IROX ETS50 Manual

ETS50
The ETS50 is a replacement and additional sensor to the device EBR505 of iROX.
More probes on compatibilities www.irox.com / Support / sensors list.

BATTERY INSTALLATION FOR REMOTE SENSOR UNIT

1. Remove the battery cover by grabbing its bottom edge (near the two recess location) from
bottom of sensor unit.
2. Insert 2 pieces of AA size batteries according to the "+" and "-" polarity marks shown in the
battery compartment and then close the battery door with the clip on (press down the snap
on both sides slightly).

WIRELESS REMOTE SENSOR REGISTRATION PROCEDURE

1. Insert 3 pieces of AA batteries first to the main unit. The temperature display shows - - - -
while the wave icon will keep blinking for 2 minutes indicate the main unit is in sensor
searching mode.
2. In a second step, insert the 2 pieces of AA batteries into the sensor unit. The red LED on
the front will start flashing at a rate of one time per 2 seconds indicates channel-1 is in
use.
3. While the red LED is flashing, press once the ▲/CH button (located in the battery
compartment) will change the sensor channel setting to 2. Keep toggle on ▲/CH button
can change channel setting up to 3. The LCD is blinking at a frequency to indicate the
channel setting, i.e. continuous blinks 2 times indicate channel-2 is selected.
Note: If user does not press any key for 10 seconds, it will exit the channel setting
mode and transmit the RF signal. The main unit will register the temperature
reading.
For later sensor search and registration:
Start the sending mode on the main (EBR505) unit by pressing the ▲/CH button for 2
-
seconds.
On the sensor unit do as described in step 2 and 3 above.
-
For more details, read the manual of the display device!
