Summary of Contents for Vision HD MX0402-310
- Page 1 Model No MX0402-310 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product.
- Page 3 Introduction Vision HD ’s MX0402-310 is a 4-by-2 DVI/HDMI true matrix. It allows any source (Blue-Ray player, HD DVD player, satellite receiver, game system, etc.) to be shown on the any of the four displays simultaneously, no matter the source is HDCP or not. Extra infrared receiver extension, IR emitter, RS232 and Ethernet port are supplied for remote control.
-
Page 4: Table Of Contents
Contents HDMI Matrix ......................1 Product Overview....................1 Features ........................1 Package Contents....................3 Connections and Operations ................3 Specifications ......................5 Panel Descriptions ....................6 Typical Application....................7 Maintenance......................8 Product Service .....................8 Provided Service ....................8 Mail-In Service.......................8 Warranty ........................9 Warranty Limits And Exclusions................9... -
Page 5: Hdmi Matrix
IR emitter for IR call back function to control the HDMI source from remote rooms. HDCP compliant. HDMI 1.3 version. Notice Vision HD reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Page 1... - Page 6 Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
-
Page 7: Package Contents
Power on the input source you want to show. (Keep the unused input power off, otherwise it may interfere the normal display.) Connect the power supply into MX0402-310 and turn on the display you want to watch. Use remote or push the button to choose input source. - Page 8 Instruction on IR call back function The sequence of "TX IR1， TX IR2， TX IR3， TX IR4" one-to-one correspond with "HDMI INPUT1，HDMI INPUT2，HDMI INPUT3，HDMI INPUT4". When an output chooses certain input, the call-back IR signal of RJ45 on this output port will choose the corresponding "TX IR" port to send the signal out.
-
Page 9: Specifications
SOURCE-SINK AUTOFIT Function. This function applies to the situation when the source's HDMI version exceeds the sink's HDMI version. (This function can be used to fix the 1080p, 1080i, 2ch audio, multi channel audio issue.) For example: When the TV is HDMI 1.2 version and PS3 source is HDMI 1.3 version, it will output HDMI 1.2 version. -
Page 10: Panel Descriptions
HDMI cable Transmission <15m (If needed, HDMI extender is Distance optional) <30m(use Vision HD UTP receiver,if UTP cable Transmission need longer distance, Vision HD's UTP Distance repeater should be used) Power Consumption 10wtts (Max.) 440mmL×203mmW×43mmH Dimensions /17.3''L×7.9''W×1.6''H Mass (Main Unit) 2kg/4.4lb... -
Page 11: Typical Application
Rear Panel ① Power input. ② IR extension. ③ Output 1 and 2 with HDMI and CAT5E. ④ Input port 1 to 4 with corresponding IR emitter. ⑤ RS232 port. ⑥ Debug port. (For matrix control) Note: RS485 port and LAN port are for matrix control. The LAN port is connected to the computer via direct UTP and connected to the router via cross UTP. -
Page 12: Maintenance
Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;... -
Page 13: Warranty
Warranty If your product does not work properly because of a defect in materials or workmanship, Vision HD (referred to as “the warrantor”) will, for the length of the period indicated as below, （Parts (1) Year， Labor(90) Days）which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished... - Page 14 damage, modification, or service by anyone other than a Factory Service Center or other Authorized Service, or damage that is attributable to acts of God. There are no express warranties except as listed under “limited warranty coverage”. The warrantor is not liable for incidental or consequential damages resulting from the use of this product, or arising out of any breach of this warranty.
