- Page 1 Instructions for Use Multiplex Trio E battery and toothed belt set for all Multiplex Trio E models Model 6146.39...
-
Page 2: Table Of Contents
Table of contents Table of contents About these instructions for use 1.1 Target groups 1.2 Labelling of notes 1.3 About this translated version Product information 2.1 Standards and regulations 2.2 Safety advice 2.3 Area of application 2.4 Product description Handling 3.1 Assembly 3.1.1 Mounting spare parts... -
Page 3: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 4: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g. -
Page 5: Product Information
Product information Product information Standards and regulations The following standards and regulations apply to Germany / Europe and are provided as a support feature. Regulations from section: Mounting spare parts Scope / Notice Regulations applicable in Ger‐ many 230-V connection VDE 0100 Part 701 (IEC 6036-7-701:2006, modified) Safety advice... -
Page 6: Product Description
Product information Product description Fig. 1: Multiplex Trio E battery and toothed belt set Battery Toothed belt Multiplex Trio E battery and toothed belt set... -
Page 7: Handling
Handling Handling Assembly 3.1.1 Mounting spare parts Replace battery DANGER! An electric shock can lead to burns and serious injury and even death. Only allow electrical work to be carried out by qualified electricians. Always de-energise the connection cable before work is commenced. - Page 8 Handling ▶ Insert the new battery. ▶ Connect the battery to the control electronics. INFO! Observe correct plug alignment. INFO! Make sure you feel the plug snap into place. Replacing the toothed belt DANGER! An electric shock can lead to burns and serious injury and even death.
- Page 9 Handling ▶ Loosen the temperature sensor from the control electronics. ▶ Detach the label on one side. ▶ Expose the temperature sensor connection cable. ▶ Loosen the toothed belt on the left side of the large gear wheel. ▶ Loosen the toothed belt on the right side of the large gear wheel. Multiplex Trio E battery and toothed belt set...
- Page 10 Handling ▶ Pull off the toothed belt on the left side over the large gear wheel. ▶ Pull off the toothed belt on the right side over the large gear wheel. NOTICE! Do not damage the temperature sensor. ▶ Turn the large gear wheel on the left side anti-clockwise as far as it will go.
- Page 11 Handling ▶ Push the new toothed belt on the left side over the large gear wheel. ▶ Push the new toothed belt on the right side over the large gear wheel. NOTICE! Do not damage the temperature sensor. ▶ Lay the toothed belt on the left side on the small gear wheel. ▶...
-
Page 12: Disposal
Handling ▶ Check that the toothed belt is seated centrally. ▶ Connect the temperature sensor. ▶ Affix the label. ▶ Connect the plugs of the cables of the control and display element with the sockets of the control unit. Connect the control element with the socket marked "TLI A". Connect the display element with the socket marked "DISPLAY". - Page 13 Viega Technology GmbH & Co. KG service-technik@viega.de viega.com INT • 2020-02 • VPN190545...
