Summary of Contents for Consair CAMU D2
- Page 1 Käyttöohje (Original) Consair CAMU D2 Bruksanvisning Instructions Gebrauchsanweisung Source extractor for dust control in dry-mix blending...
- Page 2 Manufacturer: Consair Oy Lapinlahdenkatu 16 FI-00180 Helsinki Finland info@consair.fi consair.eu...
-
Page 3: Table Of Contents
8.4 Work light Indication of the need for a filter replacement with an indicator light Indication of fault modes with an indicator light Exhaust air outlet 9. Filters..........................Filter types and categories Important to know when changing filters Pre-filter replacement Main filter replacement 10. Maintenance..........................6 Cleaning of the device 10.1 10.2 Cleaning of the engine bay 10.3 Replacement of the panels in the air-guiding doors 11. Transportation......................... 8 11.1 Transportation at the construction site 11.2 Transportation in the cargo space of a vehicle 11.3 Mechanical lifting 12. Storage..........................13. Technical data........................ 8 14. Problematic situations and troubleshooting............. 9 15. Declaration of conformity....................10 Consair CAMU D2... -
Page 4: Introduction
Introduction Important information This instruction manual describes the operation of the Con- The Consair CAMU D2 source extractor has been designed sair CAMU D2 source extractor. In this manual, it is also re- for indoor use, and it may only be used for the processing ferred to as the ‘device’ or ‘machine’. Read the instruction of dry matter, such as dry-mix concrete and mortar. The... - Page 5 Do not store the device outside without weather protection. Risk of property damage: Do not place heavy objects on top of the machine. Do not connect extension cords to the sockets of the device. Only electrical equipment used at the workstation may be connected to the sockets of the device. Do not use damaged or clogged filters. The red indicator light in the control panel Risk of personal injury and indicates that a filter has become clogged. property damage: The device may not be used without filters. Do not attempt to clean the filters, as cleaning may damage the filter material. Clogged filters must always be replaced with new ones. Make sure that the replaced filters fit properly in their place. Carelessly installed filters may cause the dust to flow past the filters. The device may not be used in a facility where harmful substances, such as asbestos, have been used until the facility has been appropriately cleaned. It is forbidden to use the device for the processing of materials that may contain hazardous harmful substances (e.g., demolition waste). The protective doors of the device must always be closed for the duration of transfers. Open doors may become detached and damaged and cause personal injuries or property damages while falling down. The device must always be strapped to the cargo space for transportation. The device may not be used in facilities where explosive gases occur. The device may Great risk of explosion: not be used for the processing of explosive or flammable materials. Consair CAMU D2...
-
Page 6: Implementation
If the exhaust air outlet of the device is connected so that it is faces. directed outwards from the building, it must also be noted that due to fluctuations in temperature and air humidity, condensa- 8.3 Startup and shutdown tion, which reduces the service life of the filters, may occur in the filters. The device is only equipped with one operating button that is used for controlling the device. • One short push starts the device for 5 minutes, after which Consair CAMU D2... - Page 7 Dust is produced when the bag is opened, closed, or emptied and when dry matter is mixed. Figure 2 – Operating button and indicator lights Figure 3 – Interpretation of the indicator lights Main filter indicator Green = Filter OK light Orange = Filter saturation rate over 70% Red = Full -> Replace the filter • The indicator lights are constantly on when the device is running and the suction is on. • The indicator lights are flashing when the device is Pre-filter indicator Operating button in the standby mode. light • The device indicates fault modes with two flashing red indicator lights. See page 4, section 8.5. Consair CAMU D2...
-
Page 8: Filters
9.1 Filter types and categories 10.1 Cleaning of the device The pre-filter used in the CAMU D2 source extractor is devel- Mortar splatter can be removed from painted surfaces with oped by Consair Oy and equipped with two-phase coarse- water and, e.g., a coarse sponge. The splashguard surfac- dust filtering and a dust-collection container. As much as es made of plastic can be cleaned with water and scraped 750–1,500 grams of coarse and fine dust produced by... - Page 9 Figure 4 – Pre-filter replacement Figure 5 – Pre-filter replacement Figure 6– Replacement of the panels in the air-guiding doors Consair CAMU D2...
-
Page 10: Transportation
IP rating IP21 11.3 Mechanical lifting Electrical outlets 2 pcs with protective earthing** The device has not been designed to be lifted mechanically, Air volume 500 m and it does not contain a lifting lug intended for mechanical lifting. The detachable parts of the device may cause seri- Sound power level Lw(A) xx dB ous injuries if they fall down. Main filter Pre-filter *The air volume and air flow rate have been optimised for source extraction, and they remain unaltered for the entire service life of the filters. **The maximum wattage for the coupled devices is 3,000 W. The connection of extension cords is forbidden. Consair CAMU D2... -
Page 11: Problematic Situations And Troubleshooting
The indicator lights of the filters and the The wiring harness or control unit of the Contact the manufacturer. work light are not on, but the device is device may have become damaged. otherwise functional. The work light does not go on, but the The power source or control unit of the Contact the manufacturer. device is otherwise functional. device may have become damaged, or the LED luminaire is damaged. Unscrew the locking screws of the door. The air-guiding doors open and close The tubular profile of the door may have Check the condition of the tubular door with difficulty. bent. The rear edge of the door may hit the frame. Check that the pre-filter en- pre-filter enclosure. The locking screws of closure is in place and the latches are the door have not been unscrewed. closed. Contact the manufacturer, if necessary. The air-guiding door does not stay in The tubular profile of the door may have Contact the manufacturer. contact with the magnetic hinge. bent. Consair CAMU D2... -
Page 12: Declaration Of Conformity
Declaration of conformity EC declaration of conformity Machinery Directive 2006/42/EC Manufacturer: Consair Oy Lapinlahdenkatu 16 FI-00180 Helsinki consair.eu info@consair.fi Declares that Equipment type: Source extractor for dust produced by the mixing of concrete, mortar, and plaster Brand: Consair Type designation CAMU D2 • complies with the relevant provisions of the Machinery Directive (2006/42/EC) • complies with the relevant provisions of the Low Voltage Directive (2014/35/EC) • complies with the relevant provisions of the EMC Directive (2014/30/EC) on electromagnetic compatibility On behalf of Consair Oy, signed by: Place, time: ..................Manufacturer, authorised representative Signature: ..................(First name Last name/title) In accordance with Appendix II to the Machinery Directive 2006/41/EC), the following is stated: This declaration exclusively relates to the machine in the condition in which it was placed on the market, and it does not cover the parts added to it afterwards by the end user and/or the operations the end user has carried out using the machine. Consair CAMU D2...
