- Page 1 Before operating this unit, please read this manual CR100000377 thoroughly and retain it for future reference. User’s Manual GKB VeriFire The Fire/Smoke Detect Expert GKB NC3860VD & GKB NC6960VD Camera Quick Setup version: 2.1...
- Page 2 GKB NC3860VD & GKB NC6960VD Camera...
- Page 3 Precaution 1. Do not drop the camera. GKB VeriFire Series IP Camera is not designed to resist heavy impact. Handle with care to avoid damage to sensitive internal components. 2.Do not expose the camera to radio activity and mount facing strong light sources.
- Page 4 GKB NC3860VD & GKB NC6960VD Camera TALBE OF CONTENTS Network Setup 2. Configuration Setup 3. Fire/Smoke Detection Alarm Setup 4. Appendix Do not dispose this camera as general waste. This product must be treated as a recyclable product. Contact your local government recycling program or the supplier of the product to confirm the proper...
-
Page 5: Network Setup
GKB NC3860VD & GKB NC6960VD Camera 1. NETWORK SETUP VeriFire IP Camera and NVR System Design LAN Connection Setup WAN Connection Setup... -
Page 6: Configuration Setup
GKB NC3860VD & GKB NC6960VD Camera 2. CONFIGURATION SETUP Mouse buttons: Left Click Enter & Right Click ESC Move the mouse to the bottom of the monitor, and left click MENU to call up Menu display. Left click Login/Logout to login the system... - Page 7 GKB NC3860VD & GKB NC6960VD Camera Left click Setup Left click Network...
- Page 8 GKB NC3860VD & GKB NC6960VD Camera Left click +/- to change the highlighted option to DHCP Left click top-right corner x, click Yes and wait...
- Page 9 GKB NC3860VD & GKB NC6960VD Camera It will assign IP Address automatically, click Yes to continue Left click Pre-Camera Setup Left Click +/- to change the highlighted option to Pre-Camera ...
- Page 10 GKB NC3860VD & GKB NC6960VD Camera Left Click Settings to call up IP CAM Setup Left click Discover and left click on the IP CAM in the list for the URL. This URL is automatically assigned by DHCP ...
- Page 11 GKB NC3860VD & GKB NC6960VD Camera On local/remote PC site, enter IP address which is assigned automatically by DHCP, ex: [192.168.99.223] in your IE browser and you'll see below. User name : admin / Password : admin...
- Page 12 GKB NC3860VD & GKB NC6960VD Camera 3. FIRE / SMOKE DETECTION ALARM SETUP Move the mouse to the bottom of the monitor, and left click MENU to call up Menu display. Left click Camera Setup...
- Page 13 GKB NC3860VD & GKB NC6960VD Camera Left click +/- to change the highlighted option to Camera Left click +/- to check/uncheck Fire/Smoke Detection this item, the default setting is √ : checked...
- Page 14 GKB NC3860VD & GKB NC6960VD Camera More detail settings left click Fire/Smoke Settings , it will show as below Left click +/- buttons to adjust the value (0-10 seconds) at Pre-record and Post-record ◎ Only one out of Fire/Smoke and Motion Detection can be chosen...
-
Page 15: Alarm Setup
GKB NC3860VD & GKB NC6960VD Camera 4. Appendix Alarm Setup Connect to IP Cam Enter IP Address in your IE browser on PC site User name : admin Password : admin Click on top-right corner VeriFire -> General Setting -> check Enable... - Page 16 GKB NC3860VD & GKB NC6960VD Camera To increase the fire/smoke detection sensitivity by adding Create Fire Point : click on top-right corner VeriFire -> Fire & Smoke Line -> Create Fire Point -> Save To decrease false alarm rate, you can add Create Disable Mask: click on top-right corner VeriFire ->...
- Page 17 GKB NC3860VD & GKB NC6960VD Camera Connect to IP Cam & NVR Left click Setup...
- Page 18 GKB NC3860VD & GKB NC6960VD Camera Left click Alarm Setup Alarm Setup display...
- Page 19 GKB NC3860VD & GKB NC6960VD Camera...
- Page 20 GKB NC3860VD & GKB NC6960VD Camera © 2016 GKB Security Corporation. Specifications are subject to change without prior notice.
