Summary of Contents for ELITEFOUR JC 582
Page 1
SHUTTER EXHAUST FAN EXHAUST VENTILATION FAN...
Page 3
MANUAL VERSION DMDC2001X1 PRODUCTS MODEL 10" Digital Controller Shutter Exhaust Fan JC 582 12" Digital Controller Shutter Exhaust Fan JC 588 14" Digital Controller Shutter Exhaust Fan JC 594 16" Digital Controller Shutter Exhaust Fan JC 600 18" Digital Controller Shutter Exhaust Fan JC 606 20"...
KEY FEATURES HEAVY DUTY BUILD WEATHERPROOF SMART CONTROLS Fans are enclosed in The shutter fan unit is sealed Programmable controller steel and wire guards to to Ingress Protection 44 with corded sensor can withstand shocks and harsh standards to be resistant to adjust airflow in response to environments.
PRODUCT CONTENTS AIRLIFT SHUTTER FAN SYSTEM (Included in all series) SHUTTER SENSOR DIGITAL FAN UNIT PROBE CONTROLLER (x1) (x1) (x1) WOOD MACHINE CONTROLLER WIRE SCREW SCREW SCREW SET TIES (x4) (x4) (x2) (x4)
MOUNTING STEP 1 When installing in a large room like a green house, barn, or garage, it is recommended that the shutter fan should be mounted on the Mounting Hole opposite side of any ventilation openings for better air circulation. The fan should also be positioned higher in the room to exhaust out heated air, which will rise on its own due to natural convection.
Page 8
MOUNTING STEP 3 Depending on your mounting surface material, use the appropriate tools to cut into the wall. Use a drill or a hand saw to create an opening large enough to insert a saw blade or jigsaw inside the outlined area of the wall panel. Thinner Woods or Plastic Woods, Tougher Plastic or, Metal STEP 4...
Page 9
MOUNTING STEP 5 From inside the room, position the shutter fan back into the opening of the fan. Make sure the controller connectors and power cord is on the inside of the room. Then, use the included hardware to secure the fan. Inside STEP 6 Once the fan is mounted securely you can...
POWERING STEP 1 Locate the connector plug of the thermal probe and plug it into the bottom of the digital controller. STEP 2 Secure the thermal probe head near by, preferably in the hottest area of the room. You can use the wire tie to secure the probe away from the fan blades.
Page 11
POWERING STEP 3 Connect the molex end from the fan into the bottom of the controller. STEP 4 Lastly, to power the fan and the controller, plug the fans power cord into an AC power outlet.
PROGRAMMING 1. MODE BUTTON 2. UP / DOWN BUTTON 3. LEAF BUTTON Cycles through the control- Turns the screen off Adjusts the settings of the ler's temperature/humidity while programs run in the mode that you are in. Up programming: ON, OFF, background.
Page 13
PROGRAMMING MODE SETTING Pressing the Mode button will cycle through the controller’s available programming modes and settings: ON Mode, OFF Mode, TIMER Mode, AUTO Mode (4 triggers), ALARM Settings (4 settings). ON MODE In this mode, the fan will heat continuously regardless of temperature or humidity.
Page 14
PROGRAMMING TRIGGER MODE: HIGH TEMPERATURE In this mode, pressing the up or down button sets the high temperature trigger. The fan will activate if the probe’s reading meets or exceeds this trigger. It will gradually ramp up until it reaches the ON Mode’s setting.
Page 15
PROGRAMMING TRIGGER MODE: HIGH HUMIDITY In this mode, pressing the up or down button sets a high humidity trigger. The fan will activate if the probe’s reading meets or exceeds this trigger. It will gradually ramp up until it reaches the ON Mode’s setting.
Page 16
PROGRAMMING ALARM SETTING: HIGH TEMPERATURE In this mode, pressing the up and down button sets a high temperature alarm. The alarm will sound and its icon will flash if the probe’s read- ing exceeds the set temperature. To activate the alarm, leave the alarm mode. The alarm will turn OFF if the probe’s reading Note that alarm triggers can only falls below the trigger or if any button is...
Page 17
PROGRAMMING ALARM SETTING: HIGH HUMIDITY In this mode, pressing the up and down button sets a high humidity alarm. The alarm will sound and its icon will flash if the probe’s reading exceeds the set humidity. To activate the alarm, leave the alarm mode. The alarm will turn OFF if the probe’s reading Note that alarm triggers can only falls below the trigger or if any button is...
Page 18
PROGRAMMING FAHRENHEIT OR CELSIUS To switch between Fahrenheit and Celsius readings, set the controller to OFF Mode. Hold the up button to switch to Fahrenheit (°F) and the down button to switch to Celsius (°C). DISPLAY BRIGHTNESS To adjust the brightness of the display, set the controller to OFF Mode, then press the up or down button to increase or decrease the brightness level.
Page 19
PROGRAMMING ALERT ICONS The top left of the display shows the alert icons. Icons may flash when the controller signals an alert to tell you a particular function or alarm is being triggered. DISPLAY LOCK ALERT This icon is visible when the controller has been locked. The icon will flash to alert you that the controller is locked if you try to change the mode or settings.
WARRANTY This product sold by ELITEFOUR is covered by our warranty program, our promise to you that your product will be free from defects in manufacturing for two years, starting from the date of purchase. If any faults in craftsmanship or materials are discovered, you may enforce this warranty to work out any issues.
