VHDC300 Manual
10/9/00
VGA/HDTV
Component Video (Y Pr Pb) Adapter
12VAC
300mA
Thank you for choosing the VGA/HDTV Component Video (Y Pr Pb)
Adapter. You have selected a quality product designed to provide
years of performance. Before attempting to use your video adapter,
please remove all accessories from the box and read the installation
and use instructions carefully.
• 1- VGA/Component Video (Y Pr Pb) Adapter
• 1- 2ft. VGA Cable
• 1- 6ft. Component Video Cable
• 1- 12 Volt AC Power Supply
1 Year Limited Warranty
2:46 PM
Page 1
V I D E O
OUTPUT TO TV
ON
OFF
Pr
Pb
Y
VHDC300

Advertisement

Table of Contents
loading

Related Manuals for THOMSON VHDC300

Summary of Contents for THOMSON VHDC300

  • Page 1 VHDC300 Manual 10/9/00 2:46 PM Page 1 V I D E O VGA/HDTV Component Video (Y Pr Pb) Adapter 12VAC OUTPUT TO TV 300mA Thank you for choosing the VGA/HDTV Component Video (Y Pr Pb) Adapter. You have selected a quality product designed to provide years of performance.
