronic V55N User Manual Please read the user manual carefully before using this system.

  • Page 2: Table Of Contents

    For A Better Inspection Tool Content 1. Introduction 2. Main Device and Accessory 3. Scope Function 4. Monitor Key Instruction 5. Operation Instruction 5-1 Video Mode 5-2 Play Mode 6. Application 7. Specification 8. Attention 9. FAQ...

  • Page 3: Introduction

    ” digital LCD monitor, this unit could connect with a variety of adroVision inspecting probe to display the high quality image. The screen is clear and stable, also could manually adjust the image size and illumination. Adronic V55N enable to support Snapshot, Audio and Video recording to enhance the detection performance.

  • Page 4: Scope Function

    For A Better Inspection Tool 3. Scope Function 3. Scope Function Indication Light:Charging Video Recording Key Indication Light:DCIN Snapshot Key Indication Light:Power/SD Card Detection Light TV-OUT Power On/Off ESC Key DCIN Downward Key SD CARD Slot Upward Key RESET Key OK Key 1/4”-20 pitch machine screw stud for supporting camera stand...

  • Page 5: Monitor Key Instruction

    4. Monitor Key Instruction Button Video Mode Play Mode Setup Mode Zoom in (Magnification cycle Play/ Pause Video Move selection to from small to large) Zoom in the upper one 、 、 、 、 Zoom out Stop Video Move selection to (Magnification cycle Zoom out the lower one...

  • Page 6: Operation Instruction

    For A Better Inspection Tool 5. Operating Instruction 5 - 1 Video Mode (Preview Mode) • Video Menu： Press key to enter ； Press to exit ; Press key to select item Selecting Item Function Remark Sound 1.On 2. Off Grid 1.On 2.
  • Page 7 (Video Mode) Grid (Video Mode) Mirror (Video Mode) Factory Set 1) Press key to execute setting , then press to select “Brightness” or “Contrast” . 2) Press key to adjust the value of parameter . 3) Press key to confirm setting . 4) Press key to exit setting .

  • Page 8: Play Mode

    For A Better Inspection Tool 5. Operating Instruction 5 - 2 Play Mode Under “ Video Mode ”→ Press key to enter “File List Preview” → Press key to select the file → Press key to check the file . （...
  • Page 9 （ Video File *.avi ） 1) Press key: Play video . 2) Press key again : Pause video . 3) Press key: Stop video . 4) Press key: Speed up playback . 5) Press key: Rewind function. 6) Press key: Forward function.
  • Page 10 For A Better Inspection Tool (Play Mode) Delete (Play Mode) Slide Show (Play Mode) Thumbnail (Play Mode) File List Image Details...
  • Page 11 (Play Mode) Volume • Setup Menu: Press key then press to enter “Setup Menu” . Selecting Item Function Default Format 1.Cancel 2. Execute Menu 1. English, 2. Français, 3. Deutsch, 4. Italiano, 5. Españo, 6. Português, 7. 繁體中文 Language 简 体中文 , 9.
  • Page 12 For A Better Inspection Tool (Setup Menu) Format (Setup Menu) Language (Setup Menu) Auto Off (Setup Menu) Sys. Reset...

  • Page 13: Date Format

    (Setup Menu) TV Output (Setup Menu) Date Input 1) Press key to select “Date Format” 2) Press to select the adjusted item, then press to set the Date/Hour/Minute/Second . 3) Press key to confirm setting and exit . (Setup Menu) USB •...

  • Page 14: Application

    For A Better Inspection Tool 6. Application Adronic V 55 N Application OD1.9-10mm Fiber Optical Rigid Scope OD3.9-16mm Standard Probe OD20/25mm Fiber Glass Scope OD3.9-6.5mm 90˚ Rigid Probe OD40/50mm Fiber Glass Scope OD3.9-16mm Articulation Probe Pen Type...

  • Page 15: Specification

    7. Specification V55N Model Name digital LCD display Display ” Full HQ 720 x 640 pixels Resolution Still Image Storage JPEG Format Video Recording MPEG4/AVI Format 17 languages are available (1 English 2 French 3 German 4 Italian 5 Spanish 6. Portuguese 7.

  • Page 16: Faq

    For A Better Inspection Tool 9. FAQ Could not take photo and video recording Power on failure Recharge the battery by power charger. Check the probe connection. No inspection image Be sure to plug tube well and restart the unit. Please take a needle-like object made with System crash insulating material to insert into the reset hole...
