- Page 1 CGC MANUAL CGC100 Installation manual Document time: Pd_IM_0006, Issue A.1 CTEK E-Mobility www.ctekemobility.com Page 1 (8)
- Page 2 CGC100 MANUAL Warranty The CTEK E-Mobility warranty for load balancers in the CGC range is valid for 12 months starting from the date of delivery. Products that become defective during the warranty period will be repaired or replaced. The warranty is only valid if the product has been used in accordance with the manufacturer’s instructions.
- Page 3 CGC100 MANUAL TABLE OF CONTENTS General information ........................4 Purpose ........................... 4 References ..........................4 Before installation .......................... 4 Tools ............................4 Material/ equipment ......................... 4 Details ............................4 Dimensions ..........................4 Installation site ......................... 4 Installation ..........................5 Cable installation ........................5 2.7.1...
-
Page 4: General Information
CGC100 MANUAL 1 General information The CHARGESTORM® Connected Grid Central (CGC100) is a load monitor for electric vehicle charging stations. It can also monitor other loads at the property during load balancing. The CGC100 can act as an internet gateway to Charge Portal, CHARGESTORM®... -
Page 5: Installation
You will also transformer cables must be installed from the need an additional port for Internet access, if energy meter in the CGC100 to the relevant required. metering point. Install one current transformer per phase, i.e. -
Page 6: Cable Installation - Power
Cable installation – power 2.7.4 after changing the configuration (See manual ref. 1) how to The CGC100 is supplied with 230VAC. The connect to the local web interface) input power should be connected to an internal b. Configure CGC100 via the mini terminal block. - Page 7 Ethernet. The way in which the load monitor connects to the internet and contacts the portal is described in reference 1). The login details for the portal must be obtained from CTEK E- Mobility in advance. You can request the login details from your sales contact.
-
Page 8: Functionality
CGC100 MANUAL Testing the load monitor 4 Functionality Connect electric vehicles to all the units and The load monitor and charging stations can be check that the sub-unit is showing that the total used immediately after installation and current does not exceed the rated current.
