Thank you for choosing this quality product. Be sure to check all packaging materials carefully for small parts that may have
become loose during shipment and place all parts on a non-abrasive surface.
IMPORTANT :These parts can be cumbersome and heavy to some people, therefore the assistance of two or more people is
recommended in order to prevent personal injury and ensure the furniture is not damaged during the assembly Process.
PART LIST
A [ 1 ] TABLE TOP
B [ 2] TABLE LEAVES
C [ 1 ] BASE
INSTRUCTIONS
Bring the table top (A) and set it on the base
1.
(C). Align the fixed nuts at the bottom of the
top to the holes on top of the base. Insert Allen
bolts (1 ) throught to Lock washers (2) and Flat
washers (3) into each fixed nuts through the
holes on top of the base, then tighten them by
using Allen key (4). DO NOT OVER TIGHTEN
Refer to FIGURE 01.
EM ERSON DINING TABLE
HARDWARE LIST
NO
D ESC RI PT I O N
1
2
3
4
A
.
ALLEN HEAD BOLT
LOCK WASHER
PLAIN WASHER
ALLEN WRENCH
C
FIGURE 01
3
2
1
Page 1 of 2
QTY
12
12
12
1
4
Advertisement
Table of Contents
Related Manuals for Resource Decor Emerson Dining Table
Summary of Contents for Resource Decor Emerson Dining Table
- Page 1 EM ERSON DINING TABLE Thank you for choosing this quality product. Be sure to check all packaging materials carefully for small parts that may have become loose during shipment and place all parts on a non-abrasive surface. IMPORTANT :These parts can be cumbersome and heavy to some people, therefore the assistance of two or more people is recommended in order to prevent personal injury and ensure the furniture is not damaged during the assembly Process.
- Page 2 FIGURE 02 Align and insert two leaves (B) to both ends of the table top (A). Secure these parts with the metal locks. See FIGURE 02 & 03. Check the table leveling, and adjust the levelers at the bottom of the base .
